PUMP VAULT
SEPTIC TANK PUMP VAULT
FILTER SYSTEM
INSTALLATION AND SERVICE MANUAL
NOTE! To the installer: Please make sure you provide this manual to the owner of the equip ment or to the responsible
party who maintains the system.
Part # 23833A631 | © 2012 Pentair Pump Group, Inc. | 11/08/12

Advertisement

Table of Contents
loading

Related Manuals for Pentair MYERS PUMP VAULT

Summary of Contents for Pentair MYERS PUMP VAULT

  • Page 1 INSTALLATION AND SERVICE MANUAL NOTE! To the installer: Please make sure you provide this manual to the owner of the equip ment or to the responsible party who maintains the system. Part # 23833A631 | © 2012 Pentair Pump Group, Inc. | 11/08/12...

  • Page 2: Before Installation

    Thank you for purchasing your Myers pump vault • A septic sump condition may exist and if entry into system. sump is necessary, then (1) provide proper safety precautions per OSHA requirements and (2) do not enter sump until these precautions are strictly DO NOT THROW AWAY THIS MANUAL.
  • Page 3 Step 3: Lower the housing into the tank, resting the support pipes on the top of the tank. Step 4: Insert the preassembled 40" PVC pipe with pipe adapter (Figure 1, part A), pipe adapter end first, into the pump. Lower the pump into the pump chamber of the housing.

  • Page 4: Typical Installation

    TYPICAL INSTALLATION CONTROL PANEL J - BOX SECURE EXCESS CORDAGE ACCESS RISER SHUT-OFF VALVE DISCHARGE MUST FALL BELOW FROST LINE FROM GRADE PER LOCAL CODE PREWIRED (PER LOCAL CODE) PIPE SEAL CONDUIT FILTERED EFFLUENT SUPPORT PIPES [44.45] 17" IN LENGTH 1.75 (2) CONFIGURATIONS AVAILABLE...

  • Page 5: Pump Installation

    WARNING: Risk of electrical shock or electrocution. Step 4: Push pump power and float cords through Failure to heed the warnings may result in serious cord grips in the junction box and tighten the cord injury, death, or fire hazard. The installer must grips.

  • Page 6: Service Frequency

    Step 5: Check the pump amperage with a clamp- the floats can be observed. Relocate and clean on amp meter on the black pump lead. Readings float(s) as necessary. higher than the nameplate indicate a clogged pump, miswiring, or improper voltage. 2.

  • Page 7: Servicing The System

    Servicing the System The following tasks should be performed each time the pump vault system is serviced: Step 1: Turn off power to the system. Step 2: Check the sludge level of the septic tank. If the sludge level reaches the bottom of the pump vault housing inlet, the septic tank must be pumped out.

  • Page 8: Standard Limited Warranty

    Warranty is effective only if Pentair Myers authorized control panels are used. All seal fail and heat sensing devices must be hooked up, functional and monitored or this warranty will be void. Pentair Myers will cover only the lower seal and labor thereof for all dual seal pumps. Under no circumstance will Pentair Myers be responsible for the cost of field labor, travel expenses, rented equipment, removal/reinstallation costs or freight expenses to and from the factory or an authorized Pentair Myers service facility.
