Sauder Pinwheel 421886 Manual

Kids open wardrobe
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
sauder.com
Kids Open Wardrobe
Pinwheel Collection | Model 421886
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
WARNING
CHOKING HAZARD - Small Parts
Not for children under 3 years.
Adult assembly required.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-15
Français pg 16-17
Español pg 18-20
Lot # 507258
09/20/17
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

Table of Contents
loading

Related Manuals for Sauder Pinwheel 421886

Summary of Contents for Sauder Pinwheel 421886

  • Page 1 Pinwheel Collection | Model 421886 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 5-15 Hammer Not actual size Français 16-17 Español 18-20 Skip the power trip. Safety 21-22 This time. Warranty Page 2 421886 www.sauder.com/services...

  • Page 3: Part Identification

    While not all parts are labeled, some of the parts will have a label or an inked letter on the edge to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts. END (2) SHELF (1) BOTTOM (1) UPRIGHT (1) SHELF MOLDING (2) ADJUSTABLE SHELF (2) www.sauder.com/services 421886 Page 3...

  • Page 4: Hardware Identification

    Esta es una etiqueta permanente. No remover. 10/16 395783 (Refer to Step 10 for proper location and application) METAL PIN - 10 SHELF SNAP - 8 THREADED PIN - 2 APPLIQUE CARD - 1 113S BLACK 1-15/16" FLAT HEAD SCREW - 2 Page 4 421886 www.sauder.com/services...
  • Page 5 Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. To begin assembly, push twelve SAUDER TWIST-LOCK® å FASTENERS (12F) into the large holes in the SHELF (B) and BOTTOM (C).

  • Page 6: Hidden Cam

    å Then, insert the metal end of a CAM DOWEL (2F) into each Some assembly HIDDEN CAM. (and snacks) required. Arrow (4 used) Arrow Insert the metal end of the CAM DOWEL into the HIDDEN CAM. Page 6 421886 www.sauder.com/services...
  • Page 7 Step 3 Fasten the SHELF MOLDINGS (E) to the SHELF (B). å How to use the SAUDER TWIST-LOCK® FASTENER Tighten four TWIST-LOCK® FASTENERS. 1. Insert the dowel end of the FASTENER into the hole of the adjoining part. NOTE: The dowel end of the FASTENER must remain fully inserted in the hole of the adjoining part while locking the FASTENER.
  • Page 8 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees Page 8 421886 www.sauder.com/services...
  • Page 9 Step 5 Insert two METAL PINS (1R) into the SHELF (B). å Slide the UPRIGHT (D) onto the METAL PINS in å the SHELF (B). www.sauder.com/services 421886 Page 9...
  • Page 10 S u r f a c i t h I S T - L O F A S T E N ® E R S 113S BLACK 1-15/16" FLAT HEAD SCREW (2 used in this step) Page 10 421886 www.sauder.com/services...
  • Page 11 Step 7 Fasten the other END (A) to the SHELF (B) and BOTTOM (C). å Tighten four TWIST-LOCK® FASTENERS. Fasten the END (A) to the SHELF MOLDINGS (E). Tighten å two HIDDEN CAMS. www.sauder.com/services 421886 Page 11...
  • Page 12 KNOBS (159K) clockwise until the THREADED PINS are tight in the ROD (27A) and each KNOB. NOTE: Do not overtighten the THREADED PINS. The KNOBS will be å snug against the ENDS when tight. 159K 159K Page 12 421886 www.sauder.com/services...
  • Page 13 METAL PINS and push down until each SHELF "snaps" into the SHELF SNAPS (8R). NOTE: If you wish to change the location of the SHELVES, å tap the SHELF up with the palm of your hand. (8 used) www.sauder.com/services 421886 Page 13...
  • Page 14 This is a permanent label. Do not remove. Cette étiquette est permanente. Ne pas l’enlever. Esta es una etiqueta permanente. No remover. 10/16 395783 Page 14 421886 www.sauder.com/services...
  • Page 15 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with a damp cloth. Wipe dry. å And to celebrate, why not share your success story? 25 lbs. (4 used) 35 lbs. 15 lbs. 15 lbs. 25 lbs. total www.sauder.com/services 421886 Page 15...

  • Page 16: Liste De Pièces

    QUANTITÉ d’ a chat de cet élément et conserver le livret pour future référence. EXTRÉMITÉ ..............2 27A TRINGLE ................1 Pour contacter Sauder TABLETTE ................1 EXCENTRIQUE ESCAMOTABLE .....4 en ce qui concerne cet DESSOUS ................1 CHEVILLE D'EXCENTRIQUE ......4 élément, faire référence au numéro de lot et...

  • Page 17: Excentrique Escamotable

    éviter d'endommager l'élément ou le sol. Fixer l'EXTRÉMITÉ (A) aux MOULURES DE TABLETTE (E). Serrer Pour commencer l'assemblage, enfoncer douze FIXATIONS deux EXCENTRIQUES ESCAMOTABLES. TWIST-LOCK® SAUDER (12F) dans les gros trous de la TABLETTE (B) et du DESSOUS (C). ÉTAPE 8 ÉTAPE 2 Relever, avec précaution, l'élément dans sa position verticale.

  • Page 18: Lista De Partes

    EXTREMO ................2 27A VARILLA ................1 et conserver le livret pour future référence. ESTANTE ................1 EXCÉNTRICO ESCONDIDO .......4 Pour contacter Sauder FONDO .................1 PASADOR DE EXCÉNTRICO ......4 en ce qui concerne cet PARAL ...................1 12F SUJETADOR TWIST-LOCK®......12 élément, faire référence au numéro de lot et...

  • Page 19: Excéntrico Escondido

    Fije las MOLDURAS DE ESTANTE (E) al EXTREMO (A). Apriete dos EXCÉNTRICOS ESCONDIDOS. Para comenzar el ensamblaje, empuje doce SUJETADORES TWIST-LOCK® SAUDER (12F) dentro de los agujeros grandes del Precaución: Riesgo de daños o heridas. Los Excéntricos ESTANTE (B) y del FONDO (C).
  • Page 20 AJUSTABLES (F) sobre las ESPIGAS DE METAL y empuje hacia abajo hasta que cada ESTANTE "encaje" en los FIADORES DE ESTANTE (8R). NOTA: Si desea cambiar la ubicación de los ESTANTES, ligeramente golpee hacia arriba en el ESTANTE con la mano. Page 20 421886 www.sauder.com/services...
  • Page 21 TOUJOURS décharger les tablettes et les tiroirs, en commençant par les surface supérieures, avant de déplacer le meuble. NE JAMAIS pousser ou tirer un meuble sur de la moquette. Demander à une autre personne de le soulever correctement pour le déplacer et/ou le repositionner. www.sauder.com/services 421886 Page 21...
  • Page 22 SIEMPRE descargue los estantes y cajones, empezando con las superfi cies superiores, antes de moverlo. NUNCA empuje ni tire de los muebles sobre una alfombra. Obtenga que un amigo le ayude a levantarlo correctamente para moverlo y/o reposicionarlo. Page 22 421886 www.sauder.com/services...

  • Page 23: Year Limited Warranty

    à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 24 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
