Page Control Unit FC1 Operation Instruction Manual Thank you for purchasing this product. In this manual, we have shown the important notice in order for you to use the device just and the method of handling this system. In addition to you read this manual well before the utilization, understanding well, and use.
Page Table of contents 1. Safety instructions..............3 2. Installation................5 2.2. Installation of control unit ............6 2.3. Installation of detector............7 2.4. Wiring................8 3. Starting the system..............9 3.2. Control unit..............10 3.3. Dimensions............... 16 3.4. Electric specifications............17 3.5.
Page 1 1 1 1 . Safety instructions Safety instructions Safety instructions Safety instructions ・ Before the using, read this chapter and use correctly. ・ The contents which it occurs when you handle erroneously are divided in two of “warning” and “caution”.
Page 4
Page ・ A term of a guarantee and a guarantee range 【A term of a guarantee】 In regard to the guarantee of this product, the designated payment of the order main thing after the paying 1 years you guarantee first only the breakdown which occurs in the normal busy condition which you follow the instruction manual.
Control unit communicates with the detector, Control unit controls the indicating LED and 7seg. LED and the buzzer and signal contact according to the state of the detector and itself. FC1-DY:DIN rail mount type FC1-HY:Surface mount type ② Communication line :...
2.2.1. FC1-DY FC1-DY is DIN rail mount type. Loosen the screw of the metallic parts for the installation of 2 places which are on the side of control unit itself. And put the control unit to the fixed 35mm width DIN rail.
Page 2.2.3. Installation places The control unit must be installed on conductive place where is grounded. And must be used, When it covers around control unit, electronic buzzer sound hears and becomes difficult to take. In addition, also heat dissipation becomes bad, becomes cause of breakdown. Because of this, usually at least please guarantee the space of width above 10mm substance control unit top and around the guaranty of the passage of air current for heat dissipation as a purpose.
Page 2.4. Wiring ・Please do the wiring after the external power supply off. It may get an electric shock or the control unit may break down. ! ! ! ! Warning ・Please use the terminal cover for the control unit when the unit is energized, after do the wiring.
Page 3 3 3 3 . Starting the system Starting the system Starting the system Starting the system 3.1.1. Setting of control unit Please verify whether the number of detectors which it is connected with the DET. NUMBERS switch which is on the panel front is same. When setting is different, trouble indication is lighting.
Page 3.2. Control unit 3.2.1. Name and function of each section ① Operation panel a. POWER : Power supply switch (White) Supply of power supply is started, or the each operation of POWER switch turns on/off the system. After turning off the system, until it turns on power supply again, Caution !...
Page 11
Page d. DET. NUMBERS×1 : Detector numbers switch (X1) This is the switch whereby to set the connectable detector numbers by ten digits. (X1) Since the setting of this switch is recognized only at the time of Caution ! ! ! ! turning the power on, the power is to be off in the event of changing the setting.
Page 12
Page i. 7 Segment LED (Red) Address of the detector where the alarm occurs is indicated. When the alarm occurs with the plural detectors, the scroll it indicates in the order where the alarm generates the address which is in the midst of alarm occurring 2 seconds. First address indicates the decimal point in simultaneously When trouble occurs in alarm state, for alarm priority indication, Caution...
Page 13
Page ② Terminal section Conformity wire 18-26AWG Screw M3×6L Tightening torque 0.5 N・m Please install the bundled terminal cover in order to prevent accident ! ! ! ! Warning such as electric shock. Use the proper screw driver bit for screw size. Tighten inside of Caution !...
Page 14
Page d. ALARM(COM,NO,NC) At the time of alarm state and power supply stopping/deciding, the alarm contact signal operates. However, at the time of zone alarm occurrence, as for the alarm contact signal it does not operate. Alarm contact Between Between COM and NO COM and NC State of control unit...
