- Page 1 Goliath Crimper Rollers OWNER'S MANUAL For Model: 6',8',10.5' Crimpers...
- Page 2 Model Specification Main Dimension Model Approx. weight Drum Width(A) Length(B) Height Depth 72" 76.9" 36.1" 35.9" 1158 lbs 96" 100.7" 36.1" 35.9" 1445 lbs 10.5' 126" 130.7" 36.1" 35.9" 1820 lbs PS. 75 lbs per foot when filling with water.
-
Page 3: Safety Introduction
SAFETY INTRODUCTION Your safety, and the safety of others, is ver y important. To help you make informed decisions about safety, we have provided operating procedures and other information in this manual. This information alerts you to potential hazards that could hurt you or others. You will find important safety information in the following form: Safety Messages –... - Page 4 OPERATIONS AND MAINTENENCE This safety alert symbol is used to indicate safety instructions. Follow these instructions to avoid personal injur y and/or property damage. Read and follow all instruction in the manual. CAUTION: Do not allow anyone to operate this equipment who has not fully read and comprehended the safety manual and who has not been properly trained in operation of the equipment.
- Page 5 Main Frame (for filling water into the drum) Weed Guard Roller Drum 3-Hole Plate (for installing on Tractors) Stand Cover crop roller description...
- Page 6 OPERATIONS AND MAINTENENCE How to disassemble to grease? Step 1: Place the tool on an even ground, ensure the (2) support function correctly. Step 2: Grease the bearing from the nipple on both sides of the crimpers.
-
Page 7: Model Parts
MODEL PARTS For 6's Model ITEM Part # Description Quantity 600-0001-01 Main Frame Assembly 600-0002-01 Roller Drum 600-0001-02 BallBearing 600-0001-04 Weed Guard 600-0001-05 Flat Washer 600-0001-06 Bolt 600-0001-07 Nut for bearings 600-0002-02 Nut on Drum 600-0002-03 Rubber washer for drum 600-0001-03 Stand 600-0001-08... - Page 8 MODEL PARTS For 10.5's Model ITEM Part # Description Quantity 105-0001-01 Main Frame Assembly 105-0002-01 Roller Drum 600-0001-02 BallBearing 600-0001-04 Weed Guard 600-0001-05 Flat Washer 600-0001-06 Bolt 600-0001-07 Nut for bearings 600-0002-02 Nut on Drum 600-0002-03 Rubber washer for drum 600-0001-03 Stand 600-0001-08...
- Page 9 MODEL PARTS...
