Hearth & Home PH-LINEAR COSMO-IFT-B Series Installation Instructions Manual

Passive heat kit

Advertisement

Models: COSMO-IFT-B Series, RAVE-IFT-B Series, JADE-B, DVLINEAR36, B41IL-AU Series
Leave this manual with party responsible for use
and operation.
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during instal-
lation. Sheet metal edges are sharp.
CAUTION! Do not install damaged components.
If any parts are missing or damaged, contact your dealer before
starting installation. DO NOT install a damaged kit.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and must be installed for
the protection of children and other at-risk
individuals.

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Kit Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Good Faith TV Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Discharge (PH-LINEAR). . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Discharge (PH-LINEAR). . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Discharge (PH-LINEAR). . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Finishing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Mantel Projections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Management Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Passive Heat Kit
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
Hearth & Home Technologies • PH-LINEAR Instructions • 2616-970 Rev. i • 10/21
PH-LINEAR
Installation Instructions

Introduction

The Passive Heat (PH-LINEAR) Heat Management Sys-
tem conveys warm air from the fireplace into the same room
through either one front discharge slot, two side discharge
heat registers or an open top discharge.
Installation of the Passive Heat kit must be done in con-
junction with the appliance installation. Installation of this
kit MUST be performed by a qualified service technician.
WARNING! Risk of Fire! DO NOT install the Passive
Heat (PH-LINEAR) Heat Management System with mod-
els that are not approved. Overheating will occur.
The Passive Heat Trim Kit is also available for installation
with the Front Discharge Passive Heat systems and must
be purchased separately. Contact your dealer to order
the appropriate kit: PH-FRTTRIM-32, PH-FRTTRIM-36
or PH-FRTTRIM-48.
The Passive Heat Trim kit is required with the side dis-
charge Passive Heat system and must be purchased sepa-
rately. Contact your dealer to order the PH-SIDETRIM kit.
Follow instructions included with the trim kit to complete
installation of the Passive Heat system.
The Passive Heat kit is tested and safe when installed in
accordance with this installation manual. It is your respon-
sibility to read all instructions before starting installation
and to follow these instructions carefully during installation.
The Passive Heat kit is carefully engineered and must
be installed only as specified. If you modify it or any of
its components you will void the warranty, and you may
possibly cause a fire hazard. Installation must be done
according to applicable local, state, provincial, and/or
national codes.

Preparation

Plan the location of the appliance.
Determine whether front, open top or side discharge is
to be installed and follow instructions for the appropriate
application.
CAUTION! Risk of Burns!
• The fireplace should be turned off and cooled before
kit is installed.
• Shut off gas supply.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PH-LINEAR COSMO-IFT-B Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hearth & Home PH-LINEAR COSMO-IFT-B Series

  • Page 1: Table Of Contents

    PH-LINEAR Models: COSMO-IFT-B Series, RAVE-IFT-B Series, JADE-B, DVLINEAR36, B41IL-AU Series Passive Heat Kit Installation Instructions Introduction Leave this manual with party responsible for use The Passive Heat (PH-LINEAR) Heat Management Sys- and operation. tem conveys warm air from the fireplace into the same room through either one front discharge slot, two side discharge CAUTION! Risk of Cuts, Abrasions or Flying Debris.
  • Page 2: Kit Contents

    Power Vent Option If an optional power vent will be installed in conjunction with the Passive Heat Kit (PH-LINEAR), Hearth & Home Technologies recommends the PVLP-SLP power vent option. If the application does not allow for the PVLP-SLP to be used, the PVI-SLP-B may be used. The PVI-SLP-B must be mounted outside the chase due to the higher noise level created.
  • Page 3: Clearances

    Clearances Clearance - Sprinkler to Passive Heat Figure 2 references the clearances that must be adhered WARNING! Risk of Fire! Maintain clearances to to when installing a sprinkler head near a passive heat combustibles as specified. discharge opening. Ensure all clearances are maintained. •...
  • Page 4: Good Faith Tv Guidelines

