AIR CONDITIONER
INDOOR UNIT (Ceiling type)
Contents
1. SAFETY PRECAUTIONS ...................................................... 1
1.1. IMPORTANT! Please read before starting ........................... 1
1.2. Special precautions ......................................................... 1
2. PRODUCT SPECIFICATION ................................................... 2
2.1. Precautions for using R32 refrigerant ................................. 2
2.2. Installation tools ............................................................ 4
2.3. For authorized service personnel only ................................. 5
2.4. Accessories .................................................................. 5
2.5. Pipe requirement ............................................................ 5
2.6. Electrical requirement ...................................................... 5
2.7. Optional parts ............................................................... 6
2.8. Selecting the pipe material ................................................ 6
3. INSTALLATION WORK ......................................................... 6
3.1. Selecting an installation location ....................................... 6
3.2. Installation dimension ...................................................... 7
3.3. Installing the unit ............................................................ 7
3.4. Pipe installation ............................................................ 9
3.5. Drain installation ......................................................... 11
3.6. Electrical wiring ......................................................... 12
3.7. Remote controller installation .......................................... 13
4. OPTIONAL INSTALLATION WORK ....................................... 14
4.1. Optional kit installation ................................................ 14
4.2. External input and output ............................................. 14
5. REMOTE CONTROL INSTALLATION .................................... 15
5.1. Group control ............................................................ 15
5.2. Multiple remote control ................................................ 15
6. FUNCTION SETTING ......................................................... 15
6.1. Function details ......................................................... 15
7. CHECK LIST ..................................................................... 18
8. FRESH-AIR INTAKE ............................................................ 19
9. TEST RUN ........................................................................ 19
10. FINISHING ........................................................................ 19
11. CUSTOMER GUIDANCE ...................................................... 19
12. ERROR CODES ............................................................... 20
NOTES: This manual describes how to install the air conditioner described above.
Handling and installation shall only be done by professionals as outlined in
this manual.
• Installation must be performed in accordance with the requirement of NEC (National
Electrical Code) and CEC (Canadian Electrical Code) by authorized personnel only.
• All products are manufactured to metric units and tolerances. United States customary
units are provided for reference only. In cases where exact dimensions and tolerances
are required, always refer to metric units.
INSTALLATION MANUAL
1. SAFETY PRECAUTIONS
1. 1. IMPORTANT! Please read before starting
This air conditioning system meets strict safety and operating standards.
As the installer or service person, it is an important part of your job to install or service the
system so it operates safely and efficiently.
For safe installation and trouble-free operation, you must:
• Carefully read this instruction booklet before beginning.
• Follow each installation or repair step exactly as shown.
• Observe all local, state, and national electrical codes.
• Pay close attention to all danger, warning, and caution notices given in this manual.
This symbol refers to a hazard or unsafe practice which can result in
WARNING:
severe personal injury or death.
This symbol refers to a hazard or unsafe practice which can result in
CAUTION:
personal injury and the potential for product or property damage.
• Hazard alerting symbols
: Electrical
If Necessary, Get Help
These instructions are all you need for most installation sites and maintenance conditions.
If you require help for a special problem, contact our sales/service outlet or your certified
dealer for additional instructions.
In Case of Improper Installation
The manufacturer shall in no way be responsible for improper installation or maintenance
service, including failure to follow the instructions in this document.
1. 2. Special precautions
When Wiring
ELECTRICAL SHOCK CAN CAUSE SEVERE PERSONAL INJURY OR DEATH. ONLY A
QUALIFIED, EXPERIENCED ELECTRICIAN SHOULD ATTEMPT TO WIRE THIS SYSTEM.
• Do not supply power to the unit until all wiring and tubing are completed or reconnected
and checked.
• Highly dangerous electrical voltages are used in this system. Carefully refer to the wir-
ing diagram and these instructions when wiring. Improper connections and inadequate
grounding (earthing) can cause accidental injury or death.
• Ground (Earth) the unit following local electrical codes.
• Connect all wiring tightly. Loose wiring may cause overheating at connection points and
a possible fi re hazard.
When Transporting
Be careful when picking up and moving the indoor and outdoor units. Get a partner to
help, and bend your knees when lifting to reduce strain on your back. Sharp edges or thin
aluminum fi ns on the air conditioner can cut your fi ngers.
When Installing...
...In a Ceiling or Wall
Make sure the ceiling/wall is strong enough to hold the unit's weight. It may be necessary
to construct a strong wood or metal frame to provide added support.
...In a Room
Properly insulate any tubing run inside a room to prevent "sweating" that can cause
dripping and water damage to walls and fl oors.
...In an Area with High Winds
Securely anchor the outdoor unit down with bolts and a metal frame.
Provide a suitable air baffl e.
...In a Snowy Area (for Heat Pump-type Systems)
Install the outdoor unit on a raised platform that is higher than drifting snow.
PART No. 9384330079-01
For authorized service personnel only.
: Safety/alert
En-1
