EAW UB12Se Specifications

FEATURES
• Ultra-compact two-way system
• 5.25-in LF/1-in tweeter
• Magnetically shielded for use with video monitors
• High output, high definition sound from an
ultracompact enclosure
DESCRIPTION
Despite its compact size, the UB12Se will faithfully deliver
high output, high definition sound for a wide variety of pro-
fessional applications. All system elements, including drivers,
crossover/filter components, and the enclosures themselves
are designed to meet EAW's rigorous standards for reliablility
and durability.
The system operates in fully passive mode with an internal
passive crossover/filter network both dividing the signal and
providing critical equalization functions.
UB12Se's are available as matched pairs of left and right side
enclosures for ultimate accuracy in reproducing the audio
imaging. Each UB12Se includes a robust 5.25-in woofer
mounted in an optimally vented enclosure and a 1-in soft
dome tweeter specifically designed to provide smooth, studio-
quality high frequency reproduction.
APPLICATION
As a stand alone system, the UB12Se delivers full range out-
put at surprisingly high levels with flat response for a wide
range of professional audio applications including multimedia
production and presentation, corporate audio/visual systems,
retail spaces, project recording studio, and home theaters.
It is also a popular choice as a secondary distributed rein-
forcement system providing additional coverage in virtually
any large scale installation such as theaters, performing arts
centers, houses of worship and even arenas and stadiums.The
ultra-compact enclosures can be unobtrusively mounted
almost anywhere. The system includes 1/4-in threaded mount-
ing points two of which are configured to accept an
Omnimount Series 50. They are also magnetically shielded for
use in immediate proximity to video monitors making them an
excellent choice for any multimedia application.
Applications include:
MultiMedia Ballroom Events
Restaurants Theaters
PERFORMANCE
Frequency Response (1 Watt @ 1m)
±3 db 98 Hz to 20 kHz
-10 dB 60 Hz
Axial Sensitivity (dB SPL, 1 Watt @ 1m)
Impedance (Ohms)
One Main Street, Whitinsville, MA 01588
EAW products are continually improved. All specifications are therefore subject to change without notice.
Boardrooms
Small Retail
89
8
508 234 6158 Toll Free 800 992 5013
SPECIFICATIONS UB12Se
Power Handling, AES Standard (Watts)
Calculated Maximum Output (dB SPL @ 1m)
Peak 116.5*
Long Term 110.5*
Nominal Coverage Angles, -6 dB Points (degrees)
Conical 120
Recommended High-Pass Frequency
24 dB/Octave 60 Hz
PHYSICAL
Configuration 2-way, full range
Powering Passive LF/HF crossover
LF Subsystem 5.25-in cone, vented
HF Subsystem 1-in soft dome tweeter
Coverage Angles 120° (conical)
Cabinet Type (shape) Rectangular
Enclosure Materials MDF
Finish Black polyurethane
Connectors 2-terminal barrier strip
Suspension Hardware (4) 1/4"-20 threaded mounting
Grille Powder coated perforated steel
Companion Systems
Sub SB48e
Accessories Wall Mount Bracket (HD12WM)
Dimensions
Height 10.75
Width 6.38
Depth 6.00
Weights
Net Weight (each) 10
Shipping Weight (per pair) 23
FAX 508 234 8251
UB12Se-888110(C)/2 pp 5/1/00
140*
points (1 each top and bottom,
2 on "outside" to accept
Omnimount Series 50)
inches millimeters
273
162
152
pounds kilograms
4.6
10.5
