Konsmetal WBNE User Manual

Electronic deposite strong safe
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WBNE and is the answer not in the manual?

Questions and answers

Related Manuals for Konsmetal WBNE

Summary of Contents for Konsmetal WBNE

  • Page 2: Table Of Contents

    INSTALLATION AND STARTING UP............3 DEPOSIT STRONG SAFE FEATURES ............4 DEPOSIT STRONG SAFE ELEMENTS LAYOUT: ........5 OPERATION ....................... 6 ..........7 PENING THE LECTRONIC EPOSIT TRONG ......................7 OGGING IN ................7 EPOSITING THE PACKAGES Package code scanning - optional ..............8 Entering the package code using the keypad ..........

  • Page 3: Installation And Starting Up

    Directions for Use: Be careful when closing and opening the door and the drum. Open and close the drum using the handle. Failure to comply with the above rules may result in an injury, in particular, your fingers may get caught between the moving elements. If there are any doubts on the functioning of the device, immediately contact the service center.

  • Page 4: Deposit Strong Safe Features

    Electronic Deposit Strong Safe with a drum is used to deposit the money in collective packaging (wallets, envelopes). Usually the deposit strong safe is built into the outer wall of the bank and is an integral part of the safe. The deposit strong safe can only be used by authorized persons who have an electronic identification card.

  • Page 5: Deposit Strong Safe Elements Layout

    Deposit Strong Safe elements layout: Card reader Emergency opening lock Fig. 1. Deposit Strong Safe view Electronics cassette Deposit hole Drum lever Fig. 2. Deposit Strong Safe view after opening front door...

  • Page 6: Operation

    Lock Bar code scanner Display Camera Printer Keypad Card reader Fig. 3. Electronics cassette Operation The daily use and programming of the deposit strong safe is done via 12 button keypad. Keys are used to enter data and navigate through the menu options. Functions of the keys: 0-9 - Entering the values and selecting the menu options Approval, save,...

  • Page 7: Opening The Electronic Deposit Strong Safe

    Opening the Electronic Deposit Strong Safe Applies to devices equipped with shielding doors of the drop-in drum. Place the card on the reader in order to open it (Fig. 1). The door will automatically open (if the door does not open, press it lightly for a while). If you need to re-use the card wait about 5 seconds.

  • Page 8: Package Code Scanning - Optional

    Package code scanning - optional Bring the barcode (printed on the package) closer to the reader, at a distance of not less than 20 cm, for a brief moment in such a way that the + symbol, displayed by the scanner, was located near the center of the bar code. The barcode read-out is signaled by a short beep.
  • Page 9 Insert the envelope and close the drum by pulling the levers down until it stops. Inserting more than one envelope at the same time will make the device registers only one deposit. Each correct drop-in (inserting the envelope to the deposit part) is signalled by a message.

  • Page 10: Deposits Removal

    Deposits removal knob locks Fig. 3. Deposit cabinet view Before opening the deposit cabinet you have to log in and then, by pressing button 2, select option 2. Clear the packages and confirm the selection by pressing #. The deposit strong safe will print a list of deposited packages. Pressing * instead of # will cancel the procedure of deposits removal.

  • Page 11: Opening The Deposit Cabinet

    Opening the deposit cabinet Open the electronic lock according to the instructions supplied with the product. Turn door mechanism is unlocked. Pull the door towards you and the deposit strong safe opens. Closing the deposit cabinet Grab the knob (bolts have to be pulled in) to close the door by pushing it to the safe, turn the knob clockwise until it stops, the door is locked.

  • Page 12: Administrator Menu

    Managing the users of the deposit strong safe and changing the parameters of LAN connection is possible after logging in as the Administrator. Default login: 54321, PIN: 01237654. Once logged in you have direct access to the settings menu. Numeric keys are used to indicate the menu options. Choosing the options or Administrator Menu Exit the Administrator Menu Changing the Administrator PIN...
  • Page 13 1. Changing the PIN code. After choosing option 1 the message will be displayed. please enter the new PIN code. (from 4 to 6 digits) # - confirmation of the data entered - deleting the last character or cancelling the operation If the correct PIN is entered it will be necessary to repeat the code and to approve it by pressing #.

  • Page 14: User Management

    2. User management Access to the deposit strong safe is possible only for users who have been programmed into the device. User authentication can be done by: - a proximity card without the code - proximity card and the PIN code - user login and the PIN code.
  • Page 15 Adding a user After There are three types of users: - Standard - a person who deposits packages in the deposit strong safe. - Escorting guard - a person who removes the packages form the deposit strong safe - Administrator - a person who manages the deposit strong safe access and configuration parameters The user type selection is done by pressing the corresponding numeric keys.
  • Page 16 If the correct PIN is entered it will be necessary to repeat the code. The user login is displayed after entering the PIN code. For a printer version of the deposit strong safe, a confirmation of adding the user, containing the username and PIN code, will be printed.
  • Page 17 Assigning the PIN code If there is a need to assign a PIN code to a user who has the card only, select Enter the login of a user who is to receive a PIN code. # - confirmation of the selection. * - deleting the last character or cancelling the operation Once the code is correctly entered, the PIN assignment procedure described on p.

  • Page 18: Setting The Time And The Date

    3. Setting the time and the date Return to the main menu Setting the date Setting the time After entering the selected option, enter the date/time using the numeric keys in the displayed order. Confirm the data entered by pressing the # key. Deleting the last character or cancelling the operation by pressing the * key.

  • Page 19: Setting The Lan Network (Ethernet) Parameters

    4. Setting the LAN network (Ethernet) parameters The following parameters of the LAN network can be set in the deposit strong safe: - IP address - subnet mask - default gateway - network port - NTP server address - enabling the DHCP client Before setting the above parameters, please contact a person responsible for the operation of the network to which the deposit strong safe is to be connected.
  • Page 20 Disabling/enabling the DHCP Enabling communication protocol that allows to set the Ethernet port parameters automatically. 0 - enabling the DHCP 1 - disabling the DHCP # - confirmation of the selection. * - cancelling the operation Setting the IP address, subnet mask and gateway Setting the parameters of the subnet mask and gateway is done under the same rules described below.
  • Page 21 Setting the TCP port number Using the numeric keys, enter the value of the parameter agreed with your network administrator. Enter five-digit values, place additional zeros if necessary. # - confirmation of the selection. - deleting the last character or cancelling the operation Setting the communication with the time server (NTP) The deposit strong safe provides the possibility to co-work with the time server.

  • Page 22: Changing The User Interface Language

    5. Changing the user interface language There are two standard languages programmed into the deposit strong safe: Polish and English. To change the language of the displayed messages select option 5 from the main menu and confirm by pressing #. The device can be programmed with other languages.

  • Page 23: Resetting The Deposit Strong Safe Settings

    7. Resetting the deposit strong safe settings The option that allows to completely cancel all data stored by the deposit strong safe and to restore the factory settings. This option should be used only in exceptional cases and only in an agreement with the service.

  • Page 24: Replacing The Paper In The Printer

    Replacing the paper in the printer Applies to the device equipped with the printer. Replacing the paper in the printer is possible after logging to the deposit strong safe and opening the electronics cassette. In order to open the electronics cassette open the deposit strong safe door, open the lock (Fig.

  • Page 25: Removing The Paper Scraps From The Printer

    Removing the paper scraps from the printer. Fig. 5 Every time you replace the paper it is necessary to remove the scraps of paper from the printer mechanism - see item (a) in the above figure. Close the mechanism cover after cleaning. Printer paper specification Paper type Paper width...
