  • Page 1 UDT-4K Transmitter Manual...
  • Page 2 Accessories included in this manual: PAC Clip-on Amplifier AVF Flexible Antenna PA / PA Ultralinear Power Amplifier RTC-03 Remote Control...
  • Page 3 This chapter indicates the available connections of the transmitter, the characteristics and the installation. Chapter 9: Remote Control The UDT-4K Transmitter can be controlled remotely by the RTC-01 or RTC- 03 devices or a RS-485 connection. Chapter 10: Mechanical Dimensions In this chapter, the mechanical drawings of the units described in this manual are included.
  • Page 4 Annex A: PA Power Amplifiers This annex explains the main characteristics of SVP Broadcast Microwave’s PA Power Amplifiers. Annex B: AVF Flexible Antenna User’s Guide The different flexible antennas and its characteristics are explained in this chapter. Annex C: Modulation Standards This chapter describes the DVB-T/T2 and DVB-S/S2 standards, as well as their features and the differences between them.
  • Page 5 We are sure that the addition of this equipment will give you a complete satisfaction in your existing installation. Please read these instructions carefully and keep them in hand in case you have to refer to them. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 6 About this manual This user’s guide provides indications and explanations about how to set up the UDT-4K easily for the most common use cases. This document is intended to help first time users: • To find their way around the GUI.
  • Page 7 50% compared to its predecessor, the H.264. • The UDT-4K HEVC UHD Multiband Transmitter is available from 1 GHz to 8 GHz, for the DVB-T2 and DVB-T. The L band output for the DVB-S2 and DVB-S is optional.
  • Page 8 PA-5 (5 W Power Amplifier), the minimum distance is 28.2 cm and if PA- 10 (10 W Power Amplifier) is used, the minimum distance is 39.9 cm. SVP Broadcast Microwave, in accordance with the requirements set forth by the FCC, provides this information as a guide to the user.
  • Page 9 G = 3 = 100 mW EIRP = 200 mW = 4 cm = 1.57 in 2. UDT-4K Transmitter + PA-5 (5 W) with AVF antenna G = 3 = 5000 mW EIRP = 10000 mW = 28.2 cm = 11.1 in 3.
  • Page 10 20 cm. The equipment, which consists of the UDT-4K Transmitter with the AVF-203 antenna fixed to it, fulfils this requirement. As shown in the figure below, the distance between the device’s radiating element (situated at the top of the...
  • Page 11 1.5 GHz, it is also exempted from the RF exposure evaluation because the maximum e.i.r.p. (200mW) is lower than 2.5 W. Conclusion: This equipment is exempted from the RF exposure evaluation. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 12 In the case of injuries to the mouth, it may be necessary to use mouth-to-nose resuscitation. Seal the victim’s mouth with your cheek and blow firmly into his nose, proceeding as above. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 13 If help as available or as soon as resuscitation is no longer required, the wound should be covered with a DRY clean dressing. Oil or grease in any form should not be applied. If severely burnt, get the victim to hospital immediately. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...

  • Page 14: Table Of Contents

    6.2.2.1 BUC Connection pinout ..........134 6.2.2.2 PA Remote Control Cable pinout ......... 134 6.2.3 RTC-DATA ..............135 6.2.4 INTERCOM-TALLY ............136 6.2.5 Video inputs ..............137 6.2.6 Audio inputs ..............138 6.2.7 Remote ..............139 UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 15 10.3 Return procedures ............161 10.4 Transportation and packaging ........162 10.5 Authorization for evaluation ........... 162 Annex A: PA Standard and PA Ultralinear Power Amplifiers ..163 A.1 Introduction ..............164 UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 16 C.3.1 How Does It Work ............183 C.4 DVB-S2 ................. 184 C.4.1 How Does It Work ............184 C.4.2 Pilots in DVB-S2 .............. 186 C.4.3 DVB-S vs DVB-S2 ............187 Glossary ..................189 UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...

  • Page 17: Chapter 1: Introduction

    Chapter 1: Introduction The UDT-4K is the multifunction and multiband transmitter developed by SVP Broadcast Microwave. The features of this equipment, achievable only by SVP, make this transmitter the most advanced in the market to date. Its feature HEVC encodes for 12G video quality signals with ultra-low latency.
  • Page 18 The equipment is fed with DC power supply from 9 to 36V. It can be powered through DC power supply connector or through the battery mount (optional). Its excellent design, mechanical and electronic assembly make the UDT-4K a robust and reliable solution.
  • Page 19 46 Mbps. DVB-T features The RF stage of the UDT-4K Transmitter is the same as the DVB-T2 one. The difference is found in the modulation part as it is commented below. The UDT-4K digital camera transmitter uses COFDM (Coded Orthogonal Frequency Division Multiplexing) modulation system (2K mode).
  • Page 20 DVB-S2 features (optional) In case the UDT-4K Transmitter is needed to be used as a satellite transmitter, it features an IF stage in the L band with an output power level from -50 to +5 dBm and a high stability and low phase noise.

