Salto AELEMENT LA1T17 Series Change Instructions

1-1/2" (
1.625" (
HANDING CHANGE INSTRUCTION
LATCHBOLT POSITION CHANGING
1. Remove special screw with allen wrench
Make sure foot is
under latch surface
Cannot put in lock with
foot above latch surface
3. Rotate latch bolt 180º and reinstall into lock,
pushing the latch bolt into the lock and then releasing
LOCKING SLIDE POSITION CHANGING
1. Remove 2 screws as shown above
Dimension in inches (dimension in millimetres)
All contents current at time of publication.
SALTO Systems S.L. reserves the right to change availability of any
item in this catalogue, its design, construction, and/or materials.
3/8"
( 9,5 )
38,1 )
41 )
2-27/64" ( 61,6 )
2. Pull latch bolt out of lock
4. From oposite side, insert the special screw and
tighten securely with the allen wrench.
2. Turn lock over opposite side and reinstall screws
as shown above. To ensure locking slide does not bind,
manually push to the desired side or alternate
tightening each screw every 2-3 turns.
©
Strike Lip Position
(Posición labio del cerradero)
(Position du recouvrement gâche)
8-13/64" ( 208,3
Mortise Lock:
Eng
SALTO LA1T17xx../LA1T07xx..
LOCK AND STRIKE INSTALLATION
PREPARING THE DOOR
1. Draw a horizontal line on edge of the door and on inside at the desired
height of knob above floor.
2. Draw a vertical centre line on door edge.
3. Draw a vertical line on inside at the proper backset to align the
template.
4. Position template
Mark ONLY top and bottom holes of mortise cavity (A) and lock front on
door edge. Remove template: Place lock face against door edge.
Trace outline of faceplate as guide for faceplate routing.
5. Mortise door for lock body and faceplate as per instructions on template
6. Position template on inside of door. Mark holes in the lateral face of the
door for turnpiece (B) and handles (C and D). Mark the corresponding
holes for the electronic escutcheon fixings (E and F). The (F) hole
doesn't have to be through, its depth has to be ¾" longer than the
lock center.
INSTALLING THE LOCK BODY
1. Insert wires through (F) hole.
2. Insert the lock into the cavity.
3. Mark & drill faceplate holes.
Fasten with faceplate screws to hold lock in place.
INSTALLING THE STRIKE
1. Center strike to lock's frontplate center lane. Refer to latch to determine
strike location on jamb.
2. Using strike as template, mark and chisel recess.
Drill holes for dust box. Place dust box and strike and fasten screws.
Please check that:
- Deadbolt and latch fit the cavities of the strike without touching it.
- Gap between door and jamb is 1/8".
HANDING ANSI door code
LUBRICATION
_____________________________________________________________________________________________________
All locks come from the factory pre-lubricated with grease. We recommend, however, continued periodic lubrication of moving
parts with commercial quality grease (every 20.000 cycles or once a year), from outside the lock. This can prolong the life of
the lockset by reducing excessive wear. If the lockset is used in a harsh environment, lubrication should be applied more
frequently
.
2013 SALTO Syst ems S.L.
2" ( 50,8 )
)
on edge of door.
FRONTPLATE
(A)
C
L
OF
LEVER
(A)
1-7/16" ( 36,5 )
(E)
C
L
(E)
OF
(F)
(B)
OF
LEVER
C
L
(D)
(C)
(D)
C
L
OF
BACKSET
Required Information
221373 - -ED.12/08/2013
