Rf projection barometer with remote thermo sensor
Hide thumbs Also See for BAR338P:

Advertisement

Table of Contents

Enlarged version
MAIN UNIT CONTROLS
RF Projection Barometer
With Remote Thermo Sensor
Model No.: BAR338P (UK VERSION BAR338PU)
User's Manual
INTRODUCTION
Congratulations on your purchasing the BAR338P RF Projection
Barometer.
The BAR338P is a multifunction, RF-controlled projection calendar
clock which automatically synchronizes its current time and date
when brought within an approximate 1500 km radius of the radio
signal generated from Frankfurt, Germany (DCF77). (The UK
version from MSF Ruby, England)
The BAR338P is very easy to use. No wire installation is required
between the main unit and the remote unit.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BAR338P and is the answer not in the manual?

Questions and answers

Related Manuals for Oregon Scientific BAR338P

Summary of Contents for Oregon Scientific BAR338P

  • Page 1: Controls

    1500 km radius of the radio signal generated from Frankfurt, Germany (DCF77). (The UK version from MSF Ruby, England) The BAR338P is very easy to use. No wire installation is required between the main unit and the remote unit.
  • Page 2 A3 IN/OUT BUTTON Changes between indoor and outdoor temperature or activates the temperature automatic scan function A4 CLOCK BUTTON Toggles the clock and calendar display or triggers the calendar clock setting mode A5 ALARM BUTTON Displays the alarm time or sets the alarm status A6 UP [ ] AND DOWN [ ] BUTTONS...
  • Page 3 A12 PROJECTION ON SLIDE SWITCH REMOTE UNIT CONTROLS Used with the projector power adapter to enable extended use of the projector B1 LED INDICATOR Flashes when the remote unit transmits a reading MAIN UNIT INDICATORS B2 RESET BUTTON A13 WEATHER FORCAST Returns all settings to default values Indicates the change of weather pattern A14 ALARM ON INDICATOR...

  • Page 4: Battery Installation

    HINTS FOR BEST OPERATION HOW TO USE THE PROJECTOR • Insert batteries for the remote unit before doing so for the main The projector projects the current time and remote temperature unit. onto a wall or ceiling. • Set the main and remote unit within range (20 to 30 meters). •...

  • Page 5: Features

    1. Remove the cover on the bottom of the stand. Projector Features 2. Plug the adapter into the adapter socket. Feature Effect Instructions 3. Connect the power adapter to a wall socket. Adjustable Rotates 180° to cast Adjust by turning forwards 4.

  • Page 6: About Radio Reception

    Reception complete No reception, or Successful reception The BAR338P is designed to automatically synchronize its manually adjusted current time and date when brought within range of the DCF77 RF signal. (UK version within a 1500km radius of radio signal (MSF) from...

  • Page 7: Temperatures

    To enable the feature again, hold down the buttons again. The ALARM AND SNOOZE FUNCTION ] signal will start blinking to initiate reception automatically. When the alarm is activated, it will go off at the set time. The display will light up for five seconds with the [ ] icon flashing.

  • Page 8: Disconnected Signals

    To clear the memory, select indoor or outdoor temperature display. Then press and hold [MEMORY] for two seconds to clear the memory for the selected display. DISCONNECTED SIGNALS sunny partly cloudy cloudy rainy snowy If without obvious reasons the display for the outdoor temperature becomes blank, press and hold [IN/OUT] for two seconds to enforce NOTE: an immediate search.

  • Page 9: Specifications

    Remote unit THE RESET BUTTON Operating range : -20.0°C to +60.0°C (-4.0°F to 140.0°F) The [RESET] button is used to enhance synchronization of signals after battery replacement or when the unit is operating in an Temperature resolution : 0.1°C (0.2°F) unfavorable way or malfunctioning.

  • Page 10: Note On Compliance

    However, there is no guarantee that interference will not occur in a Weight particular installation. If this equipment does cause harmful Main unit : 322 gm interference to radio or television reception, which can be determined Remote sensing unit : 100 gm by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Dimension...