  • Page 21: Chapter 2: Technical Features

    Max. bitrate: 31.67 Mbps ISDB-T (optional): COFDM 2K, 4K and 8K mode QPSK, 16QAM, 64QAM FEC: 1/2, 2/3, 3/4, 5/6, 7/8 IG: 1/4, 1/8, 1/16, 1/32 Bandwidth: 6, 7, 8 MHz Max bitrate: 31 Mbps UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 22 16 channels (8 pairs) Formats: Embedded or Analogue Analogue Input: 2 pair Line / Mic level Analogue Max. Level: 24dBu (Balanced) Phantom Power: 48V Phantom Power Test Signals: Video: Bars Audio: 16 Audio tones UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 23 Front panel and display Web Server interface RTC-03 via cable Monitoring: Encoding parameters Demodulation parameters Frequency and output level Alarms and warnings are sent to the receiver via RF Presets 7 user define presets UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 24 Panasonic, Sony and Grass Valley Intercom frequency range: 400 to 480 MHz Intercom Output power: 10/100mW Intercom Audio connector: Micro, Speaker and PTT in a Lemo 7pin Tally: Tally RED, Tally GREEN and On Camera UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...

  • Page 25: Chapter 3: How To Order

    Chapter 3: How to order UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...

  • Page 26: Chapter 4: Transmitter Operation And Menus

    Next, the main screen of the UDT-4K_HEVC Transmitter is shown. Figure 4.1: UDT-4K front panel / Main screen explanation Once an option has been selected, the main screen appears and these parameters are displayed: •...
  • Page 27 Next, the linkages between the input and the character on screen is shown: Video Test-Pattern Embedded Audio Analogue Test-Tone RS232 Data Remux Table 4.1: Linkages between the input and the character displayed UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...

  • Page 28: Leds

    4.2 LEDs The UDT-4K Transmitter has 5 LEDs on its front panel that show the information detailed below. ON/OFF ALARM REMOTE STATUS Figure 4.2: UDT-4K front panel LED indication The ON/OFF provides the following information: • If the LED is off, the equipment is not being fed.

  • Page 29: Front Panel

    4.3 Front panel The UDT-4K camera transmitter is configured following the menus structure on the display. The front panel has 8 buttons to enter and exit the equipment’s control menus and submenus and to navigate through them. The function of each button is detailed in the following sections.

  • Page 30: Cross Button

    In case the device is switched off with the RF output enabled then, when it is switched on again it is necessary to push again this button to enable this feature. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 31 However, if power supply fails when RF output is enabled then, once power supply returns it is not necessary to push this button because RF output will continue being enabled. Figure 4.9: RF On/Off button UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...

  • Page 32: Menu Scheme

    On the next page, a scheme that specifies the different menu options available are shown. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 33 Analogue 1 Analogue 2 Generator Generator Mode Mode Mode Mode Format Status Format Bitrate Bitrate Bitrate Bitrate Latency Bitrate Latency Profile Profile Depth Depth Mode Mode Sample Sample Format Formar Multivideo Multivideo UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 34 Audio1 PID Audio2 PID Baud Rate Antenna 5V Disable Enable Disable Enable Audio3 PID GPS Info Audio4 PID Audio5 PID Audio6 PID Audio7 PID Audio8 PID Data PID PMT PID PCR PID UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 35 LDPC FEC Symbol Rate and Bandwidth Spectrum Guard Interval Guard Interval Roll Off 10MHz Reference Spectrum Pilots Antenna Gain Time interleaving DC by RF Spectrum DC by RF 10MHz Reference Antenna Gain UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 36 Pwr Out Lemo Battery Pack Keyboard Lock Gate Night Mode Distance Units Admin Pas Video Switch Restore Admin Pas T / T2 Carrier User Pas Activation Key Restore User Activation Licenses Load Encryption keys UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...

  • Page 37: Menu Navigation

    4.5 Menu Navigation This section contains a detailed description of each parameter that can be configured in the UDT-4K HEVC camera transmitter via the menu. To enter the menu, press the Cross button in the case of being on the principal screen or in any submenu.

