Kinetik DMT-4336 Owner's Manual

Instant Flexible
Digital Thermometer
Owner's Manual
Warning :
Read instructions thoroughly before using digital thermometer.
Choking Hazard: Thermometer cap and battery may be fatal if swallowed. Do not allow children to use this device
without parental supervision.
Do not use thermometer in ear. Designed use is for oral, rectal, and armpit (axilla) readings only.
Do not place thermometer battery near extreme heat as it may explode.
Remove battery from the device when not in operation for a long time.
The use of temperature readings for self-diagnosis is dangerous. Consult your doctor for the interpretation of
results. Self-diagnosis may lead to the worsening of existing disease conditions.
Do not attempt measurements when the thermometer is wet as inaccurate readings may result.
Do not bite the thermometer. Doing so may lead to breakage and/or injury.
Do not attempt to disassemble or repair the thermometer. Doing so may result in inaccurate readings.
After each use, disinfect the thermometer especially in case the device is used by more than one person.
Do not force the thermometer into the rectum. Stop insertion and abort the measurement when pain is present.
Failure to do so may lead to injury.
Do not use thermometer orally after being used rectally.
For children who are two years old or younger, please do not use the devices orally.
If the unit has been stored at temperatures over 41°F~104°F (5°C~40°C), leave it in 41°F~104°F (5°C~40°C)
ambient temperature for about 15 minutes before using it.

Indications For Use

The digital thermometers are intended to measure the human body temperature in regular mode orally, rectally or
under the arm. And the devices are reusable for clinical or home use on people of all ages, including children under 8
years old with adult supervision.

Please Read Carefully Before Using

This digital thermometer provides a quick and highly accurate reading of an individual's body temperature. To better
understand its functions and to provide years of dependable results, please read all instructions rst.
This appliance conforms to the following standards:
EN 12470-3 Clinical thermometers —Part 3: Performance of compact electrical thermometers (non-predictive and
predictive) with maximum device,
ISO 80601-2-56 Medical electrical equipment —Part 2-56:Particular requirements for basic safety and essential
performance of clinical thermometers for body temperature measurement,
EN 60601-1-11 Medical electrical equipment —Part 1-11: General requirements for basic safety and essential
performance – Collateral Standard: Requirements for medical electrical equipment and medical electrical systems
used in the home healthcare environment and complies with the requirements of EN 60601-1-2(EMC),
IEC/EN 60601-1(Safety) standards. And the manufacturer is ISO 13485 certi ed.
Contents
1 Thermometer, 1 Owner's Manual, 1 Storage Case
Product Illustration
Figure 1
DMT-4336
Probe

Precaution

* The performance of the device may be degraded should one or more of the following occur:
- Operation outside the manufacturer's stated temperature and humidity range.
- Storage outside the manufacturer's stated temperature and humidity range.
- Mechanical shock (for example, drop test)or degraded sensor.
- Patient temperature is below ambient temperature.
* Portable and mobile RF communications can affect the device. The device needs special pre-
cautions regarding EMC according to the EMC information provided in the accompany documents.
* Keep thermometer away from Magnetic Resonance equipment.
Symbol Explanation
Direct Current
Type BF Applied Part
Read the instructions (actual symbol
colours are white on a blue background)
European Authorized Representative
Speci cations
Type:
Measure Range:
Accuracy:
Operating mode:
Display:
Memory:
Battery:
Battery life:
Dimension:
Weight:
Expected service life:
Ambient operating range:
Storage and transportation
condition:
Ingress Protection Rating:
Classi cation:
°C/°F Switchable
Temperature readings are available in the Celsius or Fahrenheit scale (°C/°F; located in the upper right corner of LCD.)
With the unit off, press and hold the On/Off Button for approximately 2 seconds to change the current setting.
Kinetik DMT-4336 EN IB 20201203
LCD ON/OFF Button
Battery Cover
Manufacture date
Manufacturer
55°C
Storage and Transportation Temperature
Limit: -20°C~55°C (-4°F~131°F)
-20°C
Digital Thermometer (Not Predictive)
32.0°C ~ 42.9°C (90.0°F ~ 109.9°F) (°C/°F chosen by manufacturer)
±0.1°C (±0.2°F) during 35.5°C ~ 42.0°C (95.9°F ~ 107.6°F) at 18°C ~ 28°C
(64.4°F ~ 82.4°F) ambient operating range ±0.2°C (±0.4°F) for other measuring
and ambient operating range
Direct Mode
Liquid crystal display, 3 1/2 digits
For storing the last measured value
One 1.5V DC. button battery (size LR41 or SR41, UCC 392)
Approx. 200hours of continuous operation or 1 year with 3 measurements per day
13.1cm x 2.0cm x 1.2cm (L x W x H)
Approx. 10 grams including battery
Three years
Temperature: 5°C ~ 40°C (41°F ~ 104°F)
Relative humidity: 15% ~ 95%RH
Atmospheric Pressure : 700hPa ~ 1060hPa
Temperature: -20°C ~ 55°C (-4°F ~ 131°F)
Relative humidity: 15% ~ 95%RH
Atmospheric Pressure : 700hPa ~ 1060hPa
IP 27
Type BF

