BUNNEspress
®
ES•1AF
ES•1AF
DISCONTINUED VERSION
The information in this manual
is no longer current.
2
C L
OPERATING & SERVICE MANUAL
Designs, materials, weights, specifications, and dimensions for equipment or replacement parts are subject to
change without notice.
BUNN-O-MATIC CORPORATION
POST OFFICE BOX 3227
SPRINGFIELD, ILLINOIS 62708-3227
PHONE: (217) 529-6601 FAX: (217) 529-6644
26691.0000C 6/97 ©1995 Bunn-O-Matic Corporation
Advertisement
Table of Contents
Related Manuals for Bunn BUNNEspress ES.1AF
Summary of Contents for Bunn BUNNEspress ES.1AF
- Page 1 OPERATING & SERVICE MANUAL Designs, materials, weights, specifications, and dimensions for equipment or replacement parts are subject to change without notice. BUNN-O-MATIC CORPORATION POST OFFICE BOX 3227 SPRINGFIELD, ILLINOIS 62708-3227 PHONE: (217) 529-6601 FAX: (217) 529-6644 26691.0000C 6/97 ©1995 Bunn-O-Matic Corporation...
-
Page 2: Table Of Contents
The Buyer shall give Bunn prompt notice of any claim to be made under this warranty by telephone at (217) 529- 6601 or by writing to Post Office Box 3227, Springfield, Illinois, 62708-3227. If requested by Bunn, the Buyer shall ship the defective equipment prepaid to an authorized Bunn service location. -
Page 3: User Notices
READ THE ENTIRE OPERATING MANUAL INCLUDING THE LIMIT OF WARRANTY AND LIABILITY BEFORE BUYING OR USING THIS PRODUCT 00986.0000C 3/94 © 1994 Bunn-O-Matic Corporation 26602.0000 WARNING HAZARDOUS U N P L U G B R E W E R B E F O R E R E M O V I N G ! 1. -
Page 4: Site Requirements
NOTE-Bunn-O-Matic recommends .375” copper tubing for no more than 25 feet from the .5” water supply line. Bunn-O-Matic does not recommend the use of a saddle valve to install the brewer. The size and shape of the hole made in the supply line by this type of device may restrict water flow. -
Page 5: Installation
BUNN Espress® PLUMBING Install the brewer as indicated below: 1. Inlet Hose 2. Strainer Assy. 3. Filter/Softener 4. Water Supply Hose 5. Drain Hose 6. Drain Cup NOTE: For cart applications, unit will function with inlet hose suspended into a container of water. Be sure not to run the container dry, damage to the pump will occur. -
Page 6: Operating Controls
OPERATING CONTROLS BUNN Espress® O N O N O F F O F F 0, 5 0, 5 1, 5 1, 5 2, 5 2, 5 12 12 16 16 ON/OFF Toggle Switch Power LED Pressure Gauge Stop Button Tall/Short Button & LEDS Cappuccino Button &... -
Page 7: Adjustments
BUNN Espress® INFUSION Water The brewer is factory set to yield these approximate amounts of water: Short Coffee Volume - 1.5 oz (44 cc) Tall Coffee Volume - 1.8 oz (53 cc) To change the factory set amounts: 1. Place the program switch in the “Program” (right) position. The program switch is located behind the switch/LED panel. -
Page 8: Operation
1. The use of a damp cloth rinsed in any mild, non-abrasive, liquid detergent is recommended for cleaning all surfaces on Bunn-O-Matic equipment. 2. Clean the gasket that seals the filter & group head, located under the group head. Ground coffee build- up on this gasket will result in a bad seal of the filter holder, and will leak brewed coffee onto the outside of the filter holder when brewing. - Page 9 BUNN Espress® Milk Frother NOTE- The milk frother parts need to be cleaned as described below at least every four to six hours depending upon use. See the DBC instruction manual for changing the clean warning alarm. It is factory set at 25 drinks.
-
Page 10: Brewing Tips
BUNN Espress® GENERAL Good espresso is identified by its taste, aroma, and the manner in which it is served. All of these elements can be improved-upon to serve your customers a better product. BEAN SELECTION The selection of a blend of coffee is a matter of personal choice. A blend with a high proportion of Central and/ or South American beans results in a beverage with a soft and agreeable flavor. -
Page 11: Alarms
BUNN Espress® PROBLEMS When a fault occurs the following will happen: Fault 1 will appear on DBC screen. Power light will flash once every three seconds. This means a flowmeter error. Water is not flowing thru the flowmeter Fault 2 will appear on DBC screen. -
Page 12: Wiring Diagram
J3-17 J3-19 J3-21 J3-23 J3-25 J3-27 J3-29 J3-31 J3-33 V I O J3-35 J3-37 J3-39 26564.0000B 11/95 © 1995 BUNN-O-MATIC CORPORATION WIRING DIAGRAM PRESSURE L I M I T SWITCH T'STAT K-N.O. HOT WATER BREW WHI WHI PUMP PRIMARY SECONDARY...
