UNILITE HX1500R Quick Start Manual

FEATURES
• High quality 1500 lumen 15W white COB LED, 6500K
• Additional 500 lumen 5W SMD LED spot beam, 6500K
• Ultra tough nylon-polymer & aluminium construction
• 180° rotating stand with super strong magnetic base
• IP65 dust & water resistant
• IK07 shock proof - 2m drop resistant
• Operating temperature -20°C to +50°C
• High power 5200mAh lithium battery
• Battery level and charging indicator lights
• Fast 2A USB-C charging - 1m cable included
BATTERY - 3.7v 5200mAh Li-ion Rechargeable Battery
WEIGHT - 400g
DIMENSIONS - 116 x 101 x 41.5mm
ADVICE & IMPORTANT INFORMATION!
Do not look directly at the LED. Do not operate in direct sunlight or extreme
temperature conditions (below -20°C or above 50°C).
LEDs will become warm/hot when switched on; do not touch and never place
LEDs face down on any surface – risk of fire!
Do not use the device if there is any visible damage to the housing, lens, switch,
charge port or cable. Take care when using a USB plug adaptor, check for any
damage. DO NOT exceed 5V 2A charging input or damage may occur to the
rechargeable battery.
The rechargeable battery will reach full performance after a few complete
charging and discharging cycles.
To keep the rechargeable battery in optimum condition, it should be recharged
every 3-6 months, especially if it is not being used for a long period of time.
Always fully charge batteries before storage.
Always protect batteries from heat, intense sunlight, fire, water and moisture –
danger of explosion!
If a battery is damaged, fluids can leak out. AVOID contact as this can lead to
skin irritation and/or burns. If skin contact occurs, rinse thoroughly with water.
If irritation persists, seek medical advice. Seek immediate medical assistance if
battery fluid comes into contact with the eyes.
Children under 12 years of age should only use the product under adult
supervision.
Do not open, disassemble or attempt to modify the product; this will void the
warranty and can be dangerous. Improper use or modification is not covered
under the warranty.
Take care not to let the lenses come into contact with hard/sharp objects,
damage/scratches to the lenses will affect light output.
This product is water resistant to IPX5 – DO NOT SUBMERGE. If the product has
been subjected to excessive water the warranty may be void.
This product has a 1 year standard warranty (or extended 2 years once registered
online at WWW.UNILITE.CO.UK/WARRANTY) against manufacturing faults
and defects. It does not cover normal wear and tear, modifications, accidental
damage or poor maintenance. Unilite warranties do not cover battery leaks
or the use of incorrect chargers and cables that can damage rechargeable
batteries.
Do not dispose of this device in normal household waste. It must be disposed
of via an authorised electrical appliance disposal centre or at your local waste
disposal unit.
Please re-use or recycle packaging where possible.
Keep these instructions for future reference or for subsequent possessors.
www.unilite.co.uk
ANSI F L 1 Standard
FLOOD LIGHT - HIGH
FLOOD LIGHT - MID
FLOOD LIGHT - LOW
SPOT BEAM
OPERATION
REAR SWITCH Sequence:- Spot Beam > Floodlight Low >
Floodlight Medium > Floodlight High > Off
MEMORY FUNCTION:- If left ON in any mode for 5 seconds or
more, the next press will turn OFF. Next press ON will return to that
last mode used.
SMD LED
COB LED
Super Strong Magnet
CHARGING
1. Only use a 5V USB-C cable (max 2A).
2. Lift the charging port cover on the back of the lamp.
3. Plug the USB-C end of the cable into the charge port.
4. Plug the USB-A end of the cable into a USB charging port.
(do not exceed 5V 2A charging input or damage may occur)
5. 3 x Green LEDs will flash to indicate charging. Once fully
charged all 3 LEDs will light up constantly.
6. Charge Time: 4 hours (charged by 2A)
(PRODUCT CAN BE USED WHILE RECHARGING, HOWEVER
BRIGHTNESS MAY DECREASE)
*Warranty void if not used with the specified cable & max charge
input*
HX1500R
1500
48 M
Lumens
800
36 M
Lumens
400
23 M
Lumens
500
37 M8
Lumens
Super Robust
Nylon Polymer & Rubber
Super Robust Battery Level &
Aluminium Back Charge Indicators
Stand
Rotates 180°
Stand
Rotates 180°
Super Strong Magnet
2 H
5 H
10 H
H
ON/OFF
Switch
Charge
Port
