Yolink YS6704-UC Installation & User Manual page 11

C o n n e c t t h e fi rs t w i re y o u u n s c re w t o t h e a s s o c i a t e d s c re w t e r m i n a l o n t h e I n - w a l l
O u t l e t ; d o t h e s a m e fo r t h e re m a i n i n g t w o w i re s
B efo re co n n e c n g t h e w i re to t h e te r m i n a l , e n s u re t h e re i s a b o u t 1 / 2 i n c h o f b a re w i re v i s i b l e ( st r i p o ff
i n s u l a o n a s n e e d e d )
Insert the wire into the terminal
Tighten the screw terminal
Gently tug on the wire to ensure a ght connec on
HOT
1/2 inch
Hot/Live
Neutral
Ground
Insert the associated
(hot, neutral, Ground)
wires
Tighten the screw
9
