We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this ceiling fan. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
USE AND CARE GUIDE
CEDAR LAKE 44-INCH CEILING FAN
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
To view an instructional video on how to install this product:
1. Go to www.homedepot.com and enter either the Item or Model number, found in the top
right corner of the cover of this instruction manual, in the search eld.
2. Click on your product from the list of search results and click on the video link in the
"Product Overview" section.
Thank you for choosing Hampton Bay!
THANK YOU
Item #1005 819 929
Model #52109
UL Model #44-BERT
Advertisement
Related Manuals for HAMPTON BAY CEDAR LAKE 52109
Summary of Contents for HAMPTON BAY CEDAR LAKE 52109
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ..............2 Assembly ................7 Safety Information ............... 2 Operation ................14 Warranty ................3 Care and Cleaning ............. 15 Pre-Installation ..............3 Troubleshooting ..............15 Installation ................6 Safety Information READ AND SAVE THESE INSTRUCTIONS. WARNING: To reduce the risk of personal injury, do not bend the blade brackets (also referred to as To reduce the risk of electric shock, ensure the electricity has... -
Page 3: Warranty
A certain amount of “wobble” is normal and should not be considered a defect. Servicing performed by unauthorized persons shall render the warranty invalid. There is no other express warranty. Hampton Bay hereby disclaims any and all warranties, including but not limited to those of merchantability and fitness for a particular purpose to the extent permitted by law. - Page 4 Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Part Description Quantity Plastic wire connector Blade arm screw Hanger pin Blade screw Locking pin Blade decorative nut Pull chain extension...
- Page 5 Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Slide-on mounting bracket Blade arm (inside canopy) Blade Ball/downrod assembly Light kit pan Canopy Light kit assembly Decorative motor collar cover LED bulb Fan-motor assembly Glass shade assembly IMPORTANT: This product and/or components are governed by one or more of the following U.S.
-
Page 6: Installation
Installation MOUNTING OPTIONS NOTE: You may need a longer downrod to maintain WARNING: To reduce the risk of fire, electric shock, proper blade clearance when installing on a steep, sloped or personal injury, mount the fan to an outlet box ceiling. -
Page 7: Assembly
Assembly - Standard Ceiling Mount Attaching the blades to Preparation for standard mounting the blade arms NOTE: The magnet is pre-attached on the canopy bottom ☐ Attach a blade (G) to the blade arm (F) by aligning the holes on cover (HH) for you to remove and install easily. - Page 8 Assembly - Standard Ceiling Mount (continued) Routing the wires Assembling the fan ☐ Route the wires exiting the top of the fan motor assembly WARNING: Failure to properly install the locking (E) through the decorative motor collar cover (D) and then pin (CC) could result in the fan becoming loose the center of the canopy bottom cover (HH).
- Page 9 Assembly - Hanging the Fan Attaching the fan to the Hanging the fan electrical box WARNING: To reduce the risk of fire, electric shock, ☐ Carefully lift the fan-motor assembly (E) up to the slide- or other personal injury, mount the fan to an outlet on mounting bracket (A).
- Page 10 Assembly - Hanging the Fan (continued) Making the electrical connections WARNING: Each wire nut supplied with this fan is designed to Outlet box accept up to one 12-gauge house wire and two wires from the in the ceiling(NN) fan. If you have larger than 12-gauge house wiring or more than one house wire to connect to the fan wiring, consult an electrician for the proper size wire nuts to use.
- Page 11 Assembly - Hanging the Fan (continued) Mounting the fan-motor assembly Wrapping the extra wire (standard mount) WARNING: When using the standard ball/downrod mounting, NOTE: Follow this step ONLY if you did not cut the extra the tab in the ring at the bottom of the mounting bracket length off from the wires coming from the ceiling fan.
- Page 12 Assembly - Attaching the Light Kit Installing the light kit pan IMPORTANT: It is critical to attach the light kit pan (H) using the quick connector. The fan will not operate unless the light kit pan is connected to the fan. ☐...
- Page 13 Assembly - Attaching the Light Kit (continued) Installing the bulb and the glass shade assembly CAUTION: Make sure the power is off before attaching or removing the glass shade assembly. WARNING: Allow the glass shade assembly to cool completely before removing. Keyhole slot ☐...
-
Page 14: Operation
Operating Your Fan A. Warm weather Turn on the power and check the operation of the fan. The fan pull chain controls the fan speed as follows: 1 pull - High; 2 pulls - Medium, 3 pulls - Low, 4 pulls - Off. Speed setting for warm or cool weather depends on factors such as the room size, ceiling height, number of fans and so on. -
Page 15: Care And Cleaning
Care and Cleaning WARNING: Make sure the power is off before cleaning your fan. ☐ Because of the fan’s natural movement, some connections may become loose. Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. It is not necessary to remove the fan from the ceiling. ☐... - Page 16 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) the device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
