ergo vac compact
2.6

Fixation of Cable Arm

Standard-Fixation ITD (accessory option, must be ordered separately)
2.7

Label

2.8

Scope of Delivery

Cable arm with patient module
Electrode suction hose (6 x 1.10 m / 4 x 1.30 m)
Spacers (2 pcs with 3 rows / 2 pcs with 2 rows)
Medical grade power supply
ECG connection cable 3.7m (15-pin D-Sub)
ECG Spray 250 ml
Standard bracket
Screw set consisting of:
Seite 12
User Guide
2021-05
2 x cable ties 200 mm
1 x D-sub connection kit
1 x cable clip, small
1 x 5 mm and 1 x 2.5 mm Allen key
4 x each of M6x12 / M6x16 / M6x20 Allen screw
4 x each of M6 nut / M6 self-locking / M6 square nut
4 x 6.3 washer / 4 x 6.37 spring washer / 4 x rubber feet
Operation manual