  • Page 38: Menu Structure

    • RF – DVB-T2/T/S2/S transmission parameters are set in this section. • Unit – Parameters related to the Web Server and other internal options of the transmitter are configured here. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 39 < Audio 8: None > ENCODER Data: RS232 <> GPS: On < KLV Metadata: Off > ENCODER Encoder Output TS Parameters Scrambler: None > ENCODER Remux: Disable > ASI out: Enable > UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 40 Once the Audio 1 input has been selected, press the OK button to configure the parameters related to it. The available options are: None • Embedded • Analogue • Generator • UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 41 Once the Audio 1 input has been selected, press the OK button to configure the parameters related to it. The available options are: • None Embedded • Analogue • • Generator UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 42 In this field, remux option can be activated. This feature is optional. ASI out (eligible parameter): In this field, ASI output option can be activated. This feature is optional. Table 4.2: Encoder Menu UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 43 1080p 23/24/25/29/30 • • 1080psf 23/24/25/29/30 • 1080p 50/59/60 2160p 23/24/25/29/30/50/59/60 • Single HD/UHD operation video format must much that of the video input. Multivideo operation video input is more flexible. • UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 44 In this field, the Multivideo mode is enabled or disabled. The available options are: • Off. Standard mode for single HD/UHD operation. On. Flexible video input format and 4x HD operation. • Table 4.3: SDI Input menu options UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 45 ASI signal then, “No present” will be displayed. The available options are: Present • No Present • Bitrate (reading parameter): In this option, the bitrate of the ASI input signal is shown. Table 4.4: ASI Input menu options UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 46 In this field, the video format is selected. The available options are: 480i59 • 576i50 • 480p59 • • 576p50 720p 50/59/60 • • 1080i 50/59/60 1080p 23/24/25/29/30 • 1080psf 23/24/25/29/30 • 1080p 50/59/60 • 2160p 23/24/25/29/30/50/59/60 • UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 47 In this field, the Multivideo mode is enabled or disabled. The available options are: • Off. Standard mode for single HD/UHD operation. On. Flexible video input format and 4x HD operation. Table 4.5: Generator Input menu options UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 48 Audio Stream Bitrate (Kb/s): In this field, the audio stream bitrate, currently information only which depends on the encoding mode. Table 4.6: Audio Embedded Input menu options UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 49 Audio Stream Bitrate (Kb/s): In this field, the audio stream bitrate, currently information only which depends on the encoding mode. Table 4.7: Audio Embedded Input menu options UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 50 Audio Stream Bitrate (Kb/s): In this field, the audio stream bitrate, currently information only which depends on the encoding mode. Table 4.8: Audio Embedded Input menu options UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 51 (Parity options are None, Odd, Even). Stop Bits (eligible parameter): Select the same number of stop bits as the received data user signal has (Stop bit options are 1 or 2). Table 4.9: RS232 Parameters UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 52 • Height of the Transmitter: The height of the transmitter from ground is specified in this value. • Satellite Level: The level of each satellite signal received is shown in this field. • Date: The updated date is shown. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 53 When this option is ON, the KLV Metadata embedded on the SDI signal is sent through the radio link. If KLV metadata is not embedded on SDI input, the UDT-4K Transmitter will show an alarm indicating that the KLV is not present.
  • Page 54 If the user selects the manual option, the first and second lines disappear on the main screen. When the encoder output is in Manual, if you activate the RF, the encoder output changes to AUTO mode automatically. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 55 Here the Video packet identifier must be entered. To change its value, first press the OK button and then, with the UP, Down arrows select the desired number. Press the OK button to save the introduced value. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 56 Here the Program Map Tables packet identifier must be entered. To change its value, first press the OK button and then, with the UP, Down arrows select the desired number. Press the OK button to save the introduced value. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 57 To change its value, first press the OK button and then, with the UP, Down arrows select the desired number. Press the OK button to save the introduced value. Table 4.10: Encoder TS menu options UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 58 With Left and Right buttons select one field and with UP, Down buttons choose one value from 0 to 9 or A to F. Press the OK button to set the key. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 59 Figure 4.24: Remux work diagram ASI bitrate must be known. You must configure it to have ASI input Bit rate plus NTT encoder Bit rate minor than modulator total Bit rate. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 60 From this menu, end user can enable or disable de ASI output. Disable ASI output when it is not used, reduces the consumption of the transmitter. ENCODER Scrambler: None > Remux: Enable < ASI Out: Enable < Figure 4.25: Remux menu screen UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 61 Select the frequency at which the signal is going to be transmitted. To establish the frequency value first, press the OK button and then, with the Up, Down arrow buttons select the desired value. To save the introduced value, press the OK button. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 62 • Power is automatically configured to PA mode when there is communication between the UDT-4K and the PA. Then, the output power can be selected using Left and Right buttons. The output power indicated as Low, Mid and High will depend on the PA model used.
  • Page 63 UDT-4K transmitter. The available options are: • On: Input supply voltage of the transmitter is delivered by • the RF output (between 8 and 36 VDC) Table 4.12: DVB-T2 menu option UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 64 DC by RF: Off > Figure 4.28: DVB-T Menu With these parameters the modulation parameters in DVB-T are configured. This is how we can vary the robustness and the bitrate of the link. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 65 • Power is automatically configured to PA mode when there is communication between the UDT-4K and the PA. Then, the output power can be selected using Left and Right buttons. The output power indicated as Low, Mid and High will depend on the PA model used.
  • Page 66 UDT-4K transmitter. The available options are: • • On: Input supply voltage of the transmitter is delivered by the RF output (between 8 and 36 VDC) Table 4.13: DVB-T menu option UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 67 Modul: 32APSK < LDPC FEC: 4/5 <> SR:12.400 B:14.88 DVB-S2 Roll Off: 0.20 > Pilots: On > Spectrum: Normal > DVB-S2 10MHz: Off < Ant. Gain: 42.0dBi BUC:None > Figure 4.29: DVB-S2 Menu UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 68 In this field, the value of the output power can be selected. The possible output power range is from -55 to +5 dBm. The available options are: L-BAND (The output power of the UDT-4K in dBm). • • HPA (The output power of the amplifier in dBW).