    Good Faith TV Guidelines Good Faith Guidelines for TV Installations Above a Fireplace with Passive Heat Option This diagram specific to these models: COSMO32-IFT-B RAVE32-IFT-B JADE32IN-B COSMO36-IFT-B RAVE36-IFT-B JADE42IN-B COSMO42-IFT-B RAVE42-IFT-B JADE42IL-B DVLINEAR36 B41L-AU WARNING! Risk of Fire! Mesh screen required on bottom of discharge opening when discharge opening is greater than 3 in.
  • Page 5: Framing Dimensions- Passive Heat Front Discharge (Ph-Linear)

    Framing Dimensions- Passive Heat Front Discharge (PH-LINEAR) Front Discharge: Air conveyed into the room through one front discharge slot. CHASE DETAIL 1-1/2 IN. (2 X 4 FRAMING) (90 x 35 mm for AU) 0-3 IN. (0-76 mm) ROOM CEILING 2 IN. MIN. CHASE CEILING REQUIRED (51 mm) WITHIN 3 IN.
  • Page 6: Framing Dimensions - Passive Heat Side Discharge (Ph-Linear)

    Framing Dimensions - Passive Heat Side Discharge (PH-LINEAR) Side Discharge: Air conveyed into the room through two discharge registers, one on each side of appliance. CHASE DETAIL WARNING! Risk of Fire! DO NOT place combustible objects or combustible materials in non-combustible 1-1/2 IN.
  • Page 7: Framing Dimensions - Passive Heat Open Top Discharge (Ph-Linear)

    Framing Dimensions - Passive Heat Open Top Discharge (PH-LINEAR) Open Top Discharge: Both sides and the top are open allowing air to be conveyed into the room. WARNING! Risk of Fire! Mesh screen required on bottom of discharge opening when discharge opening is greater than 3 in, (76 mm).
  • Page 8: Adapter Installation - Front, Side And Open Top Discharge

    Adapter Installation - Front, Side and Open Passive Heat Template - Front and Side Top Discharge Discharge CAUTION! Risk of Cuts, Abrasions or Flying Debris. Install the passive heat templates to prevent finishing Wear protective gloves and safety glasses during instal- material from being installed over passive heat discharge lation.
  • Page 9 TEMPLATES INSTALLED (FRONT DISCHARGE SHOWN) Figure 10 Template Installation ALIGN NOTCH WITH EDGE OF FRAMING Figure 11 Template Notch Alignment Hearth & Home Technologies • PH-LINEAR Instructions • 2616-970 Rev. i • 10/21...
  • Page 10: Finishing

    Finishing Painting Side Discharge: 1. Apply wall sheathing material, such as drywall up to 1/2 in. (13mm) thick up to the edge of the discharge If desired finishing includes painting of the side discharge opening. register covers, Hearth & Home Technologies recom- mends using high temperature paint with a minimum of WARNING! Risk of Overheating! DO NOT apply wall 300 °F (149 °C) continuous exposure rating.
  • Page 11 OVERLAP FIT INSIDE FIT NON-COMBUSTIBLE NON-COMBUSTIBLE FINISHING MATERIAL FINISHING MATERIAL INSIDE FIT = GREATER THAN OVERLAP FIT = 0-1 IN. THICK 1 IN. THICK 1/2 IN. THICK WALL 1/2 IN. THICK WALL SHEATHING SHEATHING Figure 13 Finishing Material Installed OPEN TOP DISCHARGE FRONT DISCHARGE 2 IN.
  • Page 12: Mantel Projections

    Mantel Projections Refer to the appliance Installation Manual. Installation of Passive Heat with Other ATTACH VENTING HERE Optional Heat Management Systems There are other heat management options available for use with the COSMO-IFT-B, RAVE-IFT-B, JADE-B, DVLINEAR36 and B41L-AU models. Consult the appliance manual for compatible options.
