Ozito DMM-080 Instruction Manual

Ozito DMM-080 Instruction Manual

1050w multi purpose mixer
Hide thumbs Also See for DMM-080:

Advertisement

Quick Links

MULTI
PURPOSE
MIXER
1050W
INSTRUCTION MANUAL

SPECIFICATIONS

Motor:
1050W
Input:
230-240V ~ 50Hz
No Load Speed:
0-550/min
Max. Mixing Capacity:
80L
Mixing Paddle Length:
590mm
Mixing Paddle Diameter: 125mm
Mixing Paddle Thread:
M14 x 2.0mm
Weight:
3.05kg
ozito.com.au
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO
Australia/New Zealand (Head Office) 25 Fox Drive, Dandenong South, Victoria, Australia 3175.

WARRANTY

The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from
the original date of purchase and is intended for DIY (Do It
Yourself) use only. If a product is defective it will be replaced in
accordance with the terms of this warranty. Warranty excludes
consumable parts, for example: carbon brushes, mixing paddle,
spanners, side handle, etc.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.

STANDARD EQUIPMENT

Multi-Purpose Mixer
Side Handle
Mixing Paddle
2 x Spanner
Spare Brushes (Pair)
DMM-080
1220

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DMM-080 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ozito DMM-080

  • Page 1 Weight: 3.05kg ozito.com.au 2 x Spanner Spare Brushes (Pair) DMM-080 WARRANTY IN ORDER TO MAKE A CLAIM UNDER THIS The benefits provided under this warranty are in addition to other rights and remedies which are available to you at law.
  • Page 2 KNOW YOUR PRODUCT SETUP & PREPARATION 1. HANDLES MULTI-PURPOSE MIXER 1 Collet 6 Forward / Reverse Lever WARNING! ENSURE THE TOOL IS SWITCHED OFF AND 2 Side Handle 7 Variable Speed Dial DISCONNECTED FROM THE POWER SUPPLY BEFORE 3 Mixer Housing 8 On/Off Trigger PERFORMING ANY OF THE FOLLOWING ASSEMBLY.
  • Page 3 OPERATION 2. FITTING & REMOVING THE PADDLE 3. ON/OFF SWITCH 1 Align the mixing WARNING! TO REDUCE THE RISK OF ELECTRICAL paddle with the collet SHOCK, THE USE OF A RESIDUAL CURRENT DEVICE at the front of the (RATED 30mA OR LESS) IS RECOMMENDED. mixer.
  • Page 4 Do not force the mixer or apply additional pressure. Let the mixer do all the work. WARNING! ALWAYS REDUCE THE SPEED WHEN SUBMERGING THE MIXER IN THE MATERIAL OR LIFTING IT OUT. ONCE THE MIXER IS FULLY SUBMERGED, INCREASE THE SPEED AGAIN TO ENSURE THAT THE MOTOR IS ADEQUATELY COOLED. DMM-080...
  • Page 5 Always replace both carbon brushes at the same time. Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the mixer by an unauthorised person or by mishandling of the mixer.
  • Page 6 Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. extension lead for signs of damage, w ear and ageing. Replace the extension lead if damaged or defective.
