Gonet Systems GoBeam 5100 Quick Installation Manual

GoBeam 5100 Quick Installation Guide
Components Included in the Package
Description
A Wall/Pole Bracket
B Clamping Bracket
C 'L' Adapter Wall/Pole Mount
D Antenna Support Plate
E Hex Bolt M8x70
F Hex Bolt M8x40
G Hex Bolt M8x25
H Flat Washer M8
I Spring Washer M8
1. Assemble the 'L' Adapter
Assemble the 'L' Adaptor to the
GoBeam 5100 Unit.
UM000018 Rev 1.0
Qty Description
1
J Nut M8
K Safety Cable
1
L Waterproof RJ45 connector
1
1
M Optional Power Injector
2
Grounding Kit
1
N Ring Terminal
Ground Screw
1
Lock Washer
Optional Mesh Antenna Kit
3
O Mesh Antenna
3
Spring Washer
Hex Bolt
"L" Adapter
Flat Washer
Qty
1
1
2
1
1
1
2
2
