• LOGIC/LOGIC-1 UNIT (BOTTOM VIEW)
CPU (IC27)
Under the shield plate
Clock Oscillator (X1)
Under the shield plate
5 V Regulator (IC40)
(for LCD Backlight)
*Only for IC-A25N
J1
2-2
J3*
GPS Module (IC17)*
Inside the shield case
