Salto LC1M Series Quick Start Manual

Cylindrical cartridge lock: SALTO
Eng
LC1Mxx.../ LC2Mxx...
UL listed
®
LOCK INSTALLATIO N
PREPARING THE DOOR
Note: if the strike already exists in the door frame, position lock using strike as reference.
(See strike position on template)
1. Draw horizontal line on both sides and edge of door at the desired height of
knob above floor.
2. Draw vertical center line on door edge.
3. Draw vertical line on each side at the proper backset to align the template.
4. Position templates on edge and sides of door.
Drill 2-1/8" hole and 1" diameter hole for latch. It is important that both holes
be on the same horizontal center line.
5. Remove template: insert the latch and using front plate as template, trace
outline and chisel recess.
NOTE :
Holes for the fixation of the SALTO electronic escutcheon are not included in this template.
Please use the template included in the escutcheon box.
INSTALLING THE LOCK BODY
1. Insert the latch (A). Mark & drill front plate holes. Fasten latch with screws.
2. In case of using an extender, 3-3/4" or 5" (95mm or 127mm ) , assemble it to
the latch before introducing it into the hole.
3. Insert then the cartridge (B) into the cavity, from inside the door to outside,
until it is completely connected to the latch.
4. Before installing outside escutcheon, fix the alignment support (C) with the
supplied screws.
5. Before mounting inside escutcheon, introduce the spring (D) in the spindle,
and push it against the lock body using the escutcheon.
C
A
LUBRICATION
_____________________________________________________________________________________________________
All locks come lubricated from the factory with grease. We recommend, however, continued periodic lubrication of internal
moving parts with a commercial quality grease. This can add years to the life of the lockset by reducing excessive wear. For
more severe environments, lubrication should be applied more frequently
Electronic escutcheon Cylind rical locksets
C
L
HANDLE
C
L
BACKSET
DOOR
EDGE
A
LATCH
LATCH
TAIL
INSTALLING THE STRIKE
1. Refer to template to determine strike location on jamb.
Using strike as template, mark and chisel recess. Drill screw holes.
2. Install dust box and strike.
Please check if:
- Latchbolt fits the cavity of the strike.
- Gap between door and jamb is in between 2-4 mm.
B
D
.
P-210190 -
C
L
HANDLE
C
L
PRONGS
B
LOCK
HOUSING
-ED.03/02/2010
