EAW SB850P Dimensions

29.91
22.19
5.38
38.10

VIEW A-A

DIMENSIONS APPLY
TO BOTH SIDES
(29.91 )
(16.50 )
13.65
L C
A
21.87
A
TOP
5.00
26.38
1.95

GRILLE PARTIALLY SHOWN

FRONT
19°
20.97
C L
(21.29 )
BOTTOM

NOTES:

1. SYMBOL
3/8-16 THREADED HOLE (PI ANGLE).
29.50
2. SYMBOL
BALANCE.
3. WEIGHT APPROX. 299 LBS.
4. SHIPPING WEIGHT APPROX. 309 LBS
INPUT
42.00
6.00
14.12
2.62
2.37
PRODUCTION
INDICATES MOUNTING POINT,
INDICATES CENTER OF
C L
23.00
C L
BACK
SB850P
EASTERN ACOUSTIC WORKS
3.50
