ergo vac compact
6

Application

Do use this device until you have read and understood the safety instructions at the beginning of
these instructions for use.
Caution
The device is a BF type device.
During operation, make sure that neither the patient- nor the conductive parts of the patient connec-
tion or the electrodes (including the neutral ones) come into contact with other persons or conducti-
ve parts (even if they are grounded).
The device must not be used if the mains connection cable is damaged or there is a
suspicion of damage.
6.1

Operating Conditions

The device is not suitable for continuous operation; switch off again after use.
Caution
High-frequency fields and radiation can influence the quality of ECG leads.
6.2

Starting a Recording

1 Preparing the patient
2 Switch on device and apply electrodes
3 Ask the patient about their well-being (note the suction strength of the electrodes)
4 Determine and adjust suction strength
5 Performing a measurement
6 Switch off the vacuum pump with the
7 The system switches off automatically after 5 seconds.
8 (Optional) After long periods of use and/or heavy perspiration by patients, the system can blow out air by
the pressing of the cleaning button
After long periods of use and/or heavy perspiration by patients, the system can blow out moisture ingress
by the pressing of the cleaning button for 2 seconds
9 Cleaning the electrodes (See chapter 7.2.1, page 23)
Seite 20
User Guide
The lower the pressure level, the better the skin tolerance!
Level 1 & 2: for smooth skin
Level 3: for lightly-hairy skin
6, 8
/
Level 4: for medium-hairy skin
Level 5: for very hairy skin
button, the electrodes detach from the patient.
2
4
