3
Installing the SV-INTERCOM-S2
This section provides information for the mechanical and electrical installation of the SV-
INTERCOM-S2.
3.1
Mechanical Installation
The SV-COM-PANEL mounts directly to the instrument panel in either a vertical or horizontal
configuration (see
Figure 1
Figure 3
as a guide to prepare, drill, and cut the instrument panel for the SV-INTERCOM-S2
module. Fasten the module to the instrument panel using the included screws to anchor nuts
installed behind the panel (see
using standard #6-32 lock nuts is acceptable.
Do not use
Do not rivet the SV-INTERCOM-2S directly to the aircraft as this will hinder
future removal if necessary.
The SV-INTERCOM-2S kit includes #6-32 hex-drive round head fasteners.
Fasteners are 5/8" in length and require a 5/64" hex drive tool.
Page | 6
and
Figure 2
for reference). Use
Figure 3
Figure 3
as a template to cut instrument panel.
Figure 3: Panel Cut-Out Dimensions (Not to Scale)
Figure 4
for specification). If access behind the panel allows it,
SV-INTERCOM-2S - Installation and User Guide, Revision B
for space planning and use
