This product can be set up using any current
web browser, i.e., Internet Explorer 6x,
Netscape Navigator 7x.
Before You Begin
1. If you purchased this router to share your high-speed Internet connection with other
computers, you must have either an Ethernet-based Cable or a DSL modem with
an established Internet account from an Internet Service Provider (ISP).
2. It's best to use the same computer that is connected to your modem for configuring
the DI-604+ router. The DI-604+ Broadband Router acts as a DHCP server and
will assign all the necessary IP address information on your network. See
Appendix at the end of this Quick Installation Guide or the Manual on the
CD-ROM for setting each network adapter to automatically obtain an IP
address.
Check Your Package Contents
These are the items included with your DI-604+ purchase:
If any of the above items are missing, please contact your reseller.
©2005 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective
holders. Software and specifications subject to change without notice.
• DI-604+ Broadband Router
• CD-ROM (containing Manual and Warranty)
• Ethernet (CAT5 UTP/Straight-Through) Cable
• 5V DC, 1.2 A Power Adapter
DI-604+
Express EtherNetwork™
Broadband Router
Using a power
supply with a
different voltage rating
will damage and void
the warranty for this
product.
Advertisement
Related Manuals for D-Link Express EtherNetwork DI-604+
Summary of Contents for D-Link Express EtherNetwork DI-604+
- Page 1 If any of the above items are missing, please contact your reseller. ©2005 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and specifications subject to change without notice.
-
Page 2: Restart Your Computer
Connecting The DI-604+ Broadband Router To Your Network First, connect the power adapter to the receptor at the back panel of the DI- 604+ and then plug the other end of the power adapter to a wall outlet or power strip. - Page 3 Connecting Additional Devices to the DI-604+ Broadband Router Using additional Ethernet (CAT5 UTP/Straight-Through) cables, connect your Ethernet-equipped computer(s) to one of the 3 remaining Ethernet LAN ports on the back panel of the DI-604+. LAN Port LEDs. Each of the LAN ports on the back of the DI-604+ have a corresponding LED light on the front panel of the unit.
- Page 4 The DI-604+ offers two easy-to-use methods to set up and manage the Router. The first, the D-Link Click’n Connect DWizard, is a stand-alone configuration utility located on the CD-ROM that came with your DI-604+. This method is described briefly below.
- Page 5 Click Next on the window above and follow the on-screen prompts to Connect the device to the computer, Connect the device to the Internet, Check device connectivity, Set your ISP, Set wireless configuration, Check your Internet connection status, ISP configuration, etc. When you have completed the Router configuration, click the Exit button on the final Congratulations window displayed below.
-
Page 6: Using The Setup Wizard
Using The Setup Wizard Open your Web browser and type “http://192.168.0.1” into the URL address box. Then press the Enter or Return key. The logon pop-up screen will appear. Type “admin” the username and leave the password field blank. Click Once you have logged in, the Home screen will appear. - Page 7 You will see the following screens. Click Next Step 1 - Set up your new password. You have the option to establish a password. Click Next Step 2 - Choose your time zone. Click Next...
- Page 8 The Setup Wizard (continued) Select the type of Internet connection for your router. Select one of these settings If you are unsure of which setting to select, please contact your Internet Service Provider. Click Next If you selected Dynamic IP Address, this screen will appear: “Clone MAC Address”...
- Page 9 If your ISP requires a Static IP Address, and this option is selected, then this screen will appear: Enter the IP address information originally provided to you by your ISP. You will need to complete all the required fields. Click Next If your ISP uses PPPoE...
- Page 10 If your ISP uses PPTP and this option is selected, then this screen will appear. Enter the IP address information originally provided to you by your ISP. Click Next If your ISP uses L2PT and this option is selected, then this screen will appear. Enter the IP address information originally provided to you by your...
- Page 11 If your ISP is Big Pond Cable and this option is selected, then this screen will appear. Enter in the username and password provided to you by your ISP and retype that same password to verify it. Click Next...
- Page 12 Your Setup is Complete! Click Restart Click Continue You will be returned to the Home tab.
-
Page 13: Test Your Internet Connection
Test Your Internet Connection Click Exit Relaunch your Web browser (i.e., Internet Explorer or Netscape Navigator), to link to your favorite Web site to test your Internet connection. For additional settings or information, refer to the Advanced, Tools, or Status tabs on the web-management interface;... - Page 14 Microsoft Windows XP: Go to Start > right click on My Network Places > select Properties > Double-click on the Network Connection associated with the Ethernet adapter (i.e., D-Link DFE-530TX+). Click Internet Protocol (TCP/IP) Click Properties Select Obtain an IP address...
- Page 15 Apple Macintosh OS X: Go to the Apple Menu and Select System Click on Preferences. Network Select Built-in Ethernet in the Show pull-down menu Select Using DHCP in the Configure pull- down menu Click on Apply Now The IP address information, the Subnet Mask, the Router’s IP address and the Ethernet adapter address will appear.