  • Page 69 Here the type of the spectrum is configured. Inverted spectrum is just another method to help prevent signal theft. Use Right and Left buttons to select the desired option. The available options are: • Normal Invert • UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 70 BUC. The options available are: None (There is not BUC) • • IRT BUC WAV BUC • Table 4.14: DVB-S2 menu options UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 71 Next, a table is shown as an example of the Symbol Rate values for a determined Bandwidth of 28 MHz. Bandwidth (MHz) Roll-off Symbol Rate (Msymb/s) 0.20 23.33 0.25 22.4 0.35 20.74 Table 4.15: Symbol Rate calculation UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 72 In this screen the modulation parameters in DVB-S are selected. These settings affect to its L band output. DVB-S FEC: 7/8 < SR:12.400 B:14.88 Spectrum: Normal > DVB-S 10MHz: Off < Ant. Gain: 42.0dBi BUC:None > Figure 4.30: DVB-S Menu UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 73 The possible output power range is from -55 to 5 dBm. The available options are: • L-BAND (The output power of the UDT-4K in dBm). HPA (The output power of the amplifier in dBW). • EIRP (HPA + Antenna Gain) (dBW).
  • Page 74 BUC. The options available are: None (There is not BUC) • • IRT BUC WAV BUC • Table 4.16: DVB-S menu options UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 75 By using the Up, Down arrow keys, select the Unit option and press the OK key. UNIT RTC SEL: Disable > RTC-01 Config: RTC-03 Config: UNIT Alarms (None) View> Monitor Remote UNIT Miscellaneous Firmware Figure 4.31: Unit Menu UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 76 RTC model, press OK button to access to the profiles mode. Figure 4.32: Unit Profile Menu • Disable: The UDT-4K Transmitter works without the Profile option. • RTC-01: Select this option if RTC-01 is used. • RTC-03: Select this option when the NVIS RTC-03 is used.
  • Page 77 Alarms and warnings are displayed if you press OK button for a short time. The output power configured on the RTC-03 is shown on the main screen of the channel selection. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 78 1 2 3 4 5 6 7 Figure 4.36: Profile selected To return to the Main menu and change the UDT-4K configuration, press Exit. While the user is controlling the Transmitter via a Remote control, Web Server is not accessible.
  • Page 79 OK button, the available profiles will be displayed. There are seven profiles available and can be enabled or disabled. Figure 4.37: Profile Config Menu Select a profile and then press the OK button to configure the parameters related to it: UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 80 Audio1 PID: 201 PROFILE 1 Audio2 PID: 202 Data PID: 203 GPS PID: 206 PROFILE 1 Alarm PID:207 PMT PID:204 PCR PID:205 PROFILE 1 KLV Metadata: 40 TS is : 7 Network id: 7 UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 81 PROFILE 1 Network Name Remux: Disable > Figure 4.38: Profile 1 Menu UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 82 • Modulation (eligible parameter): In this field, the modulation must be chosen with the Right and Left buttons. The available options are: QPSK • 16QAM • • 64QAM 256QAM (Only DVB-T2) • UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 83 In this field, the sort of Audio signal introduced in the Audio 1 input can be chosen with right and left buttons. The available options are: Embedded • Analogue • • Tone.Gen None • UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 84 Ultra Low Delay Video Profile (eligible parameter): In this field, the codification profile can be configured. To select the desired profile, press Right, Left arrows buttons. The available options are: 4.2.0 • • 4.2.2 UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 85 In this option the network identifier must be specified. Network Name (editable parameter): Specify the name of the network. Remux: You can enable or disable remux mode with Right and Left buttons. Table 4.17: Profile menu options UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 86 Figure 4.39: Profile Config Menu Select a profile and then press the OK button to configure the parameters related to it: PROFILE 1 System:DVB-T2 < Freq: 2.300,00MHz RF Power: PA High < UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 87 Audio1 PID: 201 PROFILE 1 Audio2 PID: 202 Data PID: 203 GPS PID: 206 PROFILE 1 Alarm PID:207 PMT PID:204 PCR PID:205 PROFILE 1 KLV Metadata: 40 TS is : 7 Network id: 7 UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 88 PROFILE 1 Network Name Remux: Disable > Figure 4.40: Profile 1 Menu UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 89 • Modulation (eligible parameter): In this field, the modulation must be chosen with the Right and Left buttons. The available options are: QPSK • 16QAM • • 64QAM 256QAM (Only DVB-T2) • UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 90 In this field, the sort of Audio signal introduced in the Audio 1 input can be chosen with right and left buttons. The available options are: Embedded • Analogue • • Tone.Gen None • UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 91 • Video Profile (eligible parameter): In this field, the codification profile can be configured. To select the desired profile, press Right, Left arrows buttons. The available options are: • 4.2.0 4.2.2 • UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 92 In this option the network identifier must be specified. Network Name (editable parameter): Specify the name of the network. Remux: You can enable or disable remux mode with Right and Left buttons. Table 4.18: Profile menu options UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 93 • No RS232: RS232 data source is not connected. • No KLV • PA No Forward • PA Rev High • PA Volt Low • PA Temp High • WeightOnWheels • TS Error UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 94 In this field, the voltage of the transmitter is shown. • Battery Pack (reading parameter): In this field, the percentage of the battery is shown. 4.6.3.8 Remote Figure 4.42: Unit Remote Menu UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 95 Finally press the OK button to save the introduced values. Restore User Pass: This option enables you to restore the default user password (00000000). Table 4.19: Unit remote menu options UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 96 UNIT MISCELLANEOUS T/T2 Carrier: Off Activ Key:****** S/N: 660010911 UNIT MISCELLANEOUS Activ Licenses: Load Encry keys: WoW: Disable > UNIT MISCELLANEOUS WoW Polarity:>15V Pwr Out Lemo: Off > Figure 4.43: Miscellaneous Menu UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 97 Video switch: This option permits you to automatically switch the input signal source once the configured time for the signal source has ended. The configured video sources are switched in a looped sequence. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 98 For a new license code, please contact us. Load Encry Keys: In this field you can load the encryption keys for BISS and AES modes by USB. The file must have “.svp” extension and the content must be as it is indicated in the following example: AES128:1202A3412348C9127348FE2348971234...
  • Page 99 WoW Weight on Wheels Polarity (eligible parameter): The available options are: >15 VDC • • <15 VDC Power Out though Lemo (eligible parameter): The available options are: • • Table 4.20: Unit Miscellaneous menu options UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 100 The characters which describe the number of the version are inside the red box shown in the figure above. The rest of the characters are important for the manufacturer but are not important for the user. Table 4.21: Firmware menu options UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 101 Next, the necessary steps to make a successful update are explained. The latest firmware can be found on the website of SVP Broadcast Microwave. To access the firmware file, first enter www.svpbm.com in your web browser. Click on the Support tab.
  • Page 102 To verify the version of the transmitter, go to firmware field and then look at the current firmware to check the number installed in the device (the first two digits). Figure 4.48: Updating firmware step 5 UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 103 There, with the Up, Down buttons, select the Unit option. 10. Select Firmware by pressing the OK button. 11. Select Update Firmware with the OK button. Don’t power off the device during the updating process. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...

