Summary of Contents for Carbatec WL-B440P
-
Page 2: Table Of Contents
Indexing /Spindle Lock..........................10 Maintenance............................10 Electrical Requirements........................11 Wiring Diagram.............................12 Troubleshooting............................13 Explosion Diagram..........................14 Parts List...............................15 Specifi cations Model Number M305 WL-B440P Swing Over Bed 305mm Swing Over Tool Rest Base 240mm Working Distance Between Centers 406mm Motor 1/2HP, 230V/50Hz Speeds Speed Ranges... -
Page 5: Installing Spindle Lock
Installing Spindle Lock Locate the spindle lock assembly from the Spindle lock carton, and install it onto the headstock with an adjustable wrench. (See Fig.02) Warning: Disengage the spindle lock before turning the machine on. Fig.02 Attaching Spur Center On The Headstock Headstock spindle Insert spur center, with a No. -
Page 6: Installing The Faceplate
Installing The Faceplate to the Headstock Spindle lock Thread the faceplate clockwise on to the headstock spindle. Engage the spindle lock Faceplate and stop the spindle from turning. Tighten the faceplate with the supplied wrench. (See Fig.07) Warning: Disengage spindle lock before turning the machine on. -
Page 7: Adjusting The Tailstock
Adjusting Tailstock Loosen the locking lever to move the tailstock along the lathe bed to the desired position. Tighten the lever. To adjust clamping action of the tailstock, remove it from the lathe bed and adjust the nut clockwise to tighten and counterclockwise to loosen.(See Fig.12) To adjust the tailstock arm in or out, loosen the Fig.12... -
Page 8: Indexing/Spindle Lock
The lathe can be set up for a faceplate turning operation. The work piece should be “rough cut” as close as possible to fi nished shape before mounting. (See Fig.16) Indexing/Spindle Lock The dual purpose indexing/spindle lock is positioned on the top of the headstock for ease Fig.16 of use. -
Page 9: Electrical Requirements
Eletrical Requirements In the event of a malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This tool is equipped with an electric cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into a matching outlet that is properly installed and grounded in accordance with all local codes and ordinances. -
Page 10: Troubleshooting
Troubleshooting WARNING FOR YOUR OWN SAFETY, ALWAYS TURN OFF AND UNPLUG THE MACHINE BEFORE CARRYING OUT ANY TROUBLESHOOTING. Symptom Possible Cause Solution Motor will not start Machine no plugged in Plug the machine in Low voltage Loose connection Motor overheats Motor overloaded Reduce load on motor Air fl... -
Page 11: Explosion Diagram
Explosion Diagram Exploded Diagram... -
Page 12: Parts List
Parts List Part No. Description Part No. Description Center point Clamp disc Spur center Lock nut M10 Faceplate Live center Spindle shaft Axle sleeve Bearing 6005-2Z Lock shaft Ring retaining 47mm Bolt Indexing gear Ring retaining Headstock Washer 14mm Undee washer 47mm Tailstock Ring retaining 25mm Handwheel... - Page 13 Tools & Machinery Maxis Distribution Pty Ltd ABN 93 605 273 989 info@maxis.com.au Phone: 1300 767 366 International: +61 7 3292 0392 128 Ingleston Road, Wakerley Queensland Australia 4154 www.maxis.com.au © Maxis Distribution Pty Ltd 2016...
