EAW SM129z Specifications

FEATURES

• Compact 2-way 12-inch stage monitor / PA
• Dual purpose loudspeaker: stage monitor and PA
• Two mounting points accept third party external
stand adaptor for PA use
• Rubber feet included for floor mounting
• Passive crossover and EQ for economical single
amplifier operation
• Dual Neutrik NL4 connectors on each side for input and
loop through connection
• Two integral handles strategically placed for easy transport
• Foam-backed steel grille for protection from physical
damage and dust

DESCRIPTION

The SM129z is a compact, professional loudspeaker designed
for dual-purpose stage monitor and PA use. Its 12-inch low
frequency transducer provides strong LF performance while
keeping a modest enclosure size for situations with limited
space. This is complemented by a 1-inch exit Neodymium
compression driver. The smooth HF response and high output
capability cuts through stage sound for quality monitoring
and provides good projection for PA use. The low profile and
compact size are ideal for situations where small physical size
is needed, without sacrificing professional performance.
Integral mounting points accept a third party external stand
adaptor for pole mounting. Portable usage is enhanced by the
heavy-duty enclosure construction, foam-backed steel grille,
and integral handles. The connector panels on each side have
dual Neutrik NL4 jacks for reliable input and loop through
connections.
APPLICATION
Applications include:
• Corporate Events
• Theatres
• Live Music clubs
PERFORMANCE
Frequency Response (Hz)
±3 dB 80 Hz to 19 kHz
-10 dB 65 Hz
Axial Sensitivity (dB SPL, 1 Watt @ 1 m)
Nominal Impedance (ohms)
Power Handling (watts, continuous)
One Main Street, Whitinsville, MA 01588
EAW products are continually improved. All specifications are therefore subject to change without notice.
• Band PA and monitor
• Houses of Worship
97
8
450
508 234 6158 Toll Free 800 992 5013
SPECIFICATIONS SM129z
Recommended High-Pass Frequency
24 dB/octave 65 Hz
Calculated SPL Limit (dB @ 1 m)
Peak 129
Long Term 123
Nominal Dispersion (degrees @ -6 dB)
Horizontal 90
Vertical 45
PHYSICAL
LF Subsection 1x 12-in, vented
HF Subsection 1x 1-in exit compression driver
Configuration 2-way, full range stage monitor
Powering Mode Passive LF/HF crossover
Enclosure Shape Wedge stage monitor
Enclosure Materials Exterior grade Baltic birch
Finish Wear-resistant textured
Connectors 4x Neutrik NL4 Speakon
Mounting Hardware (2) 5/16"-18 threaded mounting
Grille Powder coated perforated steel,
Dimensions
Height 19.2
Width 15.0
Depth 22.2
Floor Angle 37°
Note: The supplied feet add approx.
Weights
Net Weight 43
Shipping Weight 50
FAX 508 234 8251
SM129z-0001331/2 pp
on constant directivity horn
black paint
(2 per side)
points on top to accept a third
party external stand adaptor
foam backed
inches millimeters
488
381
564
0.4-in/10mm to the enclosure
height
pounds kilograms
19.6
22.7
info@eaw.com www.eaw.com
April 2002 Printed in USA
