- Page 1 SCWT14WQ*1K Owners Manual SCWT™ Series Barrier-Free Water Cooler PAGE 1 98702C (Rev. D - 04/16)
- Page 2 SCWT14WQ*1K Note: Danger! Electric shock hazard. Disconnect power before servicing unit. USES HFC-134A REFRIGERANT 2, 30 - SEE FIG.5 5, 6 3, 4 SEE FIG.4 15, 28, 29 12,13,14, 34, 35 FIG. 1 PAGE 2 98702C (Rev. D - 04/16)
- Page 3 SCWT14WQ*1K PAGE 3 98702C (Rev. D - 04/16)
-
Page 4: Wiring Diagram
SCWT14WQ*1K PUSH BUTTON VALVE ADJUSTMENT STREAM HEIGHT ADJUSTMENT SCREW ADJUST THIS SCREW TO ELIMINATE VALVE LEVER "FREE PLAY" OR CONTINUOUS FLOW FROM BUBBLER FIG. 3 1,20,24 FIG. 4 WIRING DIAGRAM This drawing is merely for illustrating the components of the electrical system. CORRECT STREAM HEIGHT FIG. - Page 5 SCWT14WQ*1K ITEMIZED PARTS LIST CONDENSER WATER VALVE ADJUSTMENT ITEM NO. PART NO. DESCRIPTION 15005C Nut-Regulator Retaining 51544C Bubbler The condenser water valve is factory preset for a 101507531550 Push Button Stem condenser water outlet temperature of 95° to 105° F. 101453431640 Cap Push Button If actual temperature varies greatly from this, readjust water...