  • Page 104: Chapter 5: Web Server

    OK button and then, with the Up, Down keys select the desired number. To change from one character to another, press Right, Left keys. Press the OK button to save the introduced value. Figure 5.2: Local IP UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 105 8 digits. In this way, with this password, the administrator can access to the Webserver and make any configuration, modification or monitoring. Figure 5.5: Admin Pass UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 106 Figure 5.8: Restore User Pass Once the IP, Subnet Mask, Gateway, Admin Pass and User Pass are set and the laptop or PC is connected to the UDT-4K HEVC, open the web browser and type in the Local IP configured in the transmitter.

  • Page 107: Web

    Then the change will be set in the transmitter device. Moreover, to modify an eligible parameter, select the new one and the change will appear in the transmitter. Next several screens of the web server and their features are shown. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...

  • Page 108: Encoder

    6.2.1 ENCODER Figure 5.9: Web Server Encoder screen UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 109 Manual • Level (eligible parameter): In this field, the level of the HEVC encoder can be configured. The available options are: • • • 4.2 (only available in 1080p-50/59.94/60 Hz video formats) UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 110 This field is only configurable if analogic audio signals are introduced. The user can select the sort of signal of the Audio 1 right channel introduced in the transmitter. The available options are:  Line  MIC Dynamic  MIC Phantom UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 111 “GPS data verified” message. Nevertheless, if the transmitter does not detect any GPS input signal, the status field will show “GPS not detected”. The format of the GPS coordinates used is decimal minutes as shown in the next example: UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 112 FEC, IG, BW used, in order to the video bitrate can be always the maximum allowed. SVP advises the use of the automatic mode when the signal is transmitted through RF. Manual mode is useful when the device is used as an encoder to configure the desired output bitrate in the ASI output.
  • Page 113 When the enter button is pressed, the new values are saved, and the text will appear in BLACK. It is necessary to press the enter button to save the new values in the transmitter. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 114 TS from the internal NTT encoder. You must configure it considering that the ASI input Bit rate plus the NTT encoder Bit rate must be minor than modulator total Bit rate. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 115 Specify the power at which the signal is being transmitted (Variable, Low, High and PA). • Bandwidth (eligible parameter): Enter the transmitted signal bandwidth. The available options are 5, 6, 7 and 8 MHz. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 116 When the enter button is pressed, the new values are saved, and the text will appear in BLACK. It is necessary to press the enter button to save the new values in the transmitter. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 117 Select the guard interval of the transmitted signal. The available options are 1/8, 1/16 and 1/32. • Bandwidth (eligible parameter): Enter the transmitted signal bandwidth. The available options are 1.7, 5, 6, 7 and 8 MHz. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 118 When the enter button is pressed, the new values are saved, and the text will appear in BLACK. It is necessary to press the enter button to save the new values in the transmitter. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 119 Figure 5.12: Web Server RF screen (DVB-S2) • Frequency (editable parameter): Introduce the frequency at which the signal is being transmitted. • Output Mode (eligible parameter): Specify the output mode. The available options are:  Low Carrier UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 120 The spectrum options are inverted and normal. • 10 MHz (eligible parameter): 10 MHz reference oscillator mode ON or OFF. This feature provides a reference signal to the satellite up-converter (BVC) when ON. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 121 When the enter button is pressed, the new values are saved, and the text will appear in BLACK. It is necessary to press the enter button to save the new values in the transmitter. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 122 1/2, 2/3, 3/4, 5/6, 7/8. • Symbol Rate (editable parameter): In this field the symbol rate of the transmitted signal can be selected. The valid range is from 2 to 45Mbaud/s. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 123 When the enter button is pressed, the new values are saved, and the text will appear in BLACK. It is necessary to press the enter button to keep and save the new values on the screen. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...

