COOKERS & OVENS
Instruction Book
CU322 - CU325 - CU402 - CU403 - CU423 - CU434 - FO300
SAFETY ALERT SYMBOLS
FOR YOUR SAFETY
Safety Symbols alerting you to potential personal safety hazards. Obey all safety messages following these symbols.
WARNING
Avoid possible injury
or death.
FOR YOUR SAFETY READ ALL INSTRUCTIONS bEFORE OpERATING AppLIANCE
INSTALLER: PROVIDE THESE INSTRUCTIONS TO THE CONSUMER.
CONSUMER: KEEP DOCUMENTS FOR FUTURE REFERENCE.
WARNING: if the information in this manual is not followed
exactly, a fire or explosion may result causing property
damage, personal injury or death.
- Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use phones in your recreational vehicle.
• Evacuate the recreational vehicle of all occupants.
• Turn off the gas supply tank valve(s) or main gas supply.
• Immediately call your gas supplier for instructions.
• If you cannot reach your gas supplier, call the fire
department.
- Have the gas system checked and leakage source
corrected by a qualified installer, service agency,
manufacturer or dealer or the gas supplier.
DOMETIC USA
DOCUMENT: COD41REV2
DATE: 2011-11
CAUTION
Avoid possible injury and/or
property damage.
w w w . s m e v . c o m
