Table Of Contents - MAKER MADE Standard Frame Setup Manual

TABLE OF CONTENTS

SECTION 1. Intro - 3
SECTION 2. Materials Needed - 4
SECTION 3. Building the Standard Frame
Building the canvas - 5
Attaching the motors - 6
Attaching the stud mounts - 7
Frame legs - 8
Attaching the canvas frame - 10
Leveling your frame -11
Optional skirts - 12
Attaching the chains - 13
Mounting the M2 to your frame - 14
Arduino DUE and shield - 15
SECTION 4. Appendices
Tips and warnings - 16
What's in the box? - 17
Standard Frame Dimensions - 19
Custom Frame Tips - 20
2
