Summary of Contents for Ozito DMM-080
-
Page 2: Specifications
SPECIFICATIONS MODEL NO. DMM-080 Motor: 1050W Input: 230V ~ 50Hz No load speed: 0-550/min Max. mixing capacity: Mixing paddle size: 600mm (length) 120mm (Ø) Mixing paddle thread: M14 x 2.0mm Tool weight: 3.05kg KNOW YOUR PRODUCT 1. Mid Handle (with soft grip) 8. -
Page 3: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS ……………………………………….. Page 1 INTRODUCTION………………………………………… Page 3 ELECTRICAL SAFETY…………….……………………… Page 3 GENERAL POWER TOOL SAFETY WARNINGS……… Page 4 MULTI PURPOSE MIXER SAFETY WARNINGS……… Page 6 ASSEMBLY………………………………………………… Page 7 OPERATION……………………………………………… Page 8 MAINTENANCE…………….…………………………… Page 9 SPARE PARTS …………….……………………………... Page 10 DESCRIPTION OF SYMBOLS …………………………. -
Page 4: Introduction
The electric motor has been designed for 230V and 240V only. Always check that the power supply corresponds to the voltage on the rating plate. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. -
Page 5: General Power Tool Safety Warnings
GENERAL POWER TOOL SAFETY WARNINGS WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool" in all of the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 6 GENERAL POWER TOOL SAFETY WARNINGS d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
-
Page 7: Multi Purpose Mixer Safety Warnings
MULTI PURPOSE MIXER SAFETY WARNINGS Use auxiliary handle(s), if supplied with the tool. Loss of control can cause personal injury. Hold power tool by insulated gripping surfaces, when performing an operation where the cutting accessory may contact hidden wiring or its own cord. Cutting accessory contacting a "live"... -
Page 8: Assembly
ASSEMBLY WARNING! Always turn off the tool and disconnect from the power supply prior to changing any accessories or making any handle adjustments. Side Handle Fig. 1 The 3 position side handle (9) will provide additional control, support and guidance when using the tool. The side handle (9) can be assembled to the left, top or right side of the metal gear casing (6). -
Page 9: Operation
OPERATION On/off Trigger Switch WARNING! Prior to turning on the Multi purpose Mixer ensure you have a secure hold of the Mid handle (1). To turn on the Multi-purpose Mixer, depress the on/off trigger switch (3) (Fig. 4); to stop the Multi-purpose Mixer , release the on/off trigger switch (3). -
Page 10: Maintenance
Always replace both carbon brushes at the same time. Note: : Ozito Industries will not be responsible for any damage or injuries caused by the repair of the tool by an unauthorised person or by mishandling of the tool. -
Page 11: Spare Parts
SPARE PARTS Limited spare parts are available subject to availability. Please contact your local Bunnings Special Orders Desk to order the required spare parts. Most common spare parts listed below Spare Part Part No. Carbon Brush (set) SPDMM080-27 Switch SPDMM080-34 Mixing Paddle SPDMM080-45 DESCRIPTION OF SYMBOLS... -
Page 12: Pack Contents
Reuse of recycled material decreases pollution in the environment. Please recycle packaging where facilities exist. Check with your local council authority for recycling advice. PACK CONTENTS 1 x Multi-Purpose Mixer DMM-080 1 x Mixing Paddle 1 x Side Handle 1 x Rear Spade Handle... - Page 13 OZITO INDUSTRIES PTY LTD AUSTRALIA (Head Office) 1-23 Letcon Drive, Bangholme Victoria, Australia, 3175 Telephone: 1800 069 486 Facsimile: +61 3 9238 5588 Website: www.ozito.com.au Email: enquiries@ozito.com.au...
-
Page 14: Warranty
If the tool shows signs of damage or defects caused by or resulting from abuse, accidents or alterations. • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175...