  • Page 124: Unit

    6.2.3 UNIT UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 125 Figure 5.14: Web Server UNIT screen UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 126 • No Audio 2 Input: Audio source is not connected. • No GPS: GPS source is not connected. • No RS232: RS232 data source is not connected. • No KLV • PA No Forward • PA Rev High UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 127 In this field, the user’s password is introduced. It can be set an own password which is a list of 8 digits. Then, to save the introduced value, press Enter button. There is the option to restore the default user password (00000000). UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...

  • Page 128: Web Page Setup Notes

    BLACK. It is necessary to press the enter button to save the new values in the transmitter. 6.2.3.22 Firmware Update In this field, the user can upload the firmware .SVP file and upgrade the firmware remotely. 6.3 Web Page Setup Notes For the data to be refreshed correctly, you may need to change some settings on your browser.
  • Page 129 Open a new tab, in the address bar enter about:config. In the Filter box, enter disk. Set the value for 'browser.cache.disk.enable' to false (double click to change the setting). Close the about:config tab. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...

  • Page 130: Chapter 6: Equipment Installation

    6.2 Connections Every connection of the UDT-4K camera transmitter is on the rear panel, except for the RF antenna connections that are on the front panel. All the Lemo part numbers and pinout refer to the connector of the UDT-4K.
  • Page 131 RF Output RTC-03 Power DC Remote RF Output HDMI 1-2 ASI Input Input SDI Input GPS RF L-Band RF ASI Output output output Figure 8.2: Rear and front view of the HDT-02 UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...

  • Page 132: Power Supply

    LED of the equipment blinks GREEN and RED showing an alarm. The power source of the UDT-4K should be the same as the one used for the PA. Both should be turned on and off simultaneously. They must use the same breaker.

  • Page 133: Pa Remote Connector

    6.2.2 PA REMOTE Connector The UDT-4K Transmitter incorporates an input to control remotely the PA-10 Power Amplifier. PA REMOTE Connector technical features Item Features Connector Label PA REMOTE Connector type 7 pin Lemo 0B Part number (UDT-4K) ECG.0B.307.CLV Part number (cable connector) FGG.0B.307.CLAZ...

  • Page 134: Buc Connection Pinout

    If the transmitter is configured to be used with PA Power Amplifiers, the communication and control is made through a RS232 port. The pinout of the cable which interconnects the UDT-4K Transmitter and PA Power Amplifier is indicated in the following table:...

  • Page 135: Rtc-Data

    Pinout of the cable connector (Watched from the soldering side) Description RTC - (RS-485 (-)) DATA TX (RS-232) RTC + (RS-485(+)) +V DC DATA RX (RS-232) Table 9.8: RTC-DATA cable connector pinout UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...

  • Page 136: Intercom-Tally

    Part number (Cable connector) FGG.0B.307.CLAZ Table 9.9: INTERCOM-TALLY connection technical Description INTERCOM MICROPHONE IN INTERCOM SPEAKER INTERCOM PTT +3,3V FOR TALLY. TALLY GREEN RETURN TALLY RED RETURN Table 9.10: INTERCOM-TALLY cable connector pinout UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...

  • Page 137: Video Inputs

    ASI IN connection technical features Item Features Connector label ASI IN Connector type Mini BNC Impedance 75 Ω Standard EN50083-9 Maximum Bitrate 216 Mbps Table 9.12: ASI Transport Stream input connection features UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...

  • Page 138: Audio Inputs

    6.2.6 Audio inputs The UDT-4K Transmitter has four possible Analogue Audio inputs: • 2 Audio inputs to insert 2 stereo or 4 mono analogue (mic phantom, mic dynamic and line) signals where connections are made using two 5 pin Lemo 0B connectors on equipment’s rear panel.

