1.This product contains bolts and other small parts that may present a chocking hazard for children 3 years or
under.This unit must be assembled by an adult.
2.periodically check the safety of your product by making certain all bolts and nuts are tightened securely.
COMPONENT PARTS
A
1pc
B
Back Frame
Base
D
2pcs
E
Armrest
Back Cushion
Cushions
PARTS LIST
2pcs
G
H
2pcs
30mm SCREWS AND
WOODEN
WASHERS
PLUGS
J
2pcs
K
METAL PLUGS
METAL ROD
WARNING
1pc
C
2pcs
armrests
F
1pc
1pc
Seat Cushion
I
2pcs
ALLEN KEY
2pcs
L
2pcs
45mm SCREWS AND
WASHERS
ASSEMBLY INSTRUCTIONS
Glider/Rocker with Ottoman
CAUTION
!
NOTE:
DO NOT TIGHTEN SCREWS
UNTIL STEP 3.
STEP 1
Place the back frame (A) on the base(B) and align the
holes in the back frame(A) with the holes on the
base(B).Use the screw (H) in each of the two holes as
shown and tighten with allen key (I),Put (K) into the
seat top.
A
B
ITEM#:AF20203-MSR
H
K
Page 2-1