Directions

1. Press the On/Off Button next to LCD display. A tone will sound as the screen shows
recorded temperature. After showing the self-test temperature, the thermometer is now in the testing mode.
2. Position thermometer in desired location (mouth, rectum, or armpit.)
a) Oral Use: Place thermometer under tongue as indicated by " " position shown in Figure 2.
Close your mouth and breathe evenly through the nose to prevent the measurement from
being in uenced by inhaled/exhaled air.
b) Rectal Use: Lubricate silver probe tip with petroleum jelly for easy insertion. Gently insert
sensor approximately lcm (less than 1/2 ") into rectum.
c) Armpit Use: Wipe armpit dry. Place probe in armpit and keep arm pressed rmly at side.
From a medical viewpoint, this method will always provide inaccurate readings, and
should not be used if precise measurements are required.
3. The degree sign ashes throughout the testing process. When ashing stops an alarm will beep for approximately
10 seconds. The measured reading will appear on the LCD simultaneously. The minimum measurement time until
the signaling tone (beep) must be maintained without exception. The measurement continues even after the buzzer
noti cation. So that in order to achieve better body temperature measurement result, recommend to keep the
probe in mouth and rectum about 2 minutes, or in armpit about 5 minutes regardless of the beep sound and at
least 30 seconds measurement interval should be maintained.
4. To prolong battery life, press the On/Off Button to turn unit off after testing is complete. If no action is taken, the
unit will automatically shut off after around 10 minutes.

Troubleshooting

Error message Problem
Temperature taken is Turn off, wait one minute and take a new temperature
lower than 32.0°C (90.0°F) via close contact and suf cient rest.
Temperature taken is Turn off, wait one minute and take a new temperature
higher than 42.9°C (109.9°F) via close contact and suf cient rest.
The system is not functioning Unload the battery, wait for 1 minute and repower it. If
properly. the message reappears, contact the retailer for service.
Dead battery: Battery icon is
Replace the battery.
ashing, can't be measurable.

Battery Replacement

1. Replace battery when " " appears in the lower right corner of LCD display.
2. Pull battery cover off as shown in Figure 3.
3. Gently pull out plastic circuit board with battery chamber approximately 1 cm (slightly less than 1/2".)
(See Figure 4)
4. Use pointed object such as a pen to remove old battery. Discard battery lawfully. Replace with new 1.5V DC button
type LR41 or SR41, UCC392, or equivalent. Be sure battery is installed with "
5. Slide battery chamber back into place and attach cover.
Figure 3 Figure 4

Cleaning And Disinfection

1) Immerse the thermometer probe in distilled water for at least 1 minute;
2) Using a clean, soft cloth to wipe the thermometer down to remove any residue;
3) Repeat step 1 and 2 for three times until no soil is seen with visual inspection after cleaning;
4) For thoroughly clean and disinfection, please use method A or B: Method A(High level disinfection): immerse the
thermometer probe in 0.55% OPA(O-Phthaldehyde), such as CIDEX OPA, for at least 12 minutes under temperature
at 20°C ; Method B(Low level disinfection): Using a clean soft cloth dipped in 70% medical alcohol, wipe the probe
3 times, at least one minute for each time.
5) Repeat step 1 to 3 to remove OPA residuals;
Note 1: Rectal use is not recommended for home use as OPA will not be readily available outside of a hospital. If
rectal measurement is necessary, we strongly recommend high level disinfection.
Note 2: Please operate according to the manual of OPA for reference.
To prevent damage to the thermometer please note and observe the following:
- Do not use benzene, paint thinner, gasoline or other strong solvents to clean the thermometer.
- Do not attempt to disinfect the sensing probe (tip) of the thermometer by immersing in alcohol, OPA or in hot water
(water over 122°F (50°C)) for long time.
- Do not use ultrasonic washing to clean the thermometer.

Calibration

The thermometer is initially calibrated at the time of manufacture. If the thermometer is used according to the use
instruction, periodic readjustment is not required. However, we recommend checking calibration every two years or
whenever clinical accuracy of the thermometer is in question. Turn on the thermometer and insert into the water bath
and then check the laboratory accuracy of thermometer. Please send the complete device to the dealers or
manufacturer.
The above recommendations do not supersede the legal requirements. The user must always comply with legal
requirements for the control of the measurement, functionality, and accuracy of the device which are required by the
scope of relevant laws, directives or ordinances where the device is used.

Limited Warranty

The thermometer is guaranteed for one year from the date of purchase. If the thermometer does not function properly
due to defective components or poor workmanship, we will repair or replace it free of charge. All components are
covered by this warranty excluding the battery. The warranty does not cover damages to your thermometer due to
improper handling. To obtain warranty service, an original or copy of the sales receipt from the original retailer is
required.
Disposal of this product and used batteries should be carried out
in accordance with the national regulations forthe disposal of
electronic products.
JOYTECH HEALTHCARE CO. LTD.
No.365, Wuzhou Road, Yuhang Economic Development Zone,
Hangzhou city, 311100 Zhejiang, China
Shanghai International Holding Corp. GmbH (Europe)
Eiffestrasse 80, 20537 Hamburg, Germany
The product is in compliance with the requirements
of MDD 93/42/EEC, "0197" is the identi cation
number of notify body.
, followed by last
Figure 2
Solution
+
" polarity facing up. (See Figure 5)
Figure 5
