Platform stair lift PLK8
ORIGINAL-user manual
Part 1: Operating manual
English Version 2.08
ASCENDOR GMBH
Drautendorf 48
4174 Niederwaldkirchen
Austria
Tel.: +43 7231 40040
Fax: +43 7231 40040-590
office@ascendor.at
www.ascendor.at

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLK8 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ascendor PLK8

  • Page 1 Platform stair lift PLK8 ORIGINAL-user manual Part 1: Operating manual English Version 2.08 ASCENDOR GMBH Drautendorf 48 4174 Niederwaldkirchen Austria Tel.: +43 7231 40040 Fax: +43 7231 40040-590 office@ascendor.at www.ascendor.at...
  • Page 2 Operating Manual Platform stair lift PLK8 Date of issue: March 2019 Version 2.08 Part 1 / 3 of the original user manual My ASCENDOR-partner is: Page 2 Version 2.08 Operating Manual PLK8...
  • Page 3: Table Of Contents

    Introduction ..............................5 Description of the lift ............................6 Views of the operating controls ......................6 Views of the Ascendor platform stair lift....................6 List of parts and controls ......................... 7 Service access hatch and fuse box ......................7 Intended scope of operations ......................... 8 Warranty conditions ..........................
  • Page 4 Annual inspection by Lift Inspector ....................... 28 Technical data sheet ..........................29 The further parts of the original user manual are: • Part 2: Assembly Instruction • Part 3: Maintenance and Service Manual Page 4 Version 2.08 Operating Manual PLK8...
  • Page 5: Introduction

    1. Introduction Dear reader! We would like to offer you our congratulations on purchasing this high quality ASCENDOR platform lift and in so doing offer you our thanks for the trust you have shown in our company.
  • Page 6: Description Of The Lift

    2.1 Views of the operating controls Onboard controls fitted to the lift Handheld remote control Wall mounted remote controls Key switch positions ON / OFF 2.2 Views of the Ascendor platform stair lift Front view Rear view Page 6 Version 2.08...
  • Page 7: List Of Parts And Controls

    A connection diagram label is attached to the inside of the service access cover. Push button Platform motor Connection cable for Platform OPEN F2 Fuse 7,5A Main Power Switch emergency platform opening Push button Drive motor RESET button Platform CLOSE F3 Fuse 40A F1 Fuse 2A Operating Manual PLK8 Version 2.08 Page 7...
  • Page 8: Intended Scope Of Operations

    3. Intended scope of operations The Ascendor platform stair lift PLK8 is a fixed installation which may only be used for the purpose for which it was originally designed. Environmental operating conditions: • Operating temperatures from -20° to +40°C •...
  • Page 9: Warranty Conditions

    3.2.1 User All users of an Ascendor platform lift must be in possession of the necessary mental and physical abilities and must have adequate eyesight to be able to recognise a hazard or an obstacle and be able to respond and act accordingly.
  • Page 10: General Description

    An arresting device (emergency brake) ensures that in the event of a mechanical or electrical failure, the lift remains stationary and does not descend down the travel rails. Page 10 Version 2.08 Operating Manual PLK8...
  • Page 11: Certification Plate

    Service load: … kg Maximum load capacity: Nominal power: 0,5 KW Net weight: 145 kg Only 1 Person incl. wheel chair, Ser. Nr.: PLK8-..-….. Year of manufacture 20.. maximum weight ... kg! Manufacturer: Ascendor GmbH Keep travel area in sight at all...
  • Page 12: Safety Guidelines

    ! A T T E N T I O N ! The Ascendor platform stair lift is manufactured in accordance with international safety regulations. Nevertheless, operating errors and misuse can result in heavy injury for the user and/or third parties and cause damage to the lift, its surroundings and property of the operator! The intention of this chapter is to highlight these dangers.
  • Page 13 (light lubrication), or a damp cloth. Never use running water or a hose! Use the protective cover provided for outdoor installations after every operation of the lift in order to protect it from environment influences (i.e. rain). Operating Manual PLK8 Version 2.08 Page 13...
  • Page 14 Maintenance and Service Manual. (Part 3 of the Original User Manual). We advise that an Ascendor approved partner is entrusted with this work. If the lift is to be operated without the use of third party assistance, it’s essential that extra precautions are provided so that –...
  • Page 15: Operating The Lift

