- Page 1 © EXOLANDER SYSTEMS FOR AUTEL EVO II 700-XLS-II | 700-XPS-II | 700-XSS-II | 700-3AR-II | 700-XSPS-II PRODUCT MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS © EXOLANDER Systems © EXOLANDER Landing System Reference Guide Physical Characteristics Installation © D100 Drone Spotlight Reference Guide Physical Characteristics Battery Operational Modes Installation 11-12 © Manual Payload Delivery System Reference Guide Physical Characteristics Installation 14-15 Payload Delivery Recommended Payload for Delivery CARE/CLEANING WARNINGS/WARRANTY... -
Page 3: Systems
© EXOLANDER SYSTEMS Manual EVO II D100 Landing Payload © Saddle EXOLANDER Drone Skids Delivery © © Mount Spotlight © System © EXOLANDER - - - - - - Landing System for EVO II P/N 700-XLS-II © EXOLANDER - - - Payload System for EVO II P/N 700-XPS-II... -
Page 4: Landing System
© EXOLANDER LANDING SYSTEM REFERENCE GUIDE © © EVO II SADDLE MOUNT EXOLANDER HALF Alignment Pin ( 2 ea) Alignment Slot Threaded Locking Nut Insert Snap Lock (7 ea) Locking Knob & Screw © EXOLANDER ASSEMBLED © EXOLANDER Mount Connector to ©... -
Page 5: Physical Characteristics
WHAT'S INCLUDED © EVO II Saddle Mount © EXOLANDER Landing Skid (set of 2)* *Not included in P/N 700-3AR-II PHYSICAL CHARACTERISTICS DIMENSIONS WEIGHT* 2.52 x 3.4 x 3.5 in © EVO II Saddle Mount 1.0 oz (28.3 g) (64 x 86 x 89 mm) ©... - Page 6 © © ❷ Install EXOLANDER on Saddle Mount © Place EVO II with Saddle Mount upside down on a flat surface. © Align the EXOLANDER Half with Snap Lock locations on Saddle © © Mount and slide in the EXOLANDER Half at an angle as shown below.
- Page 7 Tighten each screw until the units are mated. © The EXOLANDER installation is now complete. To install the Landing Skid, align each Tab on Landing Skid with each © Slot on the EXOLANDER Landing Foot. Press and snap Landing Skid WARNING: ©...
-
Page 8: D100 Drone Spotlight
© D100 DRONE SPOTLIGHT REFERENCE GUIDE © D100 Drone Spotlight Power/Mode Switch ¼-20 Threaded Hole (2 ea) Mounting Knob (2 ea) Back View Battery Cover... -
Page 9: Physical Characteristics
WHAT'S INCLUDED © D100 Drone Spotlight Mounting Knob (2 ea) 18650 Lithium-Ion Battery (2 ea) XTAR Battery Charger PHYSICAL CHARACTERISTICS DIMENSIONS 3.46 x 2.03 x 2.46 in (88 x 51.5 x 62.5 mm) WEIGHT 8.92 oz (253 g) 12.23 oz (346.6 g) with provided 18650 batteries WARNINGS ©... -
Page 10: Battery
BATTERY © D100 requires two (2) 18650 batteries. Mixing of new and used, or different brand batteries, is not recommended as this could lead to leakage or explosion. BATTERY INSTALLATION AND REPLACEMENT ❶ Slide the battery cover open and insert the battery according to the plus (+) and minus (-) symbol located inside of the battery compartment. -
Page 11: Installation
© D100 INSTALLATION ITEMS REQUIRED: © EXOLANDER Landing System © ❶ Install EXOLANDER Landing System on EVO II. Reference p.5 - 7. © © ❷ Install D100 on EXOLANDER Landing System. © Insert each Mounting Knob in the D100 Mounting Hole of the ©... - Page 12 © Tilt D100 to access the Switch and turn it on to desired mode. Power/Mode Switch © Adjust the tilt of D100 to desired angle and tighten the Mounting Knobs.
-
Page 13: Manual Payload Delivery System
MANUAL PAYLOAD DELIVERY © SYSTEM REFERENCE GUIDE Payload Delivery Unit with Cross Bar ¼ x 1½ QR Pin Key Ring with Ring (38 mm Diameter) Payload Handle/Cord Reel Delivery Bag with 550 Paracord Carabiner with Ring WHAT'S INCLUDED Payload Delivery Unit with Cross Bar Handle/Cord Reel with 550 Paracord (20 ft / 6.1 m) 1/4 x 1½... -
Page 14: Physical Characteristics
PHYSICAL CHARACTERISTICS WEIGHT 6.92 oz (196.3 g) - fully assembled 3.56 oz (101 g) – without bag WARNINGS While using any FoxFury product, please operate at safe speeds. It is the responsibility of drone/UAV users to follow the FAA and global laws and regulations and/or the laws and regulations applicable to the flight location. -
Page 15: Payload Delivery
© ❸ Install Payload Delivery Unit with Cross Bar on the rear of EXOLANDER Locate Payload Delivery Mounting Slots on the rear of © EXOLANDER Payload Delivery Mounting Slot Align the Cross Bar on the top hole of the Payload Delivery Mounting Slot and slide it down to lock in place. -
Page 16: Recommended Payload For Delivery
RECOMMENDED PAYLOAD FOR DELIVERY © EXOLANDER Landing System: 0.37 lbs (168.6 g) © D100 : 0.76 lbs (346.6 g) © Manual Payload Delivery System : 0.43 lbs (196.3 g) Below is the recommended payload for delivery based on reported measurements by professional users. Configuration Total Payload &... -
Page 17: Care/Cleaning
WARRANTY AND OTHER INFORMATION Usage of this product must be PRODUCT DURABILITY supervised by an adult when it is being used by a minor. Any FoxFury product should be operated at speeds safe enough to maneuver around surrounding CARE/CLEANING obstacles. Your FoxFury product is a professional Do not use under the influence of tool. -
Page 18: Contact Foxfury
www.foxfury.com/pages/warrantyregi California to cause cancer and birth stration. defects or other reproductive harm. For more information go to www. THIS IS THE ONLY WARRANTY, P65Warnings.ca.gov. EXPRESSED OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES ARE EXPRESSLY DISCLAIMED EXCEPT WHERE SUCH... - Page 19 08/2021...
