QSI Quantum Revolution-A User's Operation Manual page 26

Revolution-A: Common CV's to Modify Light Outputs:
Front Headlight (Port 1)
CV 55.70.0 Initial State
0 = OFF
1 = Automatic Control
2 = ON
3 = Dim
CV 55.70.1 Automatic
Configuration
86 = Bright in FWD, Dim in
NFF, DIM in REV, Dim in NFR
2 = Bright in FWD, OFF
in NFF, OFF in REV, OFF
in NFR
Rear Headlight (Port 2)
CV 55.73.0 Initial State
0 = OFF
1 = Automatic Control
2 = ON
3 = Dim
CV 55.73.1 Automatic
Configuration
101 = Bright in REV, Dim in
NFR, Dim, FWD, Dim in NFF
32 = Bright in REV, OFF in
NFR, OFF in FWD, OFF in NFF
Front Ditch Lights
(Port 3=Left) (Port 4=Right)
Both work together.
CV 55.84.0 Initial State
1 = Automatic Control
2 = ON
3 = Dim
CV 55.84.1 Automatic FWD
0 = OFF
1 = Dim
2 = Bright
3 = Strobe
4 = OFF (Strobe with horn)
5 = Dim (Strobe with horn)
6 = Bright (Strobe with horn)
CV 55.84.2 Neutral From FWD
0 = OFF
1 = Dim
2 = Bright
3 = Strobe
4 = OFF (Strobe with horn)
5 = Dim (Strobe with horn)
6 = Bright (Strobe with horn)
CV 55.84.3 Automatic REV
0 = OFF
1 = Dim
2 = Bright
3 = Strobe
4 = OFF (Strobe with horn)
5 = Dim (Strobe with horn)
6 = Bright (Strobe with horn
CV 55.84.4 Neutral From REV
0 = OFF
1 = Dim
2 = Bright
3 = Strobe
4 = OFF (Strobe with horn)
CV 55.76.0 Initial State
1 = Automatic Control
2 = ON
3 = Dim
CV 55.76.1 Automatic FWD
0 = OFF
1 = Dim
2 = Bright
3 = Strobe
CV 55.76.2 Automatic Neutral
From FWD
0 = OFF
1 = Dim
2 = Bright
3 = Strobe
5 = Dim (Strobe with horn)
6 = Bright (Strobe with horn)
Mars Light (Port 5)
CV 55.76.3 Automatic REV
0 = OFF
1 = Dim
2 = Bright
3 = Strobe
CV 55.76.4 Automatic
Neutral From REV
0 = OFF
1 = Dim
2 = Bright
3 = Strobe
Overhead Beacon (Port 6)
Works with F12 button
CV 55.92.0 Initial State
0 = OFF
2 = Blinking Light
18 = Rotating Beacon
34 = Strobe Light