    Emergency assistance call button (Pages 6-7, Pos. 4). 6.3 Calling and returning the lift unit The Ascendor platform stair lift can be summoned to or sent from its stationary position with the assistance of the remote-control unit. 6.3.1 Calling or returning the lift unit from the upper station:...
  • Page 16: Access To Lift Platform

    (if fitted) is first properly stowed before closing the platform with the handheld remote control. LOCATION: upper or lower station Push and hold platform CLOSE button. Both safety bars swing down and the platform folds away into the parking position. Page 16 Version 2.08 Operating Manual PLK8...
  • Page 17: What Should I Do In The Case Of An Unforeseen Stoppage

    Chapter 9.1 in this manual. 6.7.1 Emergency travel Following a technical fault, it is still possible to move the Ascendor platform stair lift into a safe position. PLEASE NOTE: The following emergency travel operation procedure is only to be used in the event of a true emergency! The lift, with a passenger onboard is positioned between stations and refuses to function and no other possibility remains to set the lift in motion.
  • Page 18: Emergency Rescue Procedure

    ! ATTENTION ! - Sudden opening of the platform! When the tension belt is removed the platform will fold down suddenly under its own weight. Page 18 Version 2.08 Operating Manual PLK8...
  • Page 19: Electrical Operation And Recharging Advice

    The battery voltage is maintained at a constant 27,6V and the charge current slowly drops to zero. The recharger can therefore always remain connected without damaging the batteries. If the battery voltage should drop below 27,6 V the recharging cycle will repeat stages 2 and 3. Operating Manual PLK8 Version 2.08 Page 19...
  • Page 20: Safety Features

    – Pos.23) are designed to prevent intrusion of foreign objects when the lift is in motion. Please note that they are NOT connected to sensors and always ensure the travel route is free from obstructions before commencing travel! Page 20 Version 2.08 Operating Manual PLK8...
  • Page 21: Optional Extras

    9. Optional extras Ascendor platform stair lifts can be fitted with a range of optional extras which have been designed to meet the different requirements of our customers. 9.1 Emergency call options We offer a choice of two options: Emergency call by UKW radio signal Emergency calling device which enables direct communication to a pre-defined telephone number using a GSM modem.
  • Page 22: Stainless Steel Folding Seat

    9.7 Wall mounted housing for recharger The wall mounted plastic housing is designed to protect the recharger from physical and environmental hazards and is suitable for indoor and outdoor use. Page 22 Version 2.08 Operating Manual PLK8...
  • Page 23: Ec Declaration Of Conformity

    Article § 17 (4) a) or b) of the RED- Directive The administration of the technical documentation of this equipment is the responsibility of: Ascendor GmbH, Technical Development and Documentation Department Drautendorf 48, A-4174 Niederwaldkirchen, Austria Any form of conversion or modification to the machine as well as the failure to observe the terms and instructions provided in the original installation, operating and service manuals, will render this conformity declaration invalid.
  • Page 24: Trouble Shooting Guide

    Check freedom of movement of safety Fault 8 bar motor bars and/or platform motor operation. Fuse F2 is broken Straighten lever of b19 switch or replace Lever switch b19 is bent or broken Page 24 Version 2.08 Operating Manual PLK8...
  • Page 25 Push RESET button on 2A Fuse F1 Short circuit Lift does not work (see Chapter 2.4) No prompt visible on PLC is defective Call service technician the PLC display Low battery voltage Call service technician Operating Manual PLK8 Version 2.08 Page 25...
  • Page 26: Dismantling And Disposal

    The weight is displayed on the name plate fitted on each lift. The transportation of the lift and its ancillaries are only to be partaken under the supervision of an Ascendor partner. Damages which occur during transport undertaken under any other circumstances are not covered by guarantee.
  • Page 27: Service Notes

    The lift should be operated at least once every 2 weeks. Use the rain cover included for exterior installations while the lift is not in use in order to protect it from rain. Operating Manual PLK8 Version 2.08 Page 27...
  • Page 28: Annual Check

    15.4 Annual check This platform lift should be serviced as required and subjected to a thorough inspection and service in accordance with the Ascendor Maintenance and Service Manual (Part 3 of the Original User Manual) at least once a year.
  • Page 29: Technical Data Sheet

    Supporting elements made from zinc-coated steel • Covering panels made from scratch resistant plastic (Standard) Travel rails • Clean, stainless steel tubular upper handrail • Stainless steel tubular lower drive rail with welded toothed rack Operating Manual PLK8 Version 2.08 Page 29...
