7-11. Unit status monitoring and the detected value indication

The wired remote controller can monitor the indoor and outdoor units' status and display the detect-
ed result as a relevant ID.
For details of the display method, refer to the Chapter of "Display Sensor Values" in the Installation
Manual of →ired remote controller (Touch panel).
The status can be monitored and displayed on the wired remote controller by assigning an arbitrary
ID. For available ID list, refer to the table below.
NOTE: Operating time for each part cannot be reset when the part is replaced. Take notes of the
operating time before replacing to count the operating time of the replaced part.
Sensor ID
00: Indoor unit
00 000 Suction temp.
00 001 Room temp.
→ired remote controller detected
00 002
temp.
00 006 Heat exchanger middle temp.
00 020 Fan rotation number
00 051 Float switch On/Off
00 052 Drain pump On/Off
00 080 Indoor unit total energized hours
00 081 Total filtering hours
00 082 Indoor unit fan total operation hours
00 140 Operation or Stop (External input)
00 142 Forced stop (External input)
00 143 Operation or Stop 2 (External input)
Operation or Stop On/Off (External
00 155
output)
00 156 Error On/Off (External output)
Indoor unit fan interlocking On/Off
00 157
(External output)
7-11. Unit status monitoring and the detected value indication
Available Sensor ID
Item
01: °F or °C
01: °F or °C
01: °F or °C
01: °F or °C
- (04-30) -
Unit
→hen the wired remote controller
thermistor is enabled, temperature of
the wired remote controller thermistor
is displayed.
03: rpm
0: Off, 1: On (→hen the water level
08: On/Off
rises)
08: On/Off 0: Off, 1: On
11: h
11: h
11: h
0: Off, 1: On
—: →hen the function setting 46 is
not set
00: —
NOTE: Available only for external
input port of the indoor unit
0: Off, 1: On
—: →hen the function setting 46 is
not set
00: —
NOTE: Available only for external
input port of the indoor unit
0: Off, 1: On
—: →hen the function setting 46 is
not set
00: —
NOTE: Available only for external
input port of the indoor unit
0: Off, 1: On
NOTE: The value is output even if
00: —
the function setting or
rotary switch is not set.
0: Off, 1: On
NOTE: The value is output even if
00: —
the function setting or
rotary switch is not set.
0: Off, 1: On
NOTE: The value is output even if
00: —
the function setting or
rotary switch is not set.