  • Page 139: Remote

    Through the USB connection, it is possible to update the firmware of the transmitter directly from an external USB device. USB connection technical features Item Features Connector Label Connector type Type A Table 9.16: USB input connection technical features UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 140 6.2.9 RF output The antenna or Power Amplifier is directly connected to the female N-type or SMA-type connectors on the front panel of the UDT-4K camera transmitter. There are up to six connectors available, each one for a different frequency band (type N for the 1-2.8 GHz band, type SMA for 3-4 GHz band, type N for...
  • Page 141 50 Ω Item Features Connector label REMOTE Connector type SMA female Impedance 50 Ω Item Features Connector label INTERCOM Connector type SMA female Impedance 50 Ω Table 9.17: RF output connections characteristics UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 142 ASI output signal type uses 75Ω BNC connector. This connector is placed on transmitter’s rear panel. It is important that 75 Ω connectors are used. This is because the female output connector of the UDT-4K unit could be damaged because of an impedance mismatch. ASI connection technical features...
  • Page 143 6.3 Mechanical Accessories In this section, different short of accessories of the UDT-4K HEVC Transmitter are shown. The accessories required by the customer must be defined when the transmitter is ordered. 6.3.1 Battery Fastening This item allows the connection to the battery (V type or Anton Bauer) to the transmitter’s case (optional).
  • Page 144 (up/down), the level of the RF and the profile selected. This equipment is especially useful in applications where the UDT-4K or HDT- 04 Transmitter is mounted away from the operator and the parameters can’t be modified directly from the front panel.
  • Page 145 Audio 1 and Audio 2 inputs, the video delay and the codification profile. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 146 Remote Control and the connectors needed. Figure 7.2: RTC-03 rear view 7.2.2.1 HDT Transmitter Connector This connector is used for the communication between the UDT-4K or HDT- 04 Transmitter and the RTC-03 Remote Control. HDT Transmitter connection technical features...
  • Page 147 Power Return (-) Not Used Not Used Table 10.4: Connector pinout for Type B actuator To automatically retract the actuator by the altimeter radar alarm, short pins 7 and 8 of this connector. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 148 To automatically retract the actuator by the altimeter radar alarm, short pins 7 and 8 of this connector. 7.2.2.3 Alarms The RTC-03 Remote Control shows transmitter alarms. When there is an alarm there will be a point in the profile screen. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 149 7.3 RS-485 Operation 7.3.1 PC Control Operation The UDT-4K can be controlled remotely from a computer via RS-485 commands using the RTC connector. The port must be configured as; 8 bits, 1 stop bit, no parity and 9600bps. In the transmitter you need to select the RTC-03 remote control.
  • Page 150 23-0 => not interesting CHK must be set to the XOR of all the previous bytes, excluding the first byte with value 0x7D. The transmitter will answer a message with the following format: UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 151 An important note to keep in mind. As the communication is half- duplex, and the master is the transmitter, to send a command to the transmitter you must wait to receive a message first, wait 20 ms, and send only one message. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 152 Chapter 8: Mechanical Dimensions In this chapter, the mechanical drawings of the units described in this manual are included. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 153 8.1 UDT-4K Transmitter UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 154 8.2 PA Standard and PA Ultralinear Power Amplifiers UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 155 8.3 PA Standard and PA Ultralinear Power Amplifiers Installation ISO 14581 M4 (10 Units) UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 156 8.4 RTC-03 Remote Control UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 157 8.5 CLTX-01 Support UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 158 8.6 CLTX-02 Support Installation ISO 14581 M4 (8 Units) ISO 14581 M3x8 (6 Units) UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 159 8.7 GPS-01 Antenna & Receiver UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 160  (*) connection Table 10.1. Maintenance Schedule table (*) If the UDT-4K installation is constantly changed, prior to each use make sure the RF output is loaded. 9.2 Maintenance Procedures Quarterly, the following inspections should be done: • Inspect antenna installation to ensure all components are secure and in good conditions.
  • Page 161 Before any Product is returned for repair and / or adjustment, authorization from SVP Broadcast Microwave for the return and instructions as to how and where the Product should be shipped must be obtained. The Product type, serial numbers, and a full description of the circumstances giving rise to the warranty claim should be included.
  • Page 162 Product. By returning a Product, the owner grants SVP Broadcast Microwave permission to open and inspect the returned Product to determine the cause of failure, and SVP Broadcast Microwave’s determination with regard hitherto shall be final.
  • Page 163 The equipment has a two-year warranty that covers any failure or manufacturing defect, providing it is not handled by anyone other than SVP Broadcast Microwave personnel and the warranty seal has not been broken. UDT-4K UHD HEVC Digital Camera Transmitter...
  • Page 164 Low intermodulation and high reliability make these Amplifiers especially interesting for broadcast and airborne applications. This PA can be controlled from the UDT-4K remotely thanks to the RS-232 communication. An excellent design, mechanical and electronic assembly make the PA a robust and reliable solution.
