INTERCOM
SKYVIEW PIN #
PIN #
SV-COM-T25/T8 #1:
D15, Pin 15
SV-COM-T25/T8 #2:
D15, Pin 15
12
SV-COM-425 #1:
D15, Pin 5
SV-COM-425#2:
D15, Pin 5
13
SV-COM-T25/T8 #1:
D15, Pin 2
14
SV-COM-425 #1:
D15, Pin 10
SV-COM-T25/T8 #2:
D15, Pin 23
15
SV-COM-425 #2:
D15, Pin 1
16
17
18
Display Unit:
19
D37, Pin 13
Display Unit:
20
D37, Pin 30
21
22
23
24
SV-COM-T25/T8 #1:
D15, Pin 23
25
SV-COM-425 #1:
D15, Pin 1
SV-INTERCOM-2S - Installation and User Guide, Revision B
INTERCOM FUNCTION
Radio PTT
N/A Power In
Radio 1 Audio Input
Radio 2 Microphone
Output
N/A Copilot Mic PTT
N/A Aux Non-Muting Input
N/A Music Lo
SkyView Audio, Left
SkyView Ground
N/A Copilot Headphones Right
N/A Pilot Headphones Right
N/A Pilot Microphone
N/A Music In, Left
Radio 1 Microphone
Output
ADDITIONAL INFORMATION
For dual COM radio installations, connect this
pin to the output of an externally mounted
COM control switch. Connect the switch
inputs to the COM 1 and COM 2 PTT outputs.
Connects to COM radio #1 audio output.
Connects to aircraft radio #2 MIC input.
This mono audio signal does not mute when
audio signals are received on other inputs.
Use this input for critical audio signals such as
a NAV radio or avionics alerts.
Used exclusively for stereo audio ground.
Should not be used for other ground
connections.
This is left channel of the stereo non-muting
input, typically used to receive audio from
SkyView or other EFIS system with stereo
output.
Used exclusively for non-muting stereo input
grounds, such as EFIS stereo audio output
grounds. Do not connect to any other
grounds.
The Music In left and right channels (Pins 24
and 11) are over-ridden by the inputs
connected to the stereo Music In jack on the
front of the Intercom.
