- Page 1 INSTALLATION + USER √ Instructions Thule Single Step V15 309968 / 309969 Bring your life OSE900-04 |3380025900 thule.com 2021-03-24...
- Page 3 Trittstufen - Bedienungsanleitung STEP - USER INSTRUCTIONS Opstraptrede - Gebruikershandleiding Marchepieds - Instructions d'utilisation Gradini - Istruzioni per l'uso Safety Escalones - Instrucciones de uso Fotsteg - Användarmanual Astinlaudat - Käyttöohje Trapper - Brugervejledning Trapper - Brukerinstruksjoner Stopnie - Instrukcja dla użytkownika WARNINGS &...
- Page 4 1 WARNINGS & INFO Instructions Safety Instructions Safety OSE900-04...
- Page 5 2 CONTENT M8 x 50 mm DIN 125 DIN 933 DIN 985 2,9 x 9,5 mm F4,8 x 0,8 mm DIN 7981 - TX10 3 TOOLS TX10 N° 13 Ø 9mm Ø 48mm OSE900-04...
-
Page 6: Installation
4 INSTALLATION Thule Single Step 550 (460) 10/23 43/51,5 69,5/78 135,5/137,5 156,5/165 190/203 200-300 mm Max! 400 mm EN 1645-1 EN 1646-1 OSE900-04... - Page 7 N° 13 Ø 9mm OSE900-04...
-
Page 8: Electrical Installation
5 ELECTRICAL INSTALLATION orange ORANGE/ORANGE/ ORANJE/ORANGE/ purple ARANCIA/NARANJA/ ORANGE/ORANSSI/ Sec. ORANGE/ORANSJE/ POMARAŃCZOWY PURPLE/LILA/PAARS/ VIOLET/VIOLA/ MORADO/LILA/ VIOLETTI/LILLA/ orange LILLA/FIOLETOWY purple Sec. Ø 48mm TX10 OSE900-04... - Page 9 THULE STEP with WARNING LAMP (or BUZZER) Dashboard START Key S3 START Step S2 grey Switch S1 brown orange purple 2.5 mm F 20A Battery 12V DC (main) ORANGE/ORANGE/ PURPLE/LILA/PAARS/ ORANJE/ORANGE/ VIOLET/VIOLA/ ARANCIA/NARANJA/ MORADO/LILA/ ORANGE/ORANSSI/ VIOLETTI/LILLA/ ORANGE/ORANSJE/ LILLA/FIOLETOWY POMARAŃCZOWY BROWN/BRAUN/...
- Page 10 THULE STEP with OPTIONAL RELAY (308200) for AUTOMATIC RETRACTION Dashboard START Key S3 START Capacity 2200µF Step S2 grey Relay brown orange Switch S1 purple 2.5 mm F 20A Battery 12V DC (main) ORANGE/ORANGE/ PURPLE/LILA/PAARS/ ORANJE/ORANGE/ VIOLET/VIOLA/ ARANCIA/NARANJA/ MORADO/LILA/ ORANGE/ORANSSI/...
-
Page 11: Open & Close
6 OPEN & CLOSE Sec. Sec. 7 MANUAL RELEASE OSE900-04... - Page 12 Thule NV, Kortrijkstraat 343 – BE 8930 Menen, BELGIUM infoRV@thule.com www.thule.com OSE900-04 © Thule Group 2020. All rights reserved.
