INSTALLATION and OPERATION MANUAL
IMPORTANT!
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notification.
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
BARNES
BARNES
Submersible Sewage Ejector
83 West Drive, Brampton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
®
Series:
3SE-DS, 3HP
(Vertical Discharge)
1750RPM, 60Hz.
3SEH-DS, 3HP
(Horizontal Discharge)
1750RPM, 60Hz.
(Double Seal)
Form No. 133408-Rev. H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Barnes 3SE-DS Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Crane Barnes 3SE-DS Series

Summary of Contents for Crane Barnes 3SE-DS Series

  • Page 1 Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur. As such Crane Pumps & Systems reserves the right to change product without prior written notification. A Crane Co. Company...

  • Page 2: Table Of Contents

    PRESSURE GAUGE KIT (see parts list) Other brand and product names are trademarks or registered trademarks of their respective holders. ® Barnes is a registered trademark of Crane Pumps & Systems, Inc 1996, 1997, 1998, 1999, 2001, 2002, 3/06, 9/06, 2/07...

  • Page 3: Safety First

    WARNING! - DO NOT pump hazardous materials IMPORTANT! - Crane Pumps & Systems, Inc. is not (flammable, caustic, etc.) unless the pump is specifically responsible for losses, injury, or death resulting from a designed and designated to handle them.

  • Page 4: Pump Specifications

    SECTION: A - PUMP SPECIFICATIONS: 1750RPM DISCHARGE ....3” NPT, Vertical 3” Flanged, Horizontal UPPER BEARING: LIQUID TEMPERATURE . 104°F (40°C) Continuous Design ..Single Row, Ball, Oil Lubricated MOTOR HOUSING ..Cast Iron ASTM A-48, Class 30 Load ..... Radial VOLUTE ......

  • Page 5: General Information

    For the location of the nearest CP&S Service Center, check will slide freely down the rails into place on the discharge your CP&S representative or Crane Pumps & Systems, Inc., stationary fitting. Once the rails are in proper alignment, bolt...

  • Page 6: Electrical Data

    C-4) Electrical Connections: C-4.3) Moisture Sensors: C-4.1) Power & Control Cords: A normally open (N/O) detector is installed in the pump The cord assembly mounted to the pump must not be modified seal chamber which will detect any moisture present. It is in any way except for shortening to a specific application.

  • Page 7: Start-Up Operation

    SECTION F: SERVICE AND REPAIR SECTION: D START-UP OPERATION D-1) Check Voltage and Phase: Before operating pump, compare the voltage and phase NOTE: All item numbers in ( ) refer to Figures 12 & 13. information stamped on the pump identification plate to the available power.
  • Page 8 F-2) Impeller and Volute Service: F-2.1) Disassembly and Inspection: To clean out volute (25) disconnect power, remove hex nuts (19), and lock washers (18), vertically lift motor and seal plate assembly from volute (25). Clean out volute if necessary. Clean and examine impeller (27), for pitting or wear and replace if required, inspect square ring (36) and replace if cut or damaged.
  • Page 9 Check motor capacitor (3, 1 phase units) with an Ohm meter by first grounding the capacitor by placing a screwdriver across both terminals and then removing screwdriver. Connect Ohm meter (set on high scale) to terminals. If needle moves to infinity (∞) then drifts back, the capacitor is good. If needle does not move or moves to infinity (∞) and does not drift back, replace capacitor (3).
  • Page 10 that it will lay on the opposite side of the cord entry bosses Reconnect motor and control leads to the underside of the of the motor housing (2). Reconnect capacitor leads. Torque terminal block(s) (21), (26) as shown in Figures 5 and 11. motor tie bolts to 22 in-lbs.

  • Page 11: Replacement Parts

    Seal - To expose shaft seal (38) for examination, complete Make sure driving lugs in retainer are matched in rotating above procedure and slide off outboard rotating member member. Place spring (38C) over shaft and in place on (38B) (see Figure 7). Remove inboard rotating member rotating member (38E), making sure it is seated in retainer (38D), from shaft.

  • Page 12: Wiring Schematics

    FIGURE 11...

  • Page 13: Trouble Shooting

    TROUBLE SHOOTING CAUTION ! Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. If operating problems persist, the following chart may be of assistance in identifying and correcting them: MATCH “CAUSE”...

  • Page 14: Cross-Section 3Se-Ds 1750Rpm (Fig. 12)

    CROSS SECTION OIL LEVEL 30 48 FIGURE 12...

  • Page 15: Exploded View 3Se-Ds 1750Rpm (Fig. 13)

    EXPLODED VIEW FIGURE 13...

  • Page 16: Parts List 3Se-Ds 1750Rpm

    PARTS KITS Seal Repair Kits Double Seal..P/N - 130178 (†) 8, 31, 36, 38 Service Kits Double Seal..P/N - 130174 (♦) 8, 11, 16, 22, 28, 29, 31, 32, 33, 36, 38, 39, 51 Seal Tool Kit....P/N-085736 Pressure Gauge Kit...P/N-085343 PARTS LIST ITEM PART NO.
  • Page 17 PARTS LIST CONT. ITEM PART NO. DESCRIPTION NOTES 066130 ♦ Retaining Ring 057882 ♦ Retaining Ring 003217 Pipe Plug ZP (when Item 17 not used) 022873 †♦ Diaphragm Buna-N 059186 ♦ Shaft Key 3/16 Sq x 1” LG, SS 038132 ♦...
  • Page 18 Notes...

  • Page 19: Warranty

    Limited 24 Month Warranty Crane Pumps & Systems warrants that products of our manufacture will be free of defects in material and workmanship under normal use and service for twenty-four (24) months after manufacture date, when installed and maintained in accordance with our instructions.This warranty gives you specifi c legal rights, and there may also be other rights which vary from state to state.

  • Page 20: Warranty Registration

    Crane Pumps & Systems, Inc. Distributor. RETURNED GOODS RETURN OF MERCHANDISE REQUIRES A “RETURNED GOODS AUTHORIZATION”. CONTACT YOUR LOCAL CRANE PUMPS & SYSTEMS, INC. DISTRIBUTOR. Products Returned Must Be Cleaned, Sanitized, Or Decontaminated As Necessary Prior To Shipment, To Insure That Employees Will Not Be Exposed To Health Hazards In Handling Said Material.
