Alfaled AFT-11 Installation Instructions

W all Mounted Touch Panel
Model No.: AFT-11, AFT-12, AFT-13, AFT-14
4 Zone/ 1-4 color/ Glass touch panel/ Color w heel/ AC input/ DMX 512 and RF 2.4G signal output
Features
● Touch panel 4 z one 1-4 color DMX512 master, can also be used as 4 zone 1-4 color RF remote.
● DMX signal output, comply to standard DMX512 protocol, compatible w ith DMX decoder from any supplier.
● W hen used as RF remote, each zone can remote control multiple Skydance's 2.4G LED controllers.
● Ultra sensitive high strength glass touch panel w ith touch color w heel in the middle and backlighting.
● Smooth and accurate color adjustment by touching the color w heel.
●Touch keys w ith chord tones and LED indicator.
Technical Parameters
Model No.
Light type
Output DMX channel number
Input and Output
Input voltage
Input current
Output signal
S afety and EM C
EMC standard (EMC)
Safety standard(LVD)
Radio Equipment(RED)
Certification
W arranty
W arranty
User Manual Ver 1.0.4
AFT-11 AFT-12
AFT-11
Single color
4
8 5 -2 6 5 VA C
Max 0.1A
DMX512, RF 2.4GHz
EN301 489,EN 62479
EN60950
EN300 328
CE,EMC,LVD,RED
5 y ears
AFT-13
AFT-12
Dual color
8
Dimming data
Input signal
RF Control distance
Dimming level
Dimming range
Environment
Operation temperature
Case temperature
IP rating
www.alfaled.sk
AFT-14
AFT-13
RGB
1 2
Touch key + RF 2.4GHz
30m
256 levels
0 - 100%
O
Ta: -30 C ~ +55
Max.
( )
Tc: +85 O
C
IP20
LVD RED
AFT-14
RGBW
1 6
O
C
