Sauder Entertainment Credenza 427465 Instruction Booklet

Hide thumbs

Advertisement

Available languages

Available languages

Quick Links

Download this manual
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
sauder.com/service
Visit
Prefer the phone? Give us a ring at
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Entertainment Credenza
Model 427465
Share your journey!
to order replacement parts, view video assembly tips, or chat with a live rep.
1-800-523-3987
.
Entertaining what
entertains you.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-36
Français pg 37-40
Español pg 41-44
Lot # 544987
08/03/20
Purchased: __________________

Advertisement

loading

Related Manuals for Sauder Entertainment Credenza 427465

Summary of Contents for Sauder Entertainment Credenza 427465

  • Page 1 CONTACT US FIRST BEFORE MAKING ANY RETURNS TO THE STORE. sauder.com/service Visit to order replacement parts, view video assembly tips, or chat with a live rep. 1-800-523-3987 Prefer the phone? Give us a ring at Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays) Entertaining what entertains you.
  • Page 2 • Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly! • This Sauder unit is designed for use with televisions weighing less than 70 pounds. Never use with a TV that weighs more.
  • Page 3 UPRIGHT (2) ADJUSTABLE SHELF (6) LEG (4) CENTER LEG (2) CENTER SKIRT (1) SKIRT (2) BOTTOM (1) VALANCE (1) RIGHT DOOR MOLDING (1) LEFT DOOR MOLDING (1) BACK (1) TOP (1) RIGHT DOOR (1) LEFT DOOR (1) www.sauder.com/service 427465 Page 3...
  • Page 4 183M 184M WHEEL - 4 BAR - 4 SUPPORT - 4 SUPPORT - 4 DOOR BARREL LONG BARREL DOOR TRACK 185M 187M 188M 189M NUT - 8 STOP - 2 NUT - 4 TUBE - 1 Page 4 427465 www.sauder.com/service...
  • Page 5 BLACK 5/8" FLAT HEAD SCREW - 4 127S BLACK 3/8" MACHINE SCREW - 8 140S BLACK 5/8" LARGE HEAD SCREW - 8 149S BROWN 5/8" FLAT HEAD SCREW - 4 150S BROWN 1/2" PAN HEAD SCREW - 4 www.sauder.com/service 427465 Page 5...
  • Page 6 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/service/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Push eight HIDDEN CAMS (1F) into the UPRIGHTS (C) å...
  • Page 7 Push four HIDDEN CAMS (1F) into the edges of the å ENDS (A and B). Then, insert the metal end of a CAM Some assembly DOWEL (2F) into each HIDDEN CAM. (and snacks) required. Do not tighten the HIDDEN CAMS in this step. Arrow www.sauder.com/service 427465 Page 7...
  • Page 8 CAM into this hole. (12 used) Arrow Do not insert a HIDDEN CAM into this hole. Arrow Arrow Hole The arrow in the HIDDEN CAM must point toward the hole in the edge of the board. Page 8 427465 www.sauder.com/service...
  • Page 9 Step 4 Turn twelve CAM SCREWS (8F) into the LEGS (E and F). å (12 used) www.sauder.com/service 427465 Page 9...
  • Page 10 HIDDEN CAMS. These surfaces should be even. Edge with CAM DOWELS S u r f a c H I D D E N i t h These surfaces should be even. The LEGS will overhang this edge. Page 10 427465 www.sauder.com/service...
  • Page 11 Tighten four HIDDEN CAMS. These surfaces should be even. Edge with CAM DOWELS i t h f a c S u r D E N H I D These surfaces should be even. The LEGS will overhang this edge. www.sauder.com/service 427465 Page 11...
  • Page 12 VALANCE (J). Use eight BLACK 9/16" LARGE HEAD SCREWS (1S). NOTE: Be sure the BRACKETS are even with the edges of å the UPRIGHTS and VALANCE. BLACK 9/16" LARGE HEAD SCREW (8 used in this step) (8 used) Page 12 427465 www.sauder.com/service...
  • Page 13 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees www.sauder.com/service 427465 Page 13...
  • Page 14 M E T B R A C K E BLACK 9/16" LARGE HEAD SCREW (4 used in this step) This hole will be closer to this edge. Page 14 427465 www.sauder.com/service...
  • Page 15 NOTE: You should start each SCREW a few turns before å completely tightening any of them. 113S BLACK 1-15/16" FLAT HEAD SCREW (4 used in this step) The groove on the other surface of the BOTTOM should be here. www.sauder.com/service 427465 Page 15...
  • Page 16 (4 used in this step) i t h f a c S u r D E N H I D i t h o f a c S u r D E N H I D Page 16 427465 www.sauder.com/service...
