- Page 1 ASSEMBLY, MAINTENANCE, & USER MANUAL MODEL #SSGM100 WARNING Read all precautions and instructions in this manual before using this equipment. Skywalker Holdings LLC Save this manual for future reference. P.O. Box 574, Brigham City, UT 84302...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Part List.....................................3 Part Identification................................4-5 Exploded Drawing................................6 Assembly...................................7-10 Limited Warranty................................11 STOP EVERYTHING YOU'RE DOING AND REGISTER YOUR PRODUCT Find our warranty registration online by typing in: www.skywalkertrampolines.com/registration/ You'll need to have the following information handy: • Name • Email address •... -
Page 3: Part List
BEFORE YOU BEGIN Thanks for choosing Skywalker Sports! We’re just as excited as you are to help your family live an active (but most importantly FUN) lifestyle. This model is one of our favorites, and we’re confident you’ll love it too. We want to make things easier for you, so we have listed all the important information that you (and your little outdoor adventurers) need to know. -
Page 4: Part Identification
PART IDENTIFICATION Before you begin, take a look at the drawings below to make sure you have all the parts! The numbers in the squares to the left (key numbers) will help you identify the parts during assembly. Upper Upright Lower Upright Volleyball Net (x1) Pole (x2) - Page 5 Bag (x1) Volleyball (x1) Pump (x1) Plastic strap (x2)
-
Page 6: Exploded Drawing
EXPLODED DRAWING (11) (10) (11) (10) (10) (10) (11) (10) (11) (10) (10) (10) (11) (10) -
Page 7: Assembly
ASSEMBLY READ THIS BEFORE YOU BEGIN • We’ve provided some tools to help with assembly, but you’re more than welcome to use your own • The assembly steps refer to parts by their descriptions and key numbers (see the part list on page 3) •... - Page 8 ASSEMBLY STEP 3 Attach four lug bolts (9), eight M6 washers (10), and four M6 locknuts (11) to the side of the upper upright pole (1) and the lower upright pole (2). Make sure all four lug bolts face the same direction. Then attach one lug bolt, two M6 washers, and one M6 locknut to the other side of the upper upright pole.
- Page 9 STEP 5 Push the upright ground stake (4) into the ground. Make sure the net is pulled tight. Attach the the upright ground stake to the lower upright pole (2). Upright Ground Stake (x2) STEP 6 Tie the ends of the three guide line cords (8) to the upper upright pole (1) and pull to secure the upright pole.
- Page 10 ASSEMBLY STEP 7 After the 3rd hole, thread the line through the eyelet on the ground stake (5), then through the 4th hole, and then tie a knot to secure. Place the ground stake into the ground and pull the line tight. Now repeat steps 6-7 to secure the remaining five guide line cords.
-
Page 11: Limited Warranty
LIMITED WARRANTY Skywalker Holdings, LLC warrants its products to be free from defects in material and workmanship under normal use and service conditions. The steel frame is warranted for three (3) years after the date of purchase. All other parts are warranted for one (1) year after the date of purchase. Warranty coverage extends only to the original retail purchaser from the date of original purchase. - Page 12 NOTE: Skywalker Holdings, LLC is not responsible or liable for indirect, special or consequential damaages arising out of or in connection with the use or performance of the product or other damages with respect to any econmic loss, loss of property, loss of revenue or profits, loss of enjoyment or use, cost of removal, installation or other consequential damages.
