Control Board LED Indicators

9 8 7
10
1. Power On 5. Key / Keypad
2. Master / Slave 6. Stop
Communication 7. Exit / Open
3. Edge Sensor 8. Phantom Loop
4. Close 9. Reverse Loop
Distributed by AFW Access Systems • www.AnchorMiami.com/afwas
____________________
17 15
16
6 5 4
10. Receiver
11. Close Limit
12. Closing
13. Opening
14. Open Limit
(21)
14 13 12
3 1 2
15. Overload
16. Active
17. Timer
11
