Gonet Systems GoBeam 6100 Quick Installation Manual

GoBeam 6100 Quick Installation Guide

Components Included in the Package

Description
A Wall/Pole Bracket
B Clamping Bracket
C 'L' Adapter Wall/Pole Mount
D 'T' Adapter Wall/Pole Mount
E Hex Bolt M8x70
F Hex Bolt M8x40
G Hex Bolt M8x25
H Flat Washer M8
I Spring Washer M8
J Nut M8
K Safety Cable
UM000017 Rev 1.0
Qty Description
1 L Waterproof RJ45 connector
1 M Optional Power Injector
1
Grounding Kit
1
N Ring Terminal
Ground Screw
2
Lock Washer
1
Optional Mesh Antenna Kit
O Mesh Antenna
1
Omni Antenna L-Brackets
4
Screw M4
4
Flat Washer M4
1
Spring Washer M4
1
Antenna Cable
Qty
2
1
1
1
2
2
1
2
2
2
2
