QUICK START GUIDE
RUGO DRONE MOUNTS
FOR DJI PHANTOM 4 (SET OF 2)
P/N 85-027
HOW TO ATTACH MOUNTS
1.
Start by matching the correct side of the
RUGO to the Drone Mount, making sure
the metal tab of the RUGO fits into the
Drone Mount notch.
2.
Use the (2) two thumb screws to attach
the RUGO to the Drone Mount.
3.
To attach the Drone Mount to the
Phantom 4 Drone, position both sides
of the mount on the drone landing gear
skid legs, rotate down to snap the Drone
Mount arms around the landing gear skid
legs. Slide the Drone Mount down the
landing gear skid legs until the bottom
arm of the Drone Mount snaps onto the
bottom of the landing gear skid leg.
4.
Repeat on both sides.
5.
Reverse these steps to remove the Drone
Mounts
WHAT'S INCLUDED:
(2) RUGO Drone Mounts
(2) Thumb Screws
GENERAL MAINTENANCE TIPS
As needed, wash the FoxFury Drone
Mounts using a soft washcloth, clean
water and a mild soap. When done, pat
dry with a soft cloth.
1
2
3
4
5
4/2018
