MAKER MADE Standard Frame Setup Manual page 9

Frame legs (continued)
8. Position the top beam on the legs, with the taller side of the stud mounts flush with the 70in
line.
Repeat the process of step 7, by centering the top and bottom holes of the stud mount on the
perpendicular line and attaching with the
2in long wood screw
9. To attach the horizontal frame legs, write back on the ends of the 2in x 4in x 3ft boards. Align
the back end on the inside of the vertical frame legs at a 90 degree angle to make an L shape.
Use the speed square to ensure the 90 angle is square and flush with the back of the vertical
frame legs. Use three
2in long wood screw
3ft
Side view
76.75in
70in
long wood screws
3ft
long wood screws.
in a triangle to attach each leg together.
Isometric
view
70in
Front view
9