  • Page 17 HIDDEN CAMS. NOTE: Be sure to position the LEGS and SKIRTS exactly as shown. å HIDDEN CAM Groove Surface with HIDDEN CAMS HIDDEN CAM Groove Groove The CAM SCREW should be closer to the bottom edge. www.sauder.com/service 427465 Page 17...
  • Page 18 Step 13 Insert the WOOD DOWELS in the CENTER LEGS (F) å into the holes in the BOTTOM (I). S u r f a c i t h H I D D E N Page 18 427465 www.sauder.com/service...
  • Page 19 NOTE: There are no pre-drilled holes in the SKIRTS. The å SCREWS will tighten into the grooves. BLACK 9/16" LARGE HEAD SCREW NOTE: Start from the center of your unit and work out å (12 used in this step) towards both ENDS for proper alignment. www.sauder.com/service 427465 Page 19...
  • Page 20 Peel the FELT DISCS from the FELT DISC CARDS (1M) å and stick them on the bottom of each LEG (E and F) in the BLACK 9/16" LARGE HEAD SCREW locations shown. (8 used in this step) Page 20 427465 www.sauder.com/service...
  • Page 21 NOTE: Perforations have been provided for access through the å BACK. Carefully cut out the holes needed. The top edge of the BACK should be down slightly from the top edge of the TOP. These holes must line up over the UPRIGHTS (C). www.sauder.com/service 427465 Page 21...
  • Page 22 IMPORTANT: The ADJUSTABLE FEET should not extend å beyond the bottom edges of the LEGS (E and F). With your No. 2 Phillips Screwdriver, turn the ADJUSTABLE FEET downward until they touch the fl oor. Floor Page 22 427465 www.sauder.com/service...
  • Page 23 Step 18 Insert the DOOR TRACK (107M) into the groove in å the BOTTOM (I). NOTE: You may need to gently tap the DOOR TRACK å into the groove in the BOTTOM using your hammer. 107M Groove www.sauder.com/service 427465 Page 23...
  • Page 24 Step 19 Insert two HOLE PLUGS (41P) into the holes in å the BOTTOM (I). Page 24 427465 www.sauder.com/service...
  • Page 25 Push the RUBBER SLEEVES (2R) over the METAL å PINS (1R). Insert the METAL PINS into the hole locations of your choice in the ENDS (A and B) and UPRIGHTS (C). Set the ADJUSTABLE SHELVES (D) onto the METAL PINS. (24 used) www.sauder.com/service 427465 Page 25...
  • Page 26 VALANCE (J). Use four BROWN 5/8" FLAT HEAD SCREWS (149S). NOTE: Be sure to position the DOOR TRACK å SUPPORTS exactly as shown. 149S Large hole BROWN 5/8" FLAT HEAD SCREW (4 used in this step) 184M Page 26 427465 www.sauder.com/service...
  • Page 27 Step 22 Apply TAPE from the TAPE CARDS (4M) to the DOOR å MOLDINGS (K and L) as shown. Then, peel off the backing from the TAPE on the DOOR MOLDINGS. www.sauder.com/service 427465 Page 27...
  • Page 28 (4 used in this step) i t h f a c o l e S u r r e h i t h f a c o l e S u r r e h (4 used) Page 28 427465 www.sauder.com/service...
  • Page 29 Use a LONG BARREL NUT (188M) and a BLACK 5/8" FLAT HEAD SCREW (123S). Repeat this step for the remaining DOOR WHEELS and å WHEEL SUPPORTS. 123S BLACK 5/8" FLAT HEAD SCREW (4 used in this step) (4 used) 188M 183M www.sauder.com/service 427465 Page 29...
  • Page 30 (8 used in this step) Repeat this step for the RIGHT DOOR (O). å Before tightening the SCREWS, slide the WHEEL SUPPORTS down 183M as far as they will go on the DOOR. 187M Page 30 427465 www.sauder.com/service...
  • Page 31 Repeat this step for the RIGHT DOOR (O). å The RETAINING BARS should move up and down easily. The RETAINING 155M BARS should overhang the bottom edge of the DOOR. SILVER 5/8" MACHINE SCREW (4 used for the PULLS) 131K www.sauder.com/service 427465 Page 31...
  • Page 32 NOTE: Before lifting the DOORS, position your hands as shown and apply pressure towards the center of the DOORS. å 150S 189M BROWN 1/2" PAN HEAD SCREW (2 used in this step) 185M 189M 189M Before lifting, apply pressure with your hands towards the center of the DOORS. Page 32 427465 www.sauder.com/service...
  • Page 33 Now, fasten the DOOR TRACK TUBE (189M) to the outer DOOR TRACK å SUPPORTS (184M). Use two BROWN 1/2" PAN HEAD SCREWS (150S). 150S BROWN 1/2" PAN HEAD SCREW (2 used in this step) 107M 155M www.sauder.com/service 427465 Page 33...
