ASSEMBLING THE STANDARD FRAME
The biggest step to starting your M2 CNC adventure is to build the frame that will
hold your material and the M2 while it cuts. The M2 mounts for your frame are
included, but you will need to purchase the following from a local hardware store
to build the standard frame to cut 4ft x 8ft.
Drew's Note: We recommend reading this entire section before beginning.
10ft Standard Frame - Materials Needed
Amount Needed
2
2
4
2
4
1 (a second one is
optional)
2 (optional)
Drew's Note: Nearly every step uses
wood screws. So, I'm going to leave the bag picture out of the
steps for redundancy's sake. Just know that you'll need a lot
of short and long wood screws are from Bags C and D (and
some extras). If you're experienced with woodworking, feel
free to use any wood screw of your choice to build the frame.
Type
2in x 4in x 10ft
2in x 4in x 8ft
2in x 4in x 4ft
2in x 4in x 3ft
24in x 48in x 5/8in
Particle Board (1/2in thick
particle board, MDF, or
plywood will also work)
1in x 6in x 8ft
1in x 6in x 4ft
short (1.5in) or long (2in)
Purpose
Top and Bottom Beams
Vertical Frame Legs
Canvas Legs
Horizontal Frame Legs
Canvas Wasteboards
Bottom Skirt and
optional top skirt (see
Part 6)
Side Skirts (Cut a 1in x
6in x 8ft in two, if not
available in your area,
see Part 6)
Short/Long frame mounting screws
Bag C and Bag D
Tools for Tools for M2
Building operation
the frame
Wrench Router
Hammer Dust Collection
System
Phillips 2 Standard (4-
Screwdriver 5lb) Sized Bricks
Drill / Impact 2+ Clamps
Driver
Tape Measure Material to Cut
Speed Square
Level
Pencil
Extra 1.5in and
2in screws
