UNILITE HX1500R Quick Start Manual

FEATURES
• High quality 1500 lumen 15W white COB LED, 6500K
• Additional 500 lumen 5W SMD LED spot beam, 6500K
• Ultra tough nylon-polymer construction
• 180° rotating stand with super strong magnetic base
• IP65 dust & water resistant
• IK07 shock proof - 2m drop resistant
• Operating temperature -20°C to +50°C
• High power 5200mAh lithium battery
• Battery level and charging indicator lights
• USB type-C rechargeable - 1m cable included
BATTERY - 3.7v 5200mAh Li-ion Rechargeable Battery
WEIGHT - 400g
DIMENSIONS - 116 x 101 x 41.5mm
ADVICE & IMPORTANT INFORMATION!
Do not look directly at the LEDs. Do not operate in direct sunlight or extreme temperature conditions (below -20⁰C or above 50⁰C). The LED will become hot when switched on; do not touch and do not place face down on
any surface – risk of fire!
Do not use the device if there is any visible damage to the housing, switch, charge port or cable. Take care when using a USB plug adaptor, check for any damage. Do not exceed 2A output or damage may occur to the
battery.
Children under 12 years of age should only use the product under adult supervision.
Do not open, disassemble or attempt to modify the product; this will void the warranty and can be dangerous. Improper use or modification is not covered under the warranty.
Take care not to let the lens come into contact with hard/sharp objects, damage to the lens will affect light output.
This product is water resistant to IPX5 – DO NOT SUBMERGE. If the product has been subjected to excessive moisture/water the warranty may be void.
The rechargeable battery will reach full performance after a few complete charging and discharging cycles.
To keep the rechargeable battery in optimum condition, it should be recharged every 3-6 months, especially if it is not being used for a long time. Always fully charge batteries before storage.
Protect batteries from heat, intense sunlight, fire, water and moisture – danger of explosion!
If a battery is damaged, fluids can leak out. AVOID contact as this can lead to skin irritation and/or burns. If skin contact occurs, rinse thoroughly with water. If irritation persists, seek medical advice. Seek immediate medical
assistance if battery fluid comes into contact with the eyes.
Do not dispose of this device in normal household waste. It must be disposed of via an authorised disposal centre or at your local waste disposal unit.
Please re-use or recycle packaging where possible.
Keep these instructions for future reference or for subsequent possessors.
WWW.UNILITE.CO.UK
ANSI FL 1 Standard
FLOOD LIGHT - HIGH
FLOOD LIGHT - MED
FLOOD LIGHT - LOW
SPOT BEAM
OPERATION
REAR SWITCH SEQUENCE:- Spot Beam > Floodlight Low >
Floodlight Medium > Floodlight High > Off
MEMORY FUNCTION:- If left ON in any mode for 5 seconds or more, the
next press will turn OFF. Next press ON will return to that last mode used.
CHARGING
1. Only use a USB-type-C 5v cable (1m cable included).
2. Lift the charge port cover on the back of the light.
3. Plug the USB-C end of the cable into the charge port.
4. Plug the USB end of the cable into any USB charging port
(for USB plug adaptors, only use 5V with max 2A output).
5. 3 x Green LEDs will flash to indicate charging.
Once fully charged all 3 LEDs will light up constantly.
6. Charge Time: 4 hours
(PRODUCT CAN BE USED WHILE RECHARGING)
**Warranty void if not used with the specified chargers**
Super Robust
Nylon Polymer & Rubber
SMD LED
COB LED
Super Strong Magnet
1500
Lumens
800
Lumens
400
Lumens
500
Lumens
Super Robust
Aluminium Back
Stand
Stand
Rotates 180°
Rotates 180°
Super Strong Magnet
HX1500R
48 M 2½ H
36 M 5 H
23 M 10 H
37 M 8 H
Battery Level &
Charge Indicators
ON/OFF
Switch
Charge
Port
