- Page 1 AR88.80-P-8500V Page 1 of 3 AR88.80-P-8500V Remove/install outer A-pillar paneling 18.9.03 MODEL 171.4 1 Paneling 2 Screw 3 Clip 4 Retaining clips 6 Retaining rail P88.80-2104-06 © 2007 Mercedes-Benz USA, LLC...
- Page 2 Turn locks (5) until paneling (1) can be Only when replacing paneling (1) or removed from retaining rail (6) retaining rail (6). Installation: Replace locks (5). Remove paneling (1) from retaining rail Install in the reverse order © 2007 Mercedes-Benz USA, LLC...
- Page 3 AR88.80-P-8500V Page 3 of 3 110 589 03 59 00 Mounting wedge © 2007 Mercedes-Benz USA, LLC...
