Pelican HeadsUp Lite 2680 Quick Start Manual

PELICAN
CAT. #2680
LED Recoil
HeadsUp Lite
2680
Both Cloth and Rubber
Straps Included.
PELICAN
You break it, we replace it... forever.
23215 Early Ave. • Torrance, CA 90505 USA
Tel (310) 326.4700 • FAX (310) 326.3311
www.pelican.com
REPLACEMENT PARTS
CAT# DESCRIPTION
2601 O-ring
2607 Cloth Head Strap
2608 Rubber Head Strap
OTHER PARTS ---
CALL CUSTOMER SERVICE DEPART
If your local retailer does not stock the
above accessory parts, you may order
them directly from Pelican Products. Send
check or money order in U.S. dollars, or
order by phone using MasterCard or Visa
(ask for customer service). SORRY NO
C.O.D.'S. California residents add 8
sales tax. Allow 2-3 week delivery time.
Pelican Products pays postage and
handling charges. POSTAGE PAID FOR
U.S. ZIP CODE AREAS ONLY.
CAUTION:
READ THIS NOTICE BEFORE USE.
Observe battery polarity labels on inside of
this light. DO NOT deviate from the correct
label polarity. DO NOT MIX BRANDS.
DO NOT MIX old and new batteries.
Always replace all batteries with new
alkaline batteries.
TM
TM
PELICAN
You break it, we replace it... forever.
23215 Early Ave. • Torrance, CA 90505 USA
Tel (310) 326.4700 • FAX (310) 326.3311
www.pelican.com
PELICAN CANADA
TM
10221-184 St. • Edmonton, Alberta T5S 2J4
Tele (780) 481.6076 • FAX (780) 481.9586
PELI PRODUCTS, S.A.
TM
c/ Casp, 33-B Pral. • 08010 • Barcelona, Spain
Tel (+34) 93.467.4999 • FAX (+34) 93.487.7393 www.peli.com
All trademarks and logos displayed herein are registered and
unregistered trademarks of Pelican Products, Inc. and others.
Eveready and Energizer are registered
trademarks of Eveready Battery Company, Inc.
Duracell is a registered trademark of the Gillette Company.
2683-311-000 © 2004 PELICAN PRODUCTS
Pelican Unconditional Lifetime Guarantee of
Excellence
If for any reason you are not satisfied with the qual-
ity or performance of any PELICAN product, we will
gladly replace the product or refund your money
(at your option) within 30 days of purchase through
the original retailer/dealer. PELICAN PRODUCTS
will continue to guarantee the product directly for
a lifetime against breakage or defects in workman-
ship. Lifetime guarantee does not cover the lamp or
batteries. The o-rings must be kept greased (and
replaced if damaged) per product instructions. This
guarantee is void only if the PELICAN product has
been abused beyond normal and sensible wear and
tear.
THE ABOVE GUARANTEE DOES NOT COVER
SHARKBITE, BEAR ATTACK OR CHILDREN
/ %
1
FAILURE TO COMPLY WITH ABOVE
4
WARNING COULD CAUSE SERIOUS
INJURY.
WARRANTY RETURN POLICY
Send all items for repair or replacement
directly to Pelican Products Customer
Service Department (Postage Paid). Per our
guarantee, Pelican Products will replace or
repair any broken or defective products.
Upon receipt of goods, Pelican Products
will notify you of any handling and return
postage charges.
ON/OFF
To turn on the HeadsUp Lite
ing away from you) turn the right side cap
towards you. To turn off, turn the cap away
from you.
HEADLAMP POSITIONING
A stretchable band is provided for
mounting around your head. The light can
be rotated up and down through 170˚.
CAUTION:
If light is not to be used for some time,
remove batteries to prevent possible
leakage and corrosion.
PRODUCT SPECIFICATIONS:
LED 1W
Battery Burn Time:
50% of light at 8 hours
Battery Type:
E91 1.5V Alkaline AA-cell (4)
Battery Brand:
JN/04 HR
Eveready Energizer ®
HeadsUp Lite
INSTRUCCIONES DE FUCIONAMIENTO
NO. DE CAT. 2680
Con Tecnología LED de reflexión
inversa (Recoil Technology
¿En qué consiste la Tecnología LED de reflexión
inversa?
Ahí está el secreto: al dirigir hacia atrás
el haz del LED, el reflector en la parte
posterior capta el 100% de la luz, y la refleja
al completo hacia adelante. El punto
luminoso cuadrado en el haz es la prueba
de que se utiliza toda la luz disponible y de
que no se produce proyección periférica.
Es un haz de luz realmente colimado que
atraviesa el humo denso, el polvo y demás
partículas. Tecnología LED de reflexión
inversa. Bien pensado, tendrá un faro en la
palma de la mano.
INSTRUCCIONES PARA
SUSTITUIR LAS PILAS
1. Retire el casquillo izquierdo (no oriente
la linterna hacia Ud.) girándolo en
sentido contrario al de las agujas
del reloj, dejando al descubierto el
compartimento de pilas.
HeadUp Lite
TM (light point-
With Recoil Technology
What is Recoil Technology
Here's the secret: by pointing the LED
backwards into the reflector, 100% of the light
is captured and projected forward. The squared
spot on the beam is your proof that all available
light is being used and there's no peripheral
projection. It's a true collimated beam that cuts
through thick smoke, dust, and other particulates.
Recoil LED Technology.
lighthouse in the palm of your hand.
BATTERY INSTRUCTIONS
1. Remove the left cap (light pointing away
from you) by turning counter-clockwise
exposing the battery compartment.
2. Remove used batteries and replace with
fresh batteries (as shown on polarity
sticker located on inside of body).
3. Place cap with side slot over locking
projections in body. Screw down
, Duracell ®
clockwise until cap is snug with body.
TM
2. Retire las pilas agotadas y sustitúyalas
por las nuevas (tal como se indica en
la pegatina de polaridad situada en el
interior del cuerpo).
3. Coloque el casquillo con la muesca
)
TM
lateral sobre los salientes de cierre
del cuerpo. Gírelo en el sentido de
as agujas del reloj hasta que se
acople correctamente al cuerpo.
ON/OFF
Para encender el frontal HeadsUp Lite
oriente la linterna hacia Ud.) gire el casquil-
lo derecho hacia usted. Para apagarla, gire
el casquillo en la dirección contraria.
COLOCACIÓN DEL FRONTAL
Se incluye una cinta elástica para ajustar la
linterna a su cabeza. La luz se puede dirigir
hacia arriba y hacia abajo, con un ángulo
de giro de 170 grados.
ADVERTENCIA:
Si la linterna no va a ser utilizada durante
un largo período, retire las pilas para evitar
las posibles fugas y la corrosión.
2680
TM
TM
Think of it as a
TM
(no
TM