Page 15
Page ③ About Trouble indication a. DETECTOR It lights up when sensitivity revision over or inside the detector, trouble occurs in the detector. (Refer to “6. Procedures/steps to be taken in the event of trouble occurrence”) In addition, address of the detector where trouble occurs is indicated in 7seg LED. b....
Page 3.4. Electric specifications Name of item : Control unit model : FC1-DY : FC1-HY Rating : DC24V 0.15A Range of working : DC24V ±10% voltage ・Please install the power supply only for the control unit as ! ! ! ! Warning much as possible.
Page 18
Page : Power off contact output State Contact Power on Open Power off Close Capacity of contact DC30V 1A AC125V 0.3A Resistance loading (11) S o u n d o f a l e r t : Electronic buzzer. Alarm sound : Continual sound trouble sound : Intermittent sound(continual sound priority) (12)
! ! ! ! Warning occur. It becomes cause of breakdown such that it stops operating normally. 3.6. Mechanical specifications External form : W125×D104×H40(FC1-DY) : W121×D104×H40(FC1-HY) Main material : SPCC t1.0 black paint Mass :...
Page 4 4 4 4 . Procedures/steps to be taken in the event of alarm occurrence Procedures/steps to be taken in the event of alarm occurrence Procedures/steps to be taken in the event of alarm occurrence Procedures/steps to be taken in the event of alarm occurrence When this system inspects abnormality, the following warning is output from control unit.
Page 5 5 5 5 . Indication of the time of trouble Indication of the time of trouble Indication of the time of trouble Indication of the time of trouble When this system inspects trouble, the following warning is output from control unit. (1) The trouble LED which responds to the contents of trouble lights up.
Doing the above-mentioned coping, case problem is not solved, please Caution ! ! ! ! inform to the nearby Fenwal Controls of Japan Co., Ltd. The time of trouble occurrence, when you redo wiring or exchanging the detector, Do it after turning off power.
La La Ca Ca La La Ca Ca La La Ca Ca Control unit Repeater Smoke Detector Heat Detector FC1-* F11-*、 F21-* SRU-*C,*Z SRU-3SH-ESD 7.1. Connectable detector The following detector is connection possible in control unit. As for details please inquire the function which we would like you to use to our company Sales Div.
8 8 8 8 . Serial communication facility Serial communication facility Serial communication facility Serial communication facility This control unit has a serial communication function. Please inquire about this facility to the Fenwal Controls of Japan Co., Ltd. Tokyo headquarters. ES0911 730110 K0...
Page 9 9 9 9 . Maintenance and Maintenance and Inspection Inspection Maintenance and Maintenance and Inspection Inspection 9.1. Daily Inspection The items that must be inspected daily are listed in bellow Table. № Item Object Inspection Method Judgment Criteria Remedy Installation Common...
Page 9.2. Periodically Inspection The items that must be inspected one or two times every 6 months to 1 year are listed below. When the equipment is moved or modified, or layout of the wiring is changed, also perform this inspection. №...
Page 27
Page № Item Object Inspection Method Judgment Criteria Remedy Behavior Normal Power LED Check The LED must be Please refer to Supervision Control visually. ON.(Green) section 6. unit The rest of Check The LED must be LED except the visually. Off.
Page 9.3. Functional Inspection This system should not confirm operation actually applying smoke and heat, because each equipment confirms the operation autonomous. The detector connected with the control unit and the control unit communicates regularly. Therefore, when trouble state of the control unit, the communication with the detector stagnates and alarm and trouble state in the detector, the control unit is automatically displayed in it.
Page 29
Page Confirm this system returns to Check the Power LED The LED must be the state of normal supervision. display of the control ON.(Green) control unit, unit The rest of LED The LED must be Off. over two except the minutes.
11 11. Support 11 11 Support Support Support Please inquire about this control unit to the Fenwal Controls of Japan Co., Ltd. Tokyo headquarters. Fenwal Controls of Japan Co., Ltd. 1-5-10 Iidabashi Chiyoda Tokyo, 102-0072 Japan Tokyo headquarters : +81-3-3237-3565...