  • Page 34 Peel the BUMPERS from the BUMPER CARDS (29M) and å stick the BUMPERS on the upper and lower corners of both sides of each DOOR (O and P). Caution To reduce the risk of pinching fi ngers, use the provided Bumpers. (8 used) Page 34 427465 www.sauder.com/service...
  • Page 35 Slide the DOORS over to the sides of your unit. Then, loosen the å SCREWS in the WHEEL SUPPORTS a 1/4 of a turn, make any needed adjustments, and tighten the SCREWS. Loosen these SCREWS a 1/4 of a turn, make adjustments, and tighten. www.sauder.com/service 427465 Page 35...
  • Page 36 - The TV must weigh less than 70 lbs. - The base of the TV must be able to sit completely on this shelf. 25 lbs. each 25 lbs. each (10 used) To cover HIDDEN CAMS Page 36 427465 www.sauder.com/service...
  • Page 37 EXTRÉMITÉ DROITE ..........1 FICHE DE TAMPONS EN FEUTRE .....2 pour future référence. EXTRÉMITÉ GAUCHE ..........1 CARTE DE RUBAN ADHÉSIF ......2 Pour contacter Sauder MONTANT ..............2 29M FICHE AVEC TAMPONS ........4 en ce qui concerne cet TABLETTE RÉGLABLE .........6 98M ROULETTE DE PORTE ..........4 élément, faire référence...
  • Page 38 Fixer les autres PIEDS (E) à l'EXTRÉMITÉ GAUCHE (B). Serrer ci-dessous avant de commencer l'assemblage ! quatre EXCENTRIQUES ESCAMOTABLES. • Cette unité Sauder est conçue pour les téléviseurs pesant moins de 31,75 kg. Ne jamais utiliser avec des téléviseurs plus lourds. ÉTAPE 7 •...
  • Page 39 REMARQUE : S'assurer de bien enfoncer les CLOUS dans les trous qui sont alignés sur les MONTANTS (C). REMARQUE : Des lignes perforées ont été prévues pour accéder facilement à l'ARRIÈRE. Découper avec précaution les trous nécessaires. www.sauder.com/service 427465 Page 39...
  • Page 40 PORTES. et coller sur chaque EXCENTRIQUE ESCAMOTABLE visible. REMARQUE :Prière de lire les informations importantes sur la sécurité fi gurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer avec un tissu humide. Essuyer. Page 40 427465 www.sauder.com/service...
  • Page 41 107M CARRIL DE LA PUERTA ............1 PARAL ..................... 2 necesita ponerse en 155M BARRA DE RETENCIÓN ............ 4 contacto con Sauder en ESTANTE AJUSTABLE ............6 cuanto a esta unidad, 183M SOPORTE DE LA RUEDA ..........4 PATA ....................4 refi...
  • Page 42 Fije las otras PATAS (E) al EXTREMO IZQUIERDO (B). Apriete abajo - antes de comenzar el ensamblaje! cuatro EXCÉNTRICOS ESCONDIDOS. • Esta unidad Sauder está diseñada para ser usada con televisores cuyo peso sea inferior a 31.75 Kg. Nunca la use para un PASO 7 televisor de mayor peso.
  • Page 43 TORNILLOS MARRONES DE CABEZA GRANDE de 11 mm (6S). NOTA: Asegúrese de clavar ligeramente los CLAVOS dentro de los agujeros que se alinean sobre los PARALES (C). NOTA: Hay perforaciones provistas para el acceso a través del DORSO. Cuidadosamente corte los agujeros necesarios. www.sauder.com/service 427465 Page 43...
  • Page 44 EXCÉNTRICO ESCONDIDO visible. NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpiar con un trapo húmedo. Seque con un paño. Page 44 427465 www.sauder.com/service...
  • Page 45 TOUJOURS décharger les tablettes et les tiroirs, en commençant par les surface supérieures, avant de déplacer le meuble. NE JAMAIS pousser ou tirer un meuble sur de la moquette. Demander à une autre personne de le soulever correctement pour le déplacer et/ou le repositionner. www.sauder.com/service 427465 Page 45...
  • Page 46 SIEMPRE descargue los estantes y cajones, empezando con las superfi cies superiores, antes de moverlo. NUNCA empuje ni tire de los muebles sobre una alfombra. Obtenga que un amigo le ayude a levantarlo correctamente para moverlo y/o reposicionarlo. Page 46 427465 www.sauder.com/service...
  • Page 47 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 48 Walmart.com in the product detail page. General Conformity Certifi cate 1. This certifi cate applies to the Sauder Woodworking Product identifi ed by this Instruction Book. 2. This certifi cate applies to compliance of this product with the CPSC Ban on Lead-Containing Paint (16 CFR 1303).