  • Page 165 Operating temperature range -20ºC to +50ºC Mechanical dimensions 251x 127.5 x 94.6 mm Weight 2.5 kg PA-15-2024U PA-10-2324U PA-10-3336U Arinc front Hook versions: PA-15-2024UH PA-10-2324UH PA-10-3336UH Table A.1 PA Ultralinear Main Characteristics UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 166 80 W to 125 W Operating temperature range -20ºC to +50ºC Mechanical dimensions 251x 127.5 x 94.6 mm Weight 2.5 kg PA-10-1315 PA-10-1722 PA-10-4450 PA-10-5053 PA-5-6470 PA-2-6873 Table A.2 PA Standard Main Characteristics UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 167 A.2.2 Block Diagram This section provides the block diagram of the PA Ultralinear and PA Standard Power Amplifiers showing the internal performance of the device. Figure A.2: PA Ultralinear Block Diagram UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 168 Figure A.3: PA Standard Block Diagram UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 169 MIL-DTL-26842 Series 2 MS3112E Connector Part number (PA connector) SOURIAU 851-02E123P50 Connector Part number (cable SOURIAU 851-06EC123S50 connector) Input voltage range 9-36 V. Consumption Max 125 W Table A.3: Power supply connection technical features UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 170 The PA Power Amplifiers incorporate an input to be controlled remotely by a UDT-4K Transmitter. This Remote Control allows switch ON/OFF, send the Power Direct, Power Reverse and Alarms to the UDT-4K Transmitter and enable the configuration of the output power. Remote Control connection technical features...
  • Page 171 Pin 5 Pin 5 Pin 7 Pin 2 Table A.6: Remote Control Cable Pinout A.2.3.2.3 RF input Here, the RF signal which comes from the UDT-4K Transmitter is connected. RF IN connection technical features Item Features Connector label RF IN (TX)
  • Page 172 • Remote Control cable (6 pin MIL-DTL-38999 to 7 pin Lemo) • Antenna The UDT-4K Transmitter is powered throughout the Lemo 1B connector and the Power Amplifier is powered throughout the SOURIAU connector. The input level is indicated in each connector's label.
  • Page 173 A.3.1 PA Configuration The following menu screen and figures show the different steps that must be followed when the connection between the UDT-4K transmitter and the PA amplifier is established. First, connect the two equipment as it is shown below: Figure A.6: Connection between the UDT-4K and the PA...
  • Page 174 Once the connection is established, go to the main menu of the UDT-4K Transmitter pressing the cross button and select the RF option: Figure A.7: Main Menu Go to DVB-T or DVB-T2 option and press the OK button to configure the parameters related to the PA amplifier.
  • Page 175 • P: The level of the transmitted power measured in dBm. • R: The reverse power percentage. If the RF button is OFF, these parameters blink on the main screen. To transmit, press the RF button. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 176 • When the LED remains switched off for long, but sometimes blinks. It means that the amplifier has been switched off remotely by the UDT-4K or by the RTC-03 Remote Control. Anyway, when the POWER DC LED is on, the amplifier is powered.
  • Page 177 This antenna has 3dBi gain and the operating frequency range is from 1.3 to 7.5 GHz. It is made of brass, stainless steel and Teflon. The figure below shows the AVF flexible antenna: Figure B.1: AVF flexible antenna UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 178 AVF-303 (3.0 to 3.7 GHz) AVF-403 (4.4 to 5.9 GHz) AVF-603 (6.0 to 7.5 GHz) Table C.1: AVF flexible antenna technical features The figure below shows antenna adaptation: Figure B.2: S11 parameter measurement UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 179 Figure B.3: Horizontal and Vertical Radiation patterns UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 180 • Can operate in 6, 7 or 8MHz channel bandwidths. Using different combinations of the above parameters a DVB-T network can be designed to match the requirements of the network operator, finding the right balance between robustness and capacity. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 181 With this rotation, dependence between the I and Q components of the signal is achieved. This means that with only one component (the I or the Q) it is possible to know exactly the symbol to which it belongs. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 182 24 Mbit/s 45.5 Mbit/s (using 8 MHz) Max. Data rate (@20 dB 31.7 Mbit/s (using 8 MHz) C/N) Required C/N ratio (@24 16.7 dB 10.8 dB Mbit/s) Table E.1: DVB-T vs DVB-T2 UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 183 This operation is called rate adaptation. DVB-S uses QPSK modulation and concatenated error protection based on a convolutional Viterbi code and a shortened Reed Solomon code. Figure C.3: Future Extension Frames UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 184 The FEC system is based on concatenation of BCH (Bose, Chaudhuri – Hocquengham) with LDPC (Low density Parity Check) inner coding. Figure C.5: DVB-S2 FEC UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 185 ACM allows operating satellite links with almost no margin, since the system adapts automatically to fading or interference conditions. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 186 • Reduce the phase noise influence. Phase noise is created by the frequency components around the main carrier frequency. This noise contains components at many frequencies with randomly changing phase. • Pilots are used to increase the reliability and the continuous receiver synchronization. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 187 Next there are shown a series of comparisons between DVB-S and DVB-S2 standards. DVB-S vs DVB-S2 Performance Figure C.8: DVB-S vs DVB-S2 Performance The figure above shows how the DVB-S2 standard is really close to the Shannon limit. UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 188 QPSK – 8PSK – 16APSK – 32APSK 35% and 25% Roll-off carrier 20% Roll off carrier Consumer LNB’s work in QPSK only Pilot tones for extra synch in 8PSK Figure C.9: Main differences between DVB-S and DVB-S2 UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 189 European Telecommunications Standards Institute Forward Error Correction Fast Fourier transform Global Positioning System High Definition HDMI High-Definition Multimedia Interface UHDReceiver UHDTransmitter Intermediate Frequency Interval Guard Internet Protocol order Intermodulation Product Liquid Crystal Display UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 190 Quadrature Amplitude Modulation QPSK Quadrature Phase-Shift Keying Radio Frequency Remote Control Standard Delay Serial Digital Interface Thin-Film Transistor Transport Stream User Datagram Protocol Ultra High Frequency Universal Serial Bus VSWR Voltage Standing Wave Ratio UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 191 Notes UDT-4K UHD HEVC Digital Camera Transmitter MANUAL V0...
  • Page 192 Final note SVP Broadcast Microwave S.L. is constantly striving to improve all of its products. Therefore, we ask you to understand that modifications may occur in designs, equipment and technology. Consequently, we do not accept responsibility for any variations of information, illustrations or descriptions contained in this manual.
  • Page 193 SVP Broadcast Microwave reserves the right to make changes to this manual and to the equipment without prior notice. C/Zubiaurre 7 bajo 48215 Iurreta Vizcaya – Spain Tel: (+34) 94620 3722 info@svpbm.com www.svpbm.com...

Table of Contents
